Sharp GX-CH170X User Manual

PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
GX-CH170X/CH170Z
C911,912 VCTYMN1CX222K J AA 0.0022 µF,16V
C913,914 VCTYMN1CX272K J AA 0.0027 µF,16V
C915~918 VCKYMN1HB331K J AA 330 pF,50V
C919,920 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C921 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
R1 VRD-ST2EE100J J AA 10 ohm,1/4W
R2 VRD-MN2BD330J J AA 33 ohms,1/8W
R3 VRD-MN2BD470J J AA 47 ohms,1/8W
R5 VRD-ST2CD334J J AA 330 kohms,1/6W [X]
R5 VRD-ST2EE334J J AA 330 kohms,1/4W [Z]
R6 VRD-ST2CD824J J AA 820 kohms,1/6W [X]
R6 VRD-ST2EE824J J AA 820 kohms,1/4W [Z]
R7 VRD-ST2EE121J J AA 120 ohms,1/4W [Y]
R7 VRD-ST2EE391J J AA 390 ohms,1/4W [X]
R9 VRD-MN2BD223J J AA 22 kohms,1/8W
R11 VRD-MN2BD222J J AA 2.2 kohms,1/8W [Z Only]
R25 VRD-ST2CD121J J AA 120 ohms,1/6W [X]
R25 VRD-ST2EE121J J AA 120 ohms,1/4W [Z]
R26 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R27 VRD-MN2BD333J J AA 33 kohms,1/8W
R28 VRD-MN2BD104J J AA 100 kohm,1/8W [Z Only]
R29 VRD-MN2BD153J J AA 15 kohms,1/8W
R30 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R35 VRD-ST2CD182J J AA 1.8 kohms,1/6W [X]
R35 VRD-ST2EE100J J AA 10 ohm,1/4W [Z]
R36 VRD-ST2EE681J J AA 680 ohms,1/4W [Z Only]
R40 VRD-MN2BD390J J AA 39 ohms,1/8W [Z Only]
R42 VRD-MN2BD390J J AA 39 ohms,1/8W [Z Only]
R43 VRD-ST2CD182J J AA 1.8 kohms,1/6W [Z Only]
R50 VRD-MN2BD101J J AA 100 ohm,1/8W [Z Only]
R201~204 VRD-MN2BD102J J AA 1 kohm,1/8W
R205,206 VRD-MN2BD560J J AA 56 ohms,1/8W
R207,208 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R209,210 VRD-MN2BD154J J AA 150 kohms,1/8W
R211,212 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R213,214 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R215,216 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R217,218 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R219,220 VRD-MN2BD333J J AA 33 kohms,1/8W
R221~224 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R225,226 VRD-MN2BD561J J AA 560 ohms,1/8W
R227,228 VRD-MN2BD470J J AA 47 ohms,1/8W
R229,230 VRD-MN2BD103J J AA 10 kohm,1/8W
R231,232 VRD-ST2EE103J J AA 10 kohm,1/4W
R236,237 VRD-MN2BD103J J AA 10 kohm,1/8W
R238 VRD-MN2BD684J J AA 680 kohms,1/8W
R239,240 VRD-MN2BD103J J AA 10 kohm,1/8W
R241 VRD-MN2BD123J J AA 12 kohms,1/8W
R243 VRD-MN2BD563J J AA 56 kohms,1/8W
R250 VRD-ST2EE101J J AA 100 ohm,1/4W
R254 VRD-MN2BD223J J AA 22 kohms,1/8W
R255 VRD-ST2CD103J J AA 10 kohm,1/6W
R259,260 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R261 VRD-MN2BD273J J AA 27 kohms,1/8W
R262 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R264 VRD-MN2BD104J J AA 100 kohm,1/8W
R268 VRD-ST2CD153J J AA 15 kohms,1/6W
R351 VRD-MN2BD473J J AA 47 kohms,1/8W
R352 VRD-MN2BD104J J AA 100 kohm,1/8W
R353 VRD-MN2BD220J J AA 22 ohms,1/8W
R354~356 VRD-ST2EE470J J AA 47 ohms,1/4W
R357,358 VRD-MN2BD272J J AA 2.7 kohms,1/8W [Z Only]
R367,368 VRD-MN2BD562J J AA 5.6 kohms,1/8W [Z Only]
R381 VRD-ST2EE333J J AA 33 kohms,1/4W
R382,383 VRD-MN2BD183J J AA 18 kohms,1/8W
R384 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R385 VRD-MN2BD103J J AA 10 kohm,1/8W
R386 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R387 VRD-MN2BD563J J AA 56 kohms,1/8W
R391 VRD-ST2EE103J J AA 10 kohm,1/4W
R392 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R399 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R408 VRG-ST2EG2R7J J AB 2.7 ohms,1/4W,Fusible
R451,452 VRD-MN2BD224J J AA 220 kohms,1/8W
R454,455 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R456 VRD-ST2EE101J J AA 100 ohm,1/4W
R500 VRD-ST2EE680J J AA 68 ohms,1/4W
R501,502 VRD-ST2EE103J J AA 10 kohm,1/4W
R503,504 VRD-MN2BD102J J AA 1 kohm,1/8W
R505,506 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R507,508 VRD-ST2EE122J J AA 1.2 kohms,1/4W
R601,602 VRD-ST2EE102J J AA 1 kohm,1/4W
R603,604 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R605 VRD-MN2BD104J J AA 100 kohm,1/8W
R606 VRD-MN2BD102J J AA 1 kohm,1/8W
R607 VRD-ST2EE103J J AA 10 kohm,1/4W
R609,610 VRG-ST2EG3R3J J AB 3.3 ohms,1/4W,Fusible
R611,612 VRD-MN2BD121J J AA 120 ohms,1/8W
R614 VRD-MN2BD102J J AA 1 kohm,1/8W
R615,616 VRD-ST2EE223J J AA 22 kohms,1/4W
R621 VRD-MN2BD104J J AA 100 kohm,1/8W
R623 VRD-MN2BD103J J AA 10 kohm,1/8W
R651 VRG-ST2EG5R6J J AB 5.6 ohms,1/4W,Fusible
R652 VRD-ST2EE561J J AA 560 ohms,1/4W
R653 VRD-ST2EE271J J AA 270 ohms,1/4W
R654 VRD-MN2BD563J J AA 56 kohms,1/8W
R655 VRD-ST2EE102J J AA 1 kohm,1/4W
R656 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R657 VRD-ST2EE181J J AA 180 ohms,1/4W
R658 VRD-MN2BD223J J AA 22 kohms,1/8W
R659 VRD-ST2EE103J J AA 10 kohm,1/4W
R660 VRD-ST2EE561J J AA 560 ohms,1/4W
R662 VRD-ST2EE561J J AA 560 ohms,1/4W
R663 VRD-ST2EE223J J AA 22 kohms,1/4W
R664 VRD-MN2BD391J J AA 390 ohms,1/8W
R665 VRD-MN2BD103J J AA 10 kohm,1/8W
R667 VRD-ST2EE103J J AA 10 kohm,1/4W
R668 VRD-ST2CD104J J AA 100 kohm,1/6W
R669 VRD-ST2EE821J J AA 820 ohms,1/4W
R670 VRD-ST2EE102J J AA 1 kohm,1/4W [Z Only]
R671 VRD-MN2BD563J J AA 56 kohms,1/8W
R672 VRD-ST2EE102J J AA 1 kohm,1/4W
R673 VRD-ST2EE1R0J J AA 1 ohm,1/4W
R674 VRD-MN2BD102J J AA 1 kohm,1/8W
R675 VRD-ST2EE104J J AA 100 kohm,1/4W
R676 VRG-ST2EG3R3J J AB 3.3 ohms,1/4W,Fusible
R701,702 VRD-MN2BD102J J AA 1 kohm,1/8W
R703 VRD-MN2BD221J J AA 220 ohms,1/8W
R704~714 VRD-MN2BD102J J AA 1 kohm,1/8W
R716~720 VRD-MN2BD102J J AA 1 kohm,1/8W
R721 VRD-ST2CD102J J AA 1 kohm,1/6W
R722 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R724 VRD-MN2BD102J J AA 1 kohm,1/8W
R726,727 VRD-ST2CD473J J AA 47 kohms,1/6W
R728 VRD-MN2BD473J J AA 47 kohms,1/8W
R730,731 VRD-MN2BD153J J AA 15 kohms,1/8W
R732~734 VRD-MN2BD223J J AA 22 kohms,1/8W
R735 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R736 VRD-MN2BD103J J AA 10 kohm,1/8W
R737 VRD-MN2BD223J J AA 22 kohms,1/8W
R738~743 VRD-MN2BD153J J AA 15 kohms,1/8W
R744 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R745 VRD-MN2BD102J J AA 1 kohm,1/8W
R746 VRD-MN2BD104J J AA 100 kohm,1/8W
R747 VRD-ST2CD103J J AA 10 kohm,1/6W
R748 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R749 VRD-ST2CD102J J AA 1 kohm,1/6W
R750 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R751 VRD-MN2BD102J J AA 1 kohm,1/8W
R752~754 VRD-MN2BD103J J AA 10 kohm,1/8W
R755 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R756 VRD-MN2BD103J J AA 10 kohm,1/8W
R757 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R758 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R759 VRD-MN2BD153J J AA 15 kohms,1/8W
R760 VRD-ST2CD223J J AA 22 kohms,1/6W
R761 VRD-MN2BD102J J AA 1 kohm,1/8W
R762 VRD-MN2BD223J J AA 22 kohms,1/8W
R765,766 VRD-MN2BD103J J AA 10 kohm,1/8W
R767 VRD-ST2CD153J J AA 15 kohms,1/6W
R768 VRD-ST2EE103J J AA 10 kohm,1/4W
R770 VRD-MN2BD101J J AA 100 ohm,1/8W
R771 VRD-MN2BD103J J AA 10 kohm,1/8W
R772 VRD-ST2CD103J J AA 10 kohm,1/6W
R773 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R774 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R775 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R776 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R777 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R778 VRD-MN2BD152J J AA 1.5 kohms,1/8W
– 3 –
!
!
!
!
