FO-4450U/FO-CS1
Switch setting and function
1 Reserved 0
2 Reserved 0
3 Reserved 0
SW54
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
Duplex scan Continuous Black Line Count
(Black line detection when reading for 1 2 3 4567
Not used
1 transmission) No. 1 0 0 0 0000 0
2 No. 2 0 0 0 0111
Other
0
3 No. 3 0 0 1 1001 1
4 No. 4 0 1 0 1010 1
Duplex scan Black Line Percent
(Black page detection when reading for
Not found
1.0% 1.5% 2.0% 2.5% 3.0% 3.5% 4.0%
5 transmission) No. 5 0 0 0 0 0 0 0 0 0
SW55
6 No. 6 0 0 0 0 1 1 1 1 1
7 No. 7 0 0 1 1 0 0 1 1 0
8 No. 8 0 1 0 1 0 1 0 1 1
Black Line Percent
4.5% 5.0% 5.5% 6.0% 7.0% 8.0% 9.0%
10.0%
5 No. 5 1 1 1 11111
6 No. 6 0 0 0 01111
7 No. 7 0 0 1 10011
8 No. 8 0 1 0 10101
Duplex scan Continuous Black Line Count
(Black line detection when reading for copies) 1 2 3 4567
Not used
1 No. 1 0 0 0 0000 0
2 No. 2 0 0 0 0111
Other
0
3 No. 3 0 0 1 1001 1
4 No. 4 0 1 0 1010 1
Duplex scan Black Line Percent
(Black page detection when reading for
Not found
1.0% 1.5% 2.0% 2.5% 3.0% 3.5% 4.0%
5 copies) No. 5 0 0 0 0 0 0 0 0 0
SW56
6 No. 6 0 0 0 0 1 1 1 1 1
7 No. 7 0 0 1 1 0 0 1 1 0
8 No. 8 0 1 0 1 0 1 0 1 1
Black Line Percent
4.5% 5.0% 5.5% 6.0% 7.0% 8.0% 9.0%
10.0%
5 No. 5 1 1 1 11111
6 No. 6 0 0 0 01111
7 No. 7 0 0 1 10011
8 No. 8 0 1 0 10101
1 Reserved 0
2 Reserved 0
3 Reserved 0
SW57
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
NO.
DATA
NO.
ITEM
Remarks
Initial
setting
10
2 – 19
