FO-4450U/FO-CS1
26
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
36 VRD-HT2HY223J AA C Resistor(1/2W 22KΩ ± 5%) [R6]
37 VRD-HT2EY183J AA C Resistor(1/4W 18KΩ ± 5%) [R9]
38 VRD-HT2EY100J AA C Resistor(1/4W 10Ω ± 5%) [R10]
39 VRD-HT2EY303J AA C Resistor(1/4W 30KΩ ± 5%) [R11]
40 VRD-HT2EY910J AA C Resistor(1/4W 91Ω ± 5%) [R12]
41 VRD-HT2EY300J AA C Resistor(1/4W 30Ω ± 5%) [R13]
42 VRD-HT2EY201J AA C Resistor(1/4W 200Ω ± 5%) [R14]
43 VRD-HT2EY391J AA C Resistor(1/4W 390Ω ± 5%) [R15]
44 VRD-HT2EY621J AA C Resistor(1/4W 620Ω ± 5%) [R16]
45 VRD-HT2EY223J AA C Resistor(1/4W 22KΩ ± 5%) [R17]
46 VRD-HT2EY223J AA C Resistor(1/4W 22KΩ ± 5%) [R18]
47 VRD-HT2EY751J AA C Resistor(1/4W 750Ω ± 5%) [R19]
48 VRD-HT2EY223J AA C Resistor(1/4W 22KΩ ± 5%) [R20]
49 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ± 5%) [R21]
50 VRD-HT2EY223J AA C Resistor(1/4W 22KΩ ± 5%) [R22]
51 VRD-HT2EY100J AA C Resistor(1/4W 10Ω ± 5%) [R23]
52 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ± 5%) [R24]
53 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ± 5%) [R26]
54 VRD-HT2EY100J AA C Resistor(1/4W 10Ω ± 5%) [R27]
55 RH-DX2007SCZZ AC B Diode bridge(S1ZB60) [REC1]
!
56 RTRNZ2163SCZZ AH B Transformer(TRTEP17-0411F) [T1]
57 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD1]
58 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD2]
59 VHEHZ27-1//-1 AB B Zener diode(HZ27-1) [ZD3]
60 VHE1ZC15///-1 AC B Zener diode(1ZC15) [ZD4]
61 VHEMTZJ8R2B-1 AC B Zener diode(MTZJ8R2B) [ZD5]
62 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD6]
63 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD7]
(Unit)
901 DCEKL422CXH01 BM E LIU PWB unit
[17] Printer PWB unit
1 VCEAGA1CW227M AB C Capacitor(16WV 220µ F) [C2]
2 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C102]
3 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C105]
4 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C106]
5 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µ F) [C107]
6 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µ F) [C109]
7 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C111]
8 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C112]
9 VCKYCY1HB103K AA C Capacitor(50WV 0.01µ F) [C113]
10 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C115]
11 VCKYCY1EB683K AD C Capacitor(25WV 0.068µ F) [C116]
12 VCKYCY1HB103K AA C Capacitor(50WV 0.01µ F) [C119]
13 VCKYCY1HB103K AA C Capacitor(50WV 0.01µ F) [C120]
14 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C124]
15 VCKYCY1HB103K AA C Capacitor(50WV 0.01µ F) [C126]
16 VCKYCY1HB103K AA C Capacitor(50WV 0.01µ F) [C127]
17 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C128]
18 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C133]
19 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C134]
20 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C135]
21 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C136]
22 VCKYCY1EB333K AB C Capacitor(25WV 0.033µ F) [C137]
23 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C138]
24 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C142]
25 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C144]
26 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C145]
27 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C146]
28 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C147]
29 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C148]
30 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C149]
31 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C150]
32 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C151]
33 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C152]
34 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C153]
35 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C154]
36 RC-FZ3039XHZZ AB C Capacitor(16WV 0.1µ F) [C155]
37 QCNCW2527SC3J AM C Connector(30pin) [CN1]
38 QCNCM2484SC0B AB C Connector(2pin) [CN2]
39 QCNCM2584SC0B AC C Connector(2pin) [CN3]
40 QCNCM2584SC1J AK C Connector(10pin) [CN4]
41 QCNCM2584SC0H AH C Connector(8pin) [CN5]
42 QCNCM2584SC0F AH C Connector(6pin) [CN6]
43 QCNCM2484SC0H AD C Connector(8pin) [CN7]
44 QCNCM2656SC0C AF C Connector(3pin) [CN8]
45 QCNCM7014SC0E AB C Connector(5pin) [CN9]
46 QCNCM2498SC0B AB C Connector(2pin) [CN10]
47 QCNCM2584SC1E AL C Connector(5pin) [CN11]
48 QCNCM2584SC0E AD C Connector(5pin) [CN12]
49 QCNCM2584SC0D AD C Connector(4pin) [CN13]
50 QCNCM2585SC0D AD C Connector(4pin) [CN14]
51 QCNCM2401SC0D AC C Connector(4pin) [CN15]
52 RH-DX2308XHZZ AH B Diode(RB501V-40TE-17) [D100]
53 VHD1SS355//-1 AB B Diode(1SS355) [D101]
[16] LIU PWB unit
