Figure 8-11: WIRING SIDE OF DISPLAY, KEY, USB, TIME, TRANSIT SUBWOOFER FLASH (R/L-CH), BATTERY TERMINAL 1/2 & AC INLET PWB (BOTTOM VIEW)
DISPLAY PWB-C1
KEY PWB-C2
SUBWOOFER FLASH (R-CH) PWB-C6
SUBWOOFER FLASH (L-CH) PWB-C7
Lead-free solder indication
Lead-free solder is used in the DISPLAY, KEY, USB, TIME, TRANSIT SUBWOOFER FLASH (R/L-CH),
BATTERY TERMINAL 1/2 & AC INLET PWB.
Refer to "Precautions for handling lead-free solder" for instructions and precautions.
7
8
9101112
A
B
C
D
E
F
G
H
1
2
3
456
USB PWB-C3
TRANSIT PWB-C5
TIME PWB-C4
To Next Page
