Sharp GX-M10 Service Manual

GX-M10
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
[8] OTHER CIRCUITRY PARTS
Bi2 QCNWNB894AWPZ AH Connector Ass'y, 8 / 7 Pin [with CNS2] [Use in MAIN PWB-A1]
Bi4 QCNWNB978AWPZ AK Connector Ass'y, 5 / 4 Pin [with CNS4] [Use in MAIN PWB-A1]
Bi250 QCNWNB959AWPZ AH Connector Ass'y, 8 / 7 Pin [with CNS250] [Use in TRANSIT PWB-C4]
Bi701AB QCNWNB899AWPZ AF Connector Ass'y, 5/4_5/4 Pin [Use in DISPLAY PWB-C1]
Bi702 QCNWNB893AWPZ AE Connector Ass'y, 2 Pin [with CNS701] [Use in DOOR SWITCH PWB-A3]
Bi704 QCNWNB898AWPZ AE
Connector Ass'y, 2 Pin [with CNS704] [Use in SUBWOOFER FLASH (L-CH) PWB-C5]
Bi705 QCNWNB898AWPZ AE Connector Ass'y, 2 Pin [with CNS705] [Use in SUBWOOFER FLASH (R-CH) PWB-C6]
Bi801 QCNWNB895AWPZ AG Connector Ass'y, 3 Pin [with CNS801] [Use in BATTERY TERMINAL 1 PWB-C7]
Bi901 QCNWNB892AWPZ AG Connector Ass'y, 8 / 7 Pin [with CNS901] [Use in MAIN PWB-A1]
Bi903 QCNWNC060AWPZ AK Connector Ass'y, 2 Pin [with CNS903] [Use in AC INLET PWB-C9]
Bi904 QCNWNB891AWPZ AE Connector Ass'y, 2 Pin [with CNS904] [Use in AC INLET PWB-C9]
CNP1 QCNCWYG16AWZZ AD Connector, 16 Pin [Use in MAIN PWB-A1]
CNP2 QCNCM201FAWZZ AB Connector, 6 Pin [Use in MAIN PWB-A1]
CNP3 92LCONE6P53253 AC Connector, 6 Pin [Use in MAIN PWB-A1]
CNP200 QCNCWA046AW30 AQ Connector, 30 Pin [Use in iPod PWB-A2]
CNP201 QCNCM202GAWZZ AC Connector, 7 Pin [Use in iPod PWB-A2]
CNP250 QCNCM202GAWZZ AC Connector, 7 Pin [Use in TRANSIT PWB-C4]
CNP600 QCNCWYH04AWZZ AB Connector, 4 Pin [Use in MAIN PWB-A1]
CNP701 QCNCWYH15AWZZ AD Connector, 15 Pin [Use in DISPLAY PWB-C1]
CNP702 QCNCM201BAWZZ AB Connector, 2 Pin [Use in MAIN PWB-A1]
CNP702A QCNCWYH07AWZZ AC Connector, 7 Pin [Use in DISPLAY PWB-C1]
CNP702B QCNCWYH07AWZZ AC Connector, 7 Pin [Use in KEY PWB-C2]
CNP781 QCNCM202EAWZZ AB Connector, 4 Pin [Use in USB PWB-C3]
CNP801 QCNCM203CAWZZ AB Connector, 3 Pin [Use in MAIN PWB-A1]
CNP802 QCNCM203BAWZZ AB Connector, 2 Pin [Use in MAIN PWB-A1]
CNP901 QCNCM203FAWZZ AB Connector, 6 Pin [Use in MAIN PWB-A1]
CNP902 QCNCM203GAWZZ AC Connector, 7 Pin [Use in MAIN PWB-A1]
CNS2AB QCNWNB887AWPZ AF Connector Wire, 6 Pin [Connect CNP2 and CD MOTOR]
CNS301_
LUG
QCNWNB922AWPZ AE Connector Ass'y, 2 Pin [with CNS301, LUG903 and Lug Terminal]
CNS701 QCNCWYG15AWZZ AD Connector, 15 Pin [Use in MAIN PWB-A1]
CNS901AB QCNWNC062AWPZ AM
Connector Ass'y, 6 Pin [with CNS901A, CNS901B and Speaker Terminal]
[ Connect CNP901 and SUBWOOFER FLASH (R-CH) PWB-C6 ]
CNS902AB QCNWNC061AWPZ AM
Connector Ass'y, 7 / 6 Pin [with CNS902A, CBNS902B and Speaker Terminal]
[ Connect CNP902 and SUBWOOFER FLASH (L-CH) PWB-C5 ]
F801 QFS-LA097WJPZ AE Chip Fuse 5A, 30V
FFC1 QCNWNB424AWPZ AE Flat cable, 16 Pin [Connect CNP1 and CD PICK UP]
FFC701 QCNWNB889AWPZ AE Flat cable, 15 Pin [Connect CNP701 and CNS701]
FFC702 QCNWNB924AWPZ AC Flat cable, 7 Pin [Connect CNP702A and CNP702B]
GUT431 QJAKJA004AWZZ AF Jack, Guitar
JK550 QJAKMA029AWZZ AE Jack, Headphone
JK570 QJAKMA029AWZZ AE Jack, Audio In
JK571 QSOCJ0120AWZZ AD Jack, Video
JK781 QSOCZA030AWZZ AF Jack, USB
JK801 QJAKCA011AWZZ AH Jack, DC
LCD701 RV-LXA009AWZZ AQ LCD Display
LUG200 QCNWNB979AWPZ AD Lug Wire
LUG602 QLUGP0002AWZZ AB Lug
LUG603 QLUGP0002AWZZ AB Lug
LUG701 QCNWNB980AWPZ AD Lug Wire
LUG782 QCNWNA981AWPZ AD Single Wire, White
LUG801 QLUGPA003AWZZ AB Lug Terminal
LUG901 QLUGPA003AWZZ AB Lug Terminal
LUG902 QLUGPA003AWZZ AB Lug Terminal
LUG903 QLUGP0002AWZZ AB Lug
MiC401 QJAKJA004AWZZ AF Jack, Mic
RX701 VHLK2013TH2E1 AG Remote Sensor
! SO901 QSOCAA008AWZZ AL AC Inlet with Switch
SW700 92LSWiCHT1663T AC
Switch, Key Type
S
W701 92LSWiCHT1663T AC Switch, Key Type
SW702 92LSWiCHT1663T AC Switch, Key Type
SW703 92LSWiCHT1663T AC Switch, Key Type
SW704 92LSWiCHT1663T AC Switch, Key Type
SW705 92LSWiCHT1663T AC Switch, Key Type
SW706 92LSWiCHT1663T AC Switch, Key Type
SW707 92LSWiCHT1663T AC Switch, Key Type
SW708 92LSWiCHT1663T AC Switch, Key Type
SW709 92LSWiCHT1663T AC Switch, Key Type
SW710 92LSWiCHT1663T AC Switch, Key Type
SW711 QSW-PA009AWZZ AE Switch, Push Type
TUN301 RTUNSA047AWZZ AW Tuner Pack
VR401 RVR-QA002AWZZ AF Switch, Jog Type (Mic Volume)
VR431 RVR-QA002AWZZ AF Switch, Jog Type (Guitar Volume)
Wire A-A' QCNWNB710AWPZ AD Single Wire, 130mm
Wire B-B' QCNWNB335AWPZ AB Single Wire, Black
Wire C-C' QCNWNB335AWPZ AB Single Wire, Black
Wire D-D' QCNWNB335AWPZ AB Single Wire, Black
Wire F QCNWNB976AWPZ AE Lug Wire, 160mm [Connect LUG902 and Ground at Chassis]
