Sharp GX-CH170X User Manual

NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PART CODE
PRICE
RANK
DESCRIPTION
GX-CH170X/CH170Z
R779 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R780 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R781 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R782 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R783 VRD-MN2BD331J J AA 330 ohms,1/8W
R784 VRD-ST2CD331J J AA 330 ohms,1/6W [Z Only]
R785,786 VRD-MN2BD331J J AA 330 ohms,1/8W
R787 VRD-MN2BD123J J AA 12 kohms,1/8W
R788 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R789 VRD-ST2CD473J J AA 47 kohms,1/6W
R801 VRD-MN2BD102J J AA 1 kohm,1/8W
R802 VRD-MN2BD104J J AA 100 kohm,1/8W
R803 VRD-MN2BD153J J AA 15 kohms,1/8W
R804 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R805 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R806 VRD-MN2BD101J J AA 100 ohm,1/8W
R807 VRD-MN2BD102J J AA 1 kohm,1/8W
R808 VRD-MN2BD123J J AA 12 kohms,1/8W
R809 VRD-MN2BD273J J AA 27 kohms,1/8W
R810 VRD-MN2BD823J J AA 82 kohms,1/8W
R811 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R812 VRD-MN2BD153J J AA 15 kohms,1/8W
R813 VRD-MN2BD333J J AA 33 kohms,1/8W
R814 VRD-MN2BD103J J AA 10 kohm,1/8W
R815 VRD-MN2BD473J J AA 47 kohms,1/8W
R816 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R817 VRD-MN2BD823J J AA 82 kohms,1/8W
R819 VRD-MN2BD393J J AA 39 kohms,1/8W
R820 VRD-MN2BD103J J AA 10 kohm,1/8W
R821 VRD-MN2BD563J J AA 56 kohms,1/8W
R822 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R823 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R824 VRD-MN2BD103J J AA 10 kohm,1/8W
R825 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R826,827 VRD-MN2BD224J J AA 220 kohms,1/8W
R828 VRD-ST2EE102J J AA 1 kohms,1/4W
R829 VRD-ST2EE102J J AA 1 kohm,1/4W
R830 VRD-ST2CD102J J AA 1 kohm,1/6W
R831 VRD-MN2BD102J J AA 1 kohm,1/8W
R832 VRD-MN2BD563J J AA 56 kohms,1/8W
R833 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R834 VRD-MN2BD102J J AA 1 kohm,1/8W
R835 VRD-MN2BD471J J AA 470 ohms,1/8W
R836,837 VRD-MN2BD473J J AA 47 kohms,1/8W
R838 VRD-MN2BD333J J AA 33 kohms,1/8W
R839,840 VRD-MN2BD223J J AA 22 kohms,1/8W
R842 VRD-ST2EE220J J AA 22 ohms,1/4W
R849 VRD-MN2BD104J J AA 100 kohm,1/8W
R856 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R857 VRD-MN2BD273J J AA 27 kohms,1/8W
R858 VRD-MN2BD681J J AA 680 ohms,1/8W
R860 VRD-MN2BD102J J AA 1 kohm,1/8W
R871 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R873,874 VRD-ST2CD101J J AA 100 ohm,1/6W
R875,876 VRD-MN2BD103J J AA 10 kohm,1/8W
R877 VRD-ST2EE221J J AA 220 ohms,1/4W
R878 VRD-MN2BD101J J AA 100 ohm,1/8W
R880 VRD-MN2BD101J J AA 100 ohm,1/8W
R903,904 VRD-MN2BD333J J AA 33 kohms,1/8W
R905,906 VRD-MN2BD683J J AA 68 kohms,1/8W
R907,908 VRD-MN2BD393J J AA 39 kohms,1/8W
R909,910 VRD-MN2BD153J J AA 15 kohms,1/8W
R911,912 VRD-MN2BD183J J AA 18 kohms,1/8W
R913,914 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R915,916 VRD-MN2BD183J J AA 18 kohms,1/8W
R917~920 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R921,922 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R923,924 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R925~928 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R929,930 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R931,932 VRD-MN2BD684J J AA 680 kohms,1/8W
R933,934 VRD-MN2BD102J J AA 1 kohm,1/8W
R935,936 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R937 VRD-ST2EE221J J AA 220 ohms,1/4W
OTHER CIRCUITRY PARTS
BI500/CNS3/CNS2 QCNWN0756AWZZ J Connector Ass’y,4-2-2Pin
BI501/CNS501 QCNWN0674AWZZ J AP Connector Ass’y,7-6Pin
BI651/CNS651 QCNWN0667AWZZ J AG Connector Ass’y,3-3Pin
BI801/CNS801 QCNWN0744AWZZ J AL Connector Ass’y,8-8Pin
BI802/CNS802 QCNWN0606AWZZ J AH Connector Ass’y,5-5Pin
BI803/CNS803 QCNWN0747AWZZ J AK Connector Ass’y,6-6Pin
BI851/CNS851 QCNWN0673AWZZ J AN Connector Ass’y,6-6Pin
BI852/CNS852 QCNWN0678AWZZ J AT Connector Ass’y,12-12Pin
CNP1 QCNCW012EAWZZ J Plug,5Pin [Z]
CNP1 92LCONE6P52287 J AC Plug,6Pin [X]
CNP2 92LCONE2P53253 J AB Plug,2Pin [Z Only]
CNP3 92LCONE2P53014 J Plug,2Pin [Z Only]
CNP201 92LCONE3P53253 J AB Plug,3Pin
CNP202 92LCONE5P53253 J AB Plug,5Pin
CNP204 QCNCW027KAWZZ J AE Plug,10Pin
CNP501 92LCONE6P53014 J AC Plug,6Pin
CNP504 92LCONE5P52287 J AC Plug,5Pin
CNP601 QTANA0404AWZZ J AF Terminal,Ext.Speaker
CNP602 QCNCW012MAWZZ J AG Plug,12Pin
CNP603 92LCONE5P52287 J AC Plug,5Pin [X]
CNP603 92LCONE6P52287 J AC Plug,6Pin [Z]
CNP651 92LCONE3P5267X J AB Plug,3Pin
CNP751 QCNCW012NAWZZ J AE Plug,13Pin
CNP753 92LCONEAP53254 J AD Plug,10Pin
CNP803 QCNCM932FAFZZ J AC Plug,6Pin
CNP851 92LCONE6P53253 J AC Plug,6Pin
CNP852 92LCONECP53253 J AD Plug,12Pin
CNS201 QCNWN0595AWZZ J AH Connector Ass’y,3Pin
CNS202 QCNWN0596AWZZ J AL Connector Ass’y,5Pin
CNS204 QCNWN0734AWZZ J AK Connector Ass’y,10Pin
CNS753 QCNWN0677AWZZ J AL Connector Ass’y,10Pin
CNW2 QCNWN0750AWZZ J AD Tip with Lead
CNW3 QCNWN0766AWZZ J Wire Lead,100mm [Z Only]
CNW502 VWAAC-BK130XX J Wire Lead,130mm
F651 92LFUSE-T252E J AD Fuse,T2.5A L 250V
F661,662 92LFUSE-T501E J AD Fuse,T500mA L 250V
F663 92LFUSE-T122E J Fuse,T1.25A L 250V
FW1 QCNWN0679AWZZ J AE Flat Cable,6Pin [X]
FW1 QCNWN0680AWZZ J AC Flat Cable,5Pin [Z]
FW504 QCNWN0749AWZZ J AD Flat Cable,5Pin
FW505 QCNWN0672AWZZ J AE Flat Cable,2Pin
FW602 QCNWN0668AWZZ J AG Flat Cable,12Pin
FW603 QCNWN0699AWZZ J AC Flat Cable,5Pin [X]
FW603 QCNWN0776AWZZ J AD Flat Cable,6Pin [Z]
FW652,653 QCNWN0666AWZZ J AD Flat Cable,2Pin
FW701 QCNWN0676AWZZ J AF Flat Cable,13Pin
FW702 QCNWN0755AWZZ J AD Flat Cable,11Pin
FW751 QCNWN0675AWZZ J AH Flat Cable,13Pin
J601 QJAKM0004AWZZ J AK Jack,Headphones
LCD801 RV-LX0020AWZZ J AT LCD
M601 92LMTR1746AASY J AP Motor with Pulley [Tape]
M701 92LMTR1858CASY J AS Motor with Chassis [Spin]
M702 92LMTR1854BASY J AP Motor with Gear [Slide]
M981 92LMTR2282DASY J AP Motor Ass’y [Loading]
RX701 VHLSPS4201C-1 J AN Remote Sensor
SO651 QSOCA0202AWZZ J AL Socket,AC Input [X]
SO651 92LSOK-720A J AK Socket,AC Input [Z]
SP601,602 VSP0010PBS3SA J AT Woofer
SP603,604 RALMB0101AFZZ J AB Tweeter
SW1 QSW-S0020AWZZ J AG Switch,Slide Type [Band]
[Z Only]
SW4 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
SW201 QSW-S0018AWZZ J AG Switch,Slide Type
[Record/Playback]
SW251 QSW-S0025AWZZ J AF Switch,Slide Type [Beat Cancel]
SW253 QSW-S0026AWZZ J AF Switch,Slide Type [Band] [X]
SW253 QSW-S0026AWZZ J AF Switch,Slide Type
[Tape Selector/FM Mode] [Z]
SW601 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 1 Main]
SW602 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 2 Main]
SW603 92LM-SW1658A J AB Switch,Leaf Type
[Tape 1/2 Selector]
SW651 QSW-S0021AWZZ J AH Switch,Slide Type [Function]
SW701 QSW-K0003AWZZ J AD Switch,Key Type [Power]
SW702 QSW-K0003AWZZ J AD Switch,Key Type [CD-Stop]
SW703 QSW-K0003AWZZ J AD Switch,Key Type [CD-Play]
SW704 QSW-K0003AWZZ J AD Switch,Key Type [CD-Pause]
SW705 QSW-K0003AWZZ J AD Switch,Key Type [CD-Cue]
SW706 QSW-K0003AWZZ J AD Switch,Key Type [CD-Review]
SW707 QSW-K0003AWZZ J AD Switch,Key Type [CD-Disc 1-2]
SW708 QSW-K0003AWZZ J AD Switch,Key Type [CD-Random]
SW709 QSW-K0003AWZZ J AD Switch,Key Type [Volume Up]
SW710 QSW-K0003AWZZ J AD Switch,Key Type [Volume Down]
SW711 QSW-K0003AWZZ J AD Switch,Key Type [CD-Program]
SW712 QSW-K0003AWZZ J AD Switch,Key Type [CD-Clear]
SW713 QSW-K0003AWZZ J AD Switch,Key Type
[CD-Tray 1 Open/Close]
– 4 –
!
!
!
!
!
