FO-4450U/FO-CS1
30
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[24] 2nd paper cassette PWB unit(FO-CS1)
1 VCEAGA1EW106M AA C Capacitor(25WV 10µ F) [C1]
2 VCEAGA1EW335M AC C Capacitor(25WV 3.3µ F) [C2]
3 VCEAGA1EW106M AA C Capacitor(25WV 10µ F) [C3]
4 VCEAGA1HW475M AA C Capacitor(50WV 4.7µ F) [C4]
5 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C100]
6 VCKYCY1HB472K AA C Capacitor(50WV 4700PF) [C101]
7 VCKYCY1HB222K AA C Capacitor(50WV 2200PF) [C102]
8 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C104]
9 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µ F) [C105]
10 QCNCM7014SC0B AD C Connector(2pin) [CN2]
11 QCNCM7014SC0B AD C Connector(2pin) [CN3]
12 QCNCM2498SC0E AH C Connector(5pin) [CN4]
13 QCNCM2498SC0E AH C Connector(5pin) [CN5]
14 QCNCM7014SC1J AC C Connector(10pin) [CN6]
15 QCNCM7014SC1J AC C Connector(10pin) [CN7]
16 QCNCM7014SC0D AB C Connector(4pin) [CN8]
17 QCNCM7014SC0D AB C Connector(4pin) [CN9]
18 QCNCM2661XH0C AH C Connector(3pin) [CN10]
19 QCNCM2660XHZZ AH C Connector(2pin) [CN10A]
20 QCNCM2401SC0B AA C Connector(2pin) [CN11]
21 QCNCM2401SC0B AA C Connector(2pin) [CN12]
22 QCNCM2661XH0C AH C Connector(3pin) [CN13]
23 QCNCM2660XHZZ AH C Connector(2pin) [CN13A]
24 VHD1SR139-400 AB B Diode(1SR139) [D1]
25 VHD1SR139-400 AB B Diode(1SR139) [D2]
26 VHDDSS133//-1 AA B Diode(1SS133) [D3]
27 VHDSR104///-1 AF B Diode(SR104) [D4]
28 VHDSR104///-1 AF B Diode(SR104) [D5]
29 VHDSR104///-1 AF B Diode(SR104) [D6]
30 VHDSR104///-1 AF B Diode(SR104) [D7]
31 VHVICPS18//-1 AE B IC protector(ICP-S1.8) [F100]
32 VHVICPS10//-1 AG B IC protector(ICP-S1.0) [F101]
33 VHVICPS10//-1 AG B IC protector(ICP-S1.0) [F102]
34 RH-IX2311XHZZ AL B IC(HD74HC157FPEL) [IC1]
35 RH-IX2312XHZZ AL B IC(HD74HC164FPEL) [IC2]
36 RH-IX2313XHZZ AH B IC(HD74HC02FPEL) [IC3]
37 VHIMTD2007F-1 AU B IC(MTD2007F) [IC4]
38 VHPSG206S//-1 AG C Photo transistor(SG206S) [PC1]
39 VRS-HT3AA1R0J AA C Resistor(1W 1Ω ± 5%) [R1]
40 VRS-HT3AA1R0J AA C Resistor(1W 1Ω ± 5%) [R2]
41 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ± 5%) [R100]
42 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ± 5%) [R101]
43 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ± 5%) [R102]
44 VRS-CY1JB133J AA C Resistor(1/16W 13KΩ ± 5%) [R103]
45 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ± 5%) [R104]
46 VRS-CY1JB752J AA C Resistor(1/16W 7.5KΩ ± 5%) [R105]
47 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ± 5%) [R106]
48 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ± 5%) [R107]
49 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ± 5%) [R108]
50 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ± 5%) [R109]
51 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ± 5%) [R110]
52 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ± 5%) [R111]
53 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ± 5%) [R112]
54 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ± 5%) [R113]
55 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ± 5%) [R114]
56 VRS-CY1JB361J AA C Resistor(1/16W 360Ω ± 5%) [R115]
57 VRS-CY1JB361J AA C Resistor(1/16W 360Ω ± 5%) [R116]
58 VRS-CY1JB153J AA C Resistor(1/16W 15KΩ ± 5%) [R117]
(Unit)
901 DCEKZ426CXH01 BK E 2nd paper cassette PWB unit
