GX-CH170X/CH170Z
225 JKNBZ0196AWSA1 J AE Button,Stop [Tape 2]
226 JKNBZ0206AWSA J AG Knob,Volume
227 JKNBZ0207AWSA J AF Knob,CD Control
228 LANGK0041AWZZ1 J AF Bracket,Cassette Button
229 92LDAMPER1651A J AD Damper
230 92LFELT666B J AA Felt
231 JKNBP0006AWSA J AC Knob,Function
232 JKNBZ0208AWSB J AE Knob,CD Eject,Tray 1
233 JKNBZ0209AWSB J AE Knob,CD Eject,Tray 2
234 LHLDF1009AWZZ J AB Holder,PWB
235 HSSND0009AWSA J AE Dial Pointer
236 JKNBZ0210AWSA J AE Knob,Tuning
237 LHLDZ1092AWZZ J AH Holder,Gear
238 LHLDZ1095AWZZ J AL Tuner Frame [X]
238 LHLDZ1122AWZZ J AF Tuner Frame [Z]
240 92LWHEL1569A J AE Dial Wheel
241 GCOVA1076AWSA J AH Cover,Tray 1
242 GCOVA1077AWSA J AH Cover,Tray 2
247 PRDAR0055AWZZ J Heat Sink
248 TSPC-0380AWZZ J Label,Specifications [X]
248 TSPC-0381AWZZ J Label,Specifications [Z]
250 92LM-LEV1746A J AB Lever,Record Spring
251 LHLDZ1097AWZZ J AC Holder,LCD
252 LHLDZ1098AWZZ J AC Holder,LED [Power]
253 LHLDZ1099AWZZ J AC Holder,LED [CD]
254 92LFSHOLD1652T J AB Holder,Fuse
255 92LBSPR1595C J AB Spring,Battery,-
256 NGERH0050AWZZ J AE Gear,Dial
259 TLABH0041AWSB J AE Label,Cassette,Tape 1
260 TLABH0042AWSB J AE Label,Cassette,Tape 2
262 PCOVS3017AWZZ J AE Shield,G.EQ.PWB
263 92LCOV1346A-BK J AB Cover,Voltage Selector [Z Only]
264 JKNBZ0233AWSA J Knob,Fine Tuning [Z Only]
265 92LN-BAND1318A J AA Nylon Band,80mm
267 JKNBZ0267AWSA J AC Knob,Band [Z Only]
268 MLEVP0051AWZZ J AC Lever,Band [Z Only]
269 92LPANEL713A J AB Label,Made in Malaysia [Z Only]
270 92LLABL1420A1 J AC Label,Class 1 [Z Only]
271 LHLDZ1120AWZZ J Holder,LED [FM ST] [Z Only]
601 LX-CZ0011AFFD J AA Screw,ø3×65mm
602 XEBSD30P10000 J AA Screw,ø3×10mm
603 XEBSD30P20000 J AA Screw,ø3×20mm
604 XHSSF30P06000 J AA Screw,ø3×6mm
605 XJSSF30P10000 9 AA Screw,ø3×10mm
606 XJSSD30P10000 J AA Screw,ø3×10mm
607 XWSSJ30-07000 J AA Washer,ø3×ø10×0.7mm
608 XEBSD30P08000 J AA Screw,ø3×8mm
609 XBPSD26P06J00 J AA Screw,ø2.6×6mm
611 XCBSD30P08000 J AA Screw,ø3×8mm
612 XHBSD20P04000 J AA Screw,ø2×4mm
614 LX-WZ9028AWZZ J AA Washer,Fiber Type
618 XWHSD32-08150 J AB Washer,ø3.2×ø13×0.8mm
620 LX-BZ0286AFFF J AA Special Screw [Z Only]
621 XNESN20-16000 J AA Nut,ø2×1.6mm [Z Only]
622 XJSSD30P08000 J AA Screw,ø3×8mm [Z Only]
SPEAKER BOX PARTS
701 92LSCAB2331AS1 J AX Front Panel Ass’y,Left
701- 1 HBDGB1004AWSA J AE Label,SHARP
702 92LSCAB2331AS2 J AX Front Panel Ass’y,Right
702- 1 HBDGB1004AWSA J AE Label,SHARP
703 QCNWN0597AWZZ J AE Speaker Cord
704 GCABB1138AWSA J AV Rear Cabinet,Left
705 GCABB1139AWSA J AV Rear Cabinet,Right
706 XEBSD30P10000 J AA Screw,ø3×10mm
707 XEBSD30P20000 J AA Screw,ø3×20mm
708 PSPAS0006AWZZ J AB Spacer,Boss
SP601,602 VSP0010PBS3SA J AT Woofer
SP603,604 RALMB0101AFZZ J AB Tweeter
ACCESSORIES/PACKING PARTS
QACCB0004AW00 J BB AC Power Supply Cord
[Z for Hong Kong]
QACCE0007AW00 J AR AC Power Supply Cord
[Z Except for Hong Kong and
Saudi Arabia]
QACCL0002AW00 J AC Power Supply Cord
[X for Australia]
SPAKA0102AWZZ J AN Packing Add.,Unit (Left/Right)
SPAKA0106AWZZ J AU Packing Add.,Speaker,Top/
Bottom
SPAKC0399AWZZ J AT Packing Case [X]
SPAKC0400AWZZ J Packing Case [Z]
SPAKP0001AWZZ1 J AC Polyethylene Bag,Unit
TINSK0048AWZZ J AD Operation Manual [X]
TINSZ0159AWZZ J Operation Manual [Z]
TLABZ0301AWZZ J Feature Label,Speaker
92LBAG002B J AA Polyethylene Bag,Accessories
[Z Only]
92LBAG1607A1 J AB Polyethylene Bag,Speaker
92LBAG1770A J AB Polyethylene Bag,AC Power
Supply Cord [X for Australia]
92LBAG760C J AA Polyethylene Bag,AC Plug
Adaptor [Z Only]
92LCORD577B J AM AC Power Supply Cord
[Z for Saudi Arabia]
92LGCARD1226E1 J Warranty Card
[X for Australia Only]
92LPLUG027 J AD AC Plug Adaptor
[Z for Saudi Arabia]
92LPLUG155A J AG AC Plug Adaptor
[Z Except for Saudi Arabia]
RRMCG0063AWSA J BB Remote Control
GFTAB1016AWSA J Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~9 92LPWB2331MANS J — Main/Power/Microcomputer/
Diplay/Terminal/Graphic
Equalizer/Switch/Switch/Fine
Tuning (Combined Ass'y)
[X Only]
PWB-B 92LPWB2325TUNS J — Tuner [X Only]
PWB-C 92LPWB2331DEKS J — Deck [X Only]
PWB-D 92LPWB2325CDUS J — CD Servo [X Only]
PWB-E QPWBF0027AWZZ J AD CD Motor (PWB Only) [X Only]
