Sharp GX-M10 Service Manual

GX-M10
6 – 3
55
TIMER_LED
OUTPUT
CMOS INPUT /
OUTPUT
OFF
TIMER LED CONTROL
H : ON , L : OFF
P6_2
56
AC_RELAY
OUTPUT
CMOS INPUT /
OUTPUT
OFF
MAIN TRANS ON/OFF CONTROL
H : POWER ON/DEMO ,
L : POWER OFF/ECO/DC MODE
P6_1
57
LEVEL_DET Input
(Analog/
Digital)
CMOS INPUT /
OUTPUT
OFF ANALOG AUDIO LEVEL INPUT A/D DETECTION
P0_5/AN2/CLK1
58
AREA Input
(Analog/
Digital)
CMOS INPUT /
OUTPUT
OFF DESTINATION SETTING A/D INPUT NEED
P0_6/AN1/DA0
59
VSS
-- -GROUND
VSS/AVSS
60
SYS_PROTECT Input
(Analog/
Digital)
CMOS INPUT /
OUTPUT
OFF SUPPLY ABNORMAL A/D DETECTION NEED
P0_7/AN0/DA1
61
VREF
- - - A/D CONVERTER REFERENCE VOLTAGE SUPPLY
VREF
62
VCC
- - - 3.3V SUPPLY
VCC/AVCC
63
HP_MUTE
OUTPUT
CMOS INPUT /
OUTPUT
OFF
HEADPHONE MUTE CONTROL
H : ON , L : OFF
P3_7/SSO
64
TUN_SCL/DAP_SCL
OUTPUT
CMOS INPUT /
OUTPUT
OFF TUNER/DAP CLOCK I2C BUS LINE
P3_5/SCL/SSCK
Note1. P4_7/XOUT is INPUT port.
Note2. ( ) port can be allocated by program.
Pin
No.
NAME
INPUT/
OUTPUT
TYPE
SOFT
PULL-UP
DESCRIPTION
HARDWARE
PULL-UP
PORT_TYPE
IC600 CH-IXA369AWA5 : Micro Computer IXA369AW00 ( 3/4 )
