Sharp FO-4450 - Memory Reception

FO-4450U/FO-CS1
3 – 12
Parts list (Fig. 4)
Fig. 4
3
4
5
1
2
2
2
2
7
9
8
Printer PWB
Printer PWBPrinter PWB
Control PWB
Control PWB
Control PWB
LIU PWB
6
6
6
6
6
6
6
1
2
3
4
5
6
7
8
9
4 PWB unit
No. Part name Qty
1 Main unit 1
2 Screw (3×6) 7
3 Screw (3×10) 1
4 Band 1
5 Core (F2146) 1
6 Connector 20
7 LIU PWB unit 1
8 Control PWB unit 1
9 Printer PWB unit 1
