Sharp GX-CH170X User Manual

PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
GX-CH170X/CH170Z
SW714 QSW-K0003AWZZ J AD Switch,Key Type
[CD-Tray 2 Open/Close]
SW981 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Tray/Mechanism Up]
SW982 92LSWICHL1749A J AD Switch,Leaf Type [Tray 1]
SW983 92LSWICHL1749A J AD Switch,Leaf Type [Tray 2]
DECK MECHANISM PARTS
1 92LM-ANG1658A J AC Joint Bracket,Mechanism
3 92LM-BELT1651B J AB FR Belt
4 92LMBELT1658A1 J AC Drive Belt [Tape 1]
5 92LMBELT1658B1 J AC Drive Belt [Tape 2]
10 92LM-CSPR667J J AA Spring,Latch Plate
12 92LM-CSPR1651F J AA Spring,Back Tention
13 92LM-EH1658A J AG Head,Erase
14 92LM-ESPR1651A J AA Spring,Lock Plate
15 92LM-ESPR1651B J AA Spring,Holder Lock Lever
17 92LM-FRRA1651A J AF FR Roller Ass’y
18 92LM-FWA1651A J AG Flywheel Ass’y [Tape 2]
19 92LM-FWA1658A J AG Flywheel Ass’y [Tape 1]
20 92LM-GEAR1651C J AA Gear,FF
21 92LM-HPLT1746A J AC Plate,Head
22 92LM-ICAM1651A J AB Cam,Idler
23 92LM-ILA1651A J AB Idler Lever Ass’y
24 92LM-LEV1651G1 J AC Lever,Main Lock
25 92LM-LEV1651I J AA Lever,AS Killer
27 92LM-LEV1651K J AA Lever,Eject Joint
28 92LM-LEV1651L J AB Lever,Erase Prevention
29 92LM-LEV1658A1 J AB Lever,Record
30 92LM-LEV1658B J AA Lever,Play
31 92LM-LEV1658C J AA Lever,Rewind
32 92LM-LEV1658D J AB Lever,FF
33 92LM-LEV1658E J AB Lever,Stop
35 92LM-LEV1658H J AB Lever,Holder Lock
37 92LM-LEV1658J J AB Guide,Tape 1
38 92LM-LGA1746A J AF Lever Guide Ass’y
40 92LM-MCA1654A J AK Main Chassis Ass’y [Tape 2]
42 92LMCPFSPR719A J AB Spring,Cassette
45 92LM-PRA1651A J AE Pinch Roller Ass’y
46 92LM-REL1651B J AB Supply Reel
47 92LM-RPH1746A J AM Head,Record/Playback
50 92LM-TSPR1746A J AA Spring,Pinch Roller
51 92LM-TSPR1651B J AA Spring,Operate Lever
52 92LM-TSPR1651C J AA Spring,Record Lever
53 92LM-TSPR1651D J AA Spring,Idler Lever
55 92LM-TSPR1651F J AA Spring,AS Killer Lever
56 92LMTURA1651A1 J AF Take-up Reel Ass’y
58 92LM-TSPR1651G J AA Spring,Pause Stop Lever
64 92L1R5WC3R8R5P J AA Washer,ø1.5×ø3.8×0.5mm
66 92L1R8WC3R4R5P J AA Washer,ø1.8×ø3.4×0.5mm
67 92L2R3W6R5P J AA Washer,ø2.3×ø6×0.5mm
69 92L1R2WC4-R5P J AA Washer,ø1.2×ø4×0.5mm
70 92L3R6W6-R5P J AA Washer,ø3.6×ø6×0.5mm
71 92LS2R7W6R4R5L J AA Washer,ø2.7×ø6.4×0.5mm
72 92LM-MCA1858A J AH Main Chassis Ass’y [Tape 1]
501 92LS2R6S1746A J AA Motor Screw,ø2.6mm
504 92L2BTS+5BZ J AA Screw,ø2×5mm
505 92L2BTS+7BZ J AA Screw,ø2×7mm
506 92L2TTS+3BZ J AA Screw,ø2×3mm
508 92L2TTS+4BZ J AA Screw,ø2×4mm
509 92L2TTS+4PZ J AA Screw,ø2×4mm
510 92LS2S1658C J AA Screw,ø2×9mm
511 92L2BTS+5PZ J AA Screw,ø2×5mm
M601 92LMTR1746AASY J AP Motor with Pulley [Tape]
SW601 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 1 Main]
SW602 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 2 Main]
SW603 92LM-SW1658A J AB Switch,Leaf Type
[Tape 2 Selector]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 PCUSG0427AFSC J AC Cushion
306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 92L2R6S+6CZ J AB Screw,ø2.6×6mm
702 92L2TTS+5BB J AB Screw,ø2×5mm
703 92L2S+3PZ J AA Screw,ø2×3mm
704 92L1R5WC3R8R25 J AA Washer,ø1.5×ø3.8×0.25mm
M701 92LMTR1858CASY J AS Motor with Chassis [Spin]
M702 92LMTR1854BASY J AP Motor with Gear [Slide]
SW4 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CHANGER MECHANISM
101 LCHSM0026AWZZ J AW Main Base
102 PGIDM0013AWZZ J AQ Stabilizer Guide
103 NPLYR0003AWZZ J AC Pulley,Transmisson
104 NGERH0045AWZZ J AD Gear,Idler
105 NGERH0046AWZZ J AE Gear,Tray Drive
106 NGERH0047AWZZ J AC Gear,Drive
107 MLEVP0044AWZZ J AG Lever,Mecha Move
108 GCOVA1067AWZZ J AM Disc Tray 1
109 GCOVA1068AWZZ J AM Disc Tray 2
110 PGIDM0014AWZZ J AL Holder,CD Mechanism
111 MLEVP0045AWZZ J AC Lever,Switch [Disc 1]
112 MLEVP0046AWZZ J AC Lever,Switch [Disc 2]
113 MLEVP0047AWZZ J AC Lever,Detection Switch
114 MSPRD0064AWFJ J AB Spring,Switch Lever
115 NBLTK0016AWZZ J AD Belt
116 LHLDZ1096AWZZ J AG Holder,CD Servo PWB
117 LHLDM1004AWZZ J AG Stabilizer
118 PMAGF0001AWZZ J AF Magnet
121 PCOVZ1005AWZZ J AE Cover
122 LHLDZ1107AWZZ J AF Holder,Disc 2
123 LHLDZ1106AWZZ J AF Holder,Disc 1
124 92LN-BAND1318A J AA Nylon Band,80mm
401 XEBSD26P20000 J AA Screw,ø2.6×20mm
402 LX-EZ0005AWFD J AA Screw,ø2.6×10mm
403 XBPSD26P05000 J AA Screw,ø2.6×5mm
404 XEBSD26P10000 J AA Screw,ø2.6×10mm
405 XEBSD30P10000 J AA Screw,ø3×10mm
406 XEBSD26P08000 J AA Screw,ø2.6×8mm
M981 92LMTR2282DASY J AP Motor Ass’y [Loading]
SW981 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Tray/Mechanism Up]
SW982 92LSWICHL1749A J AD Switch,Leaf Type [Tray 1]
SW983 92LSWICHL1749A J AD Switch,Leaf Type [Tray 2]
CABINET PARTS
201 92LCAB2331AS1 J AZ Front Cabinet Ass’y [X]
201 92LCAB2332AS1 J Front Cabinet Ass’y [Z]
201- 1 ———— — Front Cabinet
(Not Replacement Item)
201- 2 HPNLH1068AWSA J AG Panel,LCD
203 GCABB1148AWSA J AX Rear Cabinet [X]
203 GCABB1149AWSA J Rear Cabinet [Z]
204 92LBSPR1401A J AC Spring,Battery,+/-
205 GFTAB1001AWSA J AE Battery,Lid
206 JHNDP1012AWSA J AN Handle
207 LANGF0018AWFW J AH Bracket,Handle,Right
208 LANGF0019AWFW J AH Bracket,Handle,Left
209 LHLDL1002AWZZ J AB Stoper,Handle
210 QANTR0006AWZZ J AQ Rod Antenna
211 QTANZ9001AWFW J AE Terminal,Rod Antenna
213 92LMEC2331CTS1 J AK Cassette Holder Ass’y,Tape 1
213- 1 ———— — Cassette Holder,Tape 1
(Not Replacement Item)
213- 2 HPNLH1063AWSA J AE Panel,Cassette,Tape 1
214 92LMEC2331CTS2 J AK Cassette Holder Ass’y,Tape 2
214- 1 ———— — Cassette Holder,Tape 2
(Not Replacement Item)
214- 2 HPNLH1064AWSA J AE Panel,Cassette,Tape 2
215 92LCSPR1596A J AA Spring,Cassette Up
216 92LCUSN1585A J AA Cushion,Leg
217 92LPNL2331AS1 J AK Decoration Panel Ass’y [X]
217 92LPNL2332AS1 J Decoration Panel Ass’y [Z]
217- 1 ———— — Decoration Panel
(Not Replacement Item)
217- 2 HPNLD1004AWSA J AD Panel,Dial
219 JKNBZ0190AWSA1 J AD Button,Record [Tape 1]
220 JKNBZ0191AWSA1 J AD Button,Play [Tape 1]
221 JKNBZ0192AWSA1 J AD Button,Rewind [Tape 1]
222 JKNBZ0193AWSA1 J AD Button,FF [Tape 1]
223 JKNBZ0194AWSA1 J AD Button,Stop [Tape 1]
224 JKNBZ0195AWSA1 J AE Button,Play [Tape 2]
– 5 –
!
