NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PART CODE
PRICE
RANK
DESCRIPTION
HT-CN300
210 GCOVA1015BGSB J AF Cover,Back,Right
[HT-CN300 (BK)]
211 NFANP0001AWZZ J AD Rotary Fan
212 92LCSPR1431C J AA Spring,Ring
213 GBOXS6001BGSA J BD Subwoofer Box [HT-CN300 (S)]
213 GBOXS6001BGSB J BD Subwoofer Box [HT-CN300 (BK)]
214 92L430-SX-2136 J Cushion
215 LCHSM0003BGFW J AS Chassis,Main
216 LANGK0006BGFW J AF Bracket,Fan Stand
217 PRDAR0010BGFW J AX Heat Sink,Sub
218 PRDAR0011BGFW J AR Heat Sink,Main
219 GITAR0021BGSA J AM Rear Panel [HT-CN300 (S)]
[Except for Canada]
219 GITAR0022BGSA J AM Rear Panel [HT-CN300 (BK)]
[Except for Canada]
219 GITAR0023BGSA J Rear Panel [HT-CN300 (S)]
[For Canada]
219 GITAR0025BGSA J Rear Panel [HT-CN300 (BK)]
[For Canada]
220 LANGK0007BGFW J AN Bracket,PWB
221 LANGF0002BGFW J AG Bracket,Chassis
222 TLABZ0045BGSA J AE Label,Speaker A
223 TLABZ0046BGSA J AE Label,Speaker B
224 PCUSG0001BGZZ J AB Cushion,Leg
225 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
226 PSHEG0001BGZZ J AF Sheet,Thermal
227 PSPAN0001BGZZ J AB Spacer,Thermal
229 PSLDM3004BGFW J AF Shield,Plate
1 230 QFSHD1017CEZZ J Fuse Holder
1 231 QFSHD1018CEZZ J Fuse Holder
232 LHLDW1033CE00 J AA Nylon Band
1 233 QACCD0030AWZZ J AC Power Supply Cord
234(SP1) RSPA10001BG6W J Speaker
601 LX-EZ0001BGFF J AC Screw,Hexagon [HT-CN300
(BK)]
601 LX-EZ0001BGFN J AC Screw,Hexagon [HT-CN300 (S)]
602 LX-HZ0169AFFD J AA Screw,ø4×10mm
603 LX-LZ0008AWZZ J AC Push Rivet
604 XBBSD20P04000 J AA Screw,ø2×4mm
605 XBBSD30P08000 J AA Screw,ø3×8mm
606 XJBSD30P06000 J AA Screw,ø3×6mm
607 LX-JZ0010AFFD J Screw,ø3×10mm
608 XJBSD40P20000 J AA Screw,ø4×20mm
609 XJBSF30P08000 J AA Screw,ø3×8mm
610 XJBSF40P20000 J AB Screw,ø4×20mm
611 XTBSD40P12000 J AA Screw,ø4×12mm
612 XTBSD40P16000 J AA Screw,ø4×16mm
613 XJBSD30P08000 J AA Screw,ø3×8mm
614 XJBSD40P25000 J Screw,ø4×25mm
SPEAKER (Subwoofer)
SP1(234) RSPA10001BG6W Speaker
PACKING PARTS (Except for U.S.A.)
SPAKA0006BGZZ J AR Packing Add.
SPAKC0054BGZZ J AX Packing Case
[Except for Canada]
[HT-CN300 (S)]
SPAKC0055BGZZ J AX Packing Case
[Except for Canada]
[HT-CN300 (BK)]
SPAKC0061BGZZ J Packing Case [For Canada]
[HT-CN300 (S)]
SPAKC0062BGZZ J Packing Case [For Canada]
[HT-CN300 (BK)]
SSAKA0002BGZZ J AB Polyethylene Bag,Accessories
SSAKH0007BGZZ J AD Polyethylene Bag,Sensor
SSAKH0008BGZZ J AF Polyethylene Bag,Unit
ACCESSORIES
TCAUZ0006BGZZ J AD Sheet,Caution
TINSE0012BGZZ J AD Quick Guide [For U.S.A. Only]
TINSE0013BGZZ J AF Operation Manual
[Except for Canada]
TINSE0019BGZZ J Operation Manual [For Canada]
TLABR1259BGZZ J AD Label,Bar Code
[HT-CN300 (BK)]
TLABR1260BGZZ J AD Label,Bar Code [HT-CN300 (S)]
CNP203 QCNCM698HAFZZ J AC Plug,8Pin
CNP205 QCNCM705BAFZZ J AA Plug,2Pin
CNP301 QCNCM603CAFZZ J AB Plug,3Pin
CNP302 QCNCM698CAFZZ J AB Plug,3Pin
CNP430 QCNCWZY11BGZZ J AD Socket,11Pin
CNP431 QCNCM035FAWZZ J AC Plug,6Pin
CNP510 QCNCM036BAWZZ J AC Plug,2Pin
CNP550 QCNCWZX17BGZZ J AE Socket,17Pin
CNP601 QCNCWZX14BGZZ J AD Socket,14Pin
CNP640 QCNCWZX29BGZZ J AF Socket,29Pin
CNP670 QCNCWZX10BGZZ J AD Socket,10Pin
CNP701 QCNCWZX29BGZZ J AF Socket,29Pin
CNP702 QCNCM604DAFZZ J AB Plug,4Pin
CNP704 QCNCWZX11BGZZ J AD Socket,11Pin
CNP708 QCNCWZX14BGZZ J AD Socket,14Pin
CNP710 QCNCWZX17BGZZ J AE Socket,17Pin
CNP711 QCNCWZX19BGZZ J AE Socket,19Pin
CNP712 QCNCWZX08BGZZ J AD Socket,8Pin
CNP713 QCNCM698MAFZZ J AF Plug,12Pin
CNS205 QCNWN0071BGZZ J Connector Ass’y,2Pin
CON201 QCNCM454BAFZZ J AE Plug,2Pin
CON210 QCNCL057MAWZZ J AG Plug,11Pin
CON211 QCNCL778MAFZZ J AF Socket,11Pin
CON301 QCNCWZY08BGZZ J AD Socket,8Pin
CON703 QCNCWZX10BGZZ J AD Socket,10Pin
CON707 QSOCJ0103BGZZ J AD Jack,DVD DIGITAL IN DIG2
1 F101,102 QFS-D802BSJNI J AC Fuse,8A/125V
1 F111,112 QFS-D132BSJNI J AD Fuse,1.25A/125V
1 F121 QFS-D801BSJNI J AG Fuse,800mA,125V
1 F511 QFS-D402BSJNI J AB Fuse,4A/125V
FE301 RTUNS0001SJZZ J AQ FM Front End
FL690 VVKHNA9SS32-1 J AX FL Display
FW6 QCNWN0072BGZZ J Flat Cable,25Pin
FW7 QCNWN0079BGZZ J Flat Cable,10Pin
FW8 QCNWN0074BGZZ J Flat Cable,14Pin
FW9 QCNWN0080BGZZ J Flat Cable,8Pin
FW10 QCNWN0075BGZZ J Flat Cable,17Pin
FW11 QCNWN0073BGZZ J Flat Cable,11Pin
FW12 QCNWN0076BGZZ J Flat Cable,19Pin
J201 QTANZ0001BGZZ J AK Terminal,Speaker
J401 QSOCJ0301BGZZ J AF Jack,Video In/Out
J420 QSOCZ0001BGZZ J AF Jack,TV Monitor Out
J430 QSOCZ0001BGZZ J AF Jack,DVD In
J550 QSOCJ0801BGZZ J AH Jack,Audio In/Out
M200 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
RY210 RRLYD0014AWZZ J AK Relay
RY230 RRLYD0014AWZZ J AK Relay
RY250 RRLYD0014AWZZ J AK Relay
RY511 RRLYD0011AWZZ J AE Relay
SW678 QSW-K0008AWZZ J AC Switch,Key Type [Power]
REMOTE SENSOR PARTS
CCABA1012BGM1 J Remote Sensor Unit
[HT-CN300 (S)]
CCABA1012BGM2 J Remote Sensor Unit
[HT-CN300 (BK)]
CABINET PARTS
201 GCAB-1002BGSA J AV Top Cover A [HT-CN300 (S)]
201 GCAB-1002BGSB J AV Top Cover A [HT-CN300 (BK)]
202 HDECQ0038BGSA J AM Panel,Display [HT-CN300 (S)]
202 HDECQ0038BGSB J AM Panel,Display [HT-CN300 (BK)]
203 JKNBZ0014BGSA J AF Button,Power [HT-CN300 (S)]
203 JKNBZ0014BGSB J AF Button,Power [HT-CN300 (BK)]
204 HBDGA1004BGSA J AD Badge,SHARP
205 GDAI-1001BGSA J AQ Stand,Subwoofer
[HT-CN300 (S)]
205 GDAI-1001BGSB J AQ Stand,Subwoofer
[HT-CN300 (BK)]
206 LHLDW1002BGSA J AE Holder,FL Display
207 GCOVA1013BGSA J AC Cover,LED
208 GCAB-1006BGSA J AL Top Cover B [HT-CN300 (S)]
208 GCAB-1006BGSB J AL Top Cover B [HT-CN300 (BK)]
209 GCOVA1014BGSA J AG Cover,Back,Left [HT-CN300 (S)]
209 GCOVA1014BGSB J AG Cover,Back,Left
[HT-CN300 (BK)]
210 GCOVA1015BGSA J AG Cover,Back,Right
[HT-CN300 (S)]
– 6 –
