Sharp FP-A60UW User Manual

E-10
CLEANING THE FILTERS
1
Turn off the unit, and unplug the
power cord.
2
Remove the Front Panel.
(Refer to E-8)
3
Clean the filter and Dust sensor.
Gently remove dust from the filter, using a
vacuum cleaner with attachment or similar tool.
Dust Sensor
(FP-A80U only)
Remove the Sensor cover, and remove the
dust on the Sensor filter.
If it is very dirty, wash it with water and dry it
thoroughly.
CLEANING THE UNIT
Dust sensor
(FP-A80U only)
Deodorizing Pre filter
Sensor cover
Sensor filter
MAINTENANCE
Wipe with a dry, soft cloth
.
For stubborn stains or dirt, use a soft cloth
dampened with warm water.
Do not use volatile fluids and
detergents.
Benzine, paint thinner, polishing powder,
detergent ingredients etc., may damage
the unit.
Care Cycle :
Whenever dust accumulates on the unit or every 1 month.
OM_FP-A80U_A60U-EN+SP.indb 10 8/5/11 9:42:24 AM

Sharp FP-A60UW Specifications

General

Brand	Sharp
Model	FP-A60UW
Category	Air Cleaner
Language	English
