Sharp HT-SB60 Service Manual

HT-SB60
6 – 6
IC1 VHiEP92A2E : HDMI IC (EP92A2E) (1/4)
Name In/Out Description
RXC0- IN Di erential Clock Input Pair for HDMI Input Port 0
RXC0+ IN Di
erential Clock Input Pair for HDMI Input Port 0
RX00- IN Di
erential Data Input Pair0 for HDMI Input Port 0
RX00+ IN Di
erential Data Input Pair0 for HDMI Input Port 0
RX10- IN Di
erential Data
Input Pair1 for HDMI Input Port 0
RX10+ IN Di
erential Data Input Pair1 for HDMI Input Port 0
RX20- IN Di
erential Data Input Pair2 for HDMI Input Port 0
RX20+ IN Di
erential Data Input Pair2 for HDMI Input Port 0
RXC1- IN Di
erential Clock Input Pair for HDMI Input Port 1
RXC1+ IN Di
erential Clock Input Pair for HDMI Input Port 1
RX01- IN Di
erential Data Input Pair0 for HDMI Input Port 1
RX01+ IN Di
erential Data Input Pair0 f
or HDMI Input Port 1
RX11- IN Di
erential Data Input Pair1 for HDMI Input Port 1
RX11+ IN Di
erential Data Input Pair1 for HDMI Input Port 1
RX21- IN Di
erential Data Input Pair2 for HDMI Input Port 1
RX21+ IN Di
erential Data Input Pair2 for HDMI Input Port 1
RXC2- IN Di
erential Clock Input Pair for HDMI Input Port 2
RXC2+ IN Di
erential Clock Input Pair for HDMI Input Port 2
RX02- IN Di
erential Data Input Pair0 for HDMI Input Por
t 2
RX02+ IN Di
erential Data Input Pair0 for HDMI Input Port 2
RX12- IN Di
erential Data Input Pair1 for HDMI Input Port 2
RX12+ IN Di
erential Data Input Pair1 for HDMI Input Port 2
RX22- IN Di
erential Data Input Pair2 for HDMI Input Port 2
RX22+ IN Di
erential Data Input Pair2 for HDMI Input Port 2
EXT_RES IN
HDMI Input Ports
Unless otherwise stated, unused input pins must be tied to ground, and unused output pins left open.
should tie this pin to AVDD33. 470Ω is recommended.
External Termination Resistor for all HDMI Input Ports. A resistor
Name In/Out Description
TXC- OUT Di erential Clock Output Pair for HDMI Output
TXC+ OUT Di
erential Clock Output Pair for HDMI Output
TX0- OUT Di
erential Data Output Pair0 for HDMI Output
TX0+ OUT Di
erential Data Output Pair0 for HDMI Output
TX1- OUT Di
erential Data Output Pair1 for HDMI Output
TX1+ OUT Di
erential Data Output Pair1 for HDMI Output
TX2- OUT Di
erential Data Output Pair2 for HDMI Output
TX2+ OUT Di
er
ential Data Output Pair2 for HDMI Output
SWING Analog
Voltage Swing Adjust for HDMI Output. A resistor should tie this
pin to PVDD18. This resistance determines the amplitude of the
voltage swing. 390Ω is recommended.
COMR Analog Common ground for pull-down resistors of HDMI Data Output
Name In/Out Description
ARC+/- IN/OUT AC coupled ARC input pins
HDMI Output Ports
ARC RX Pins

Sharp HT-SB60 Specifications

General

Audio decoders	Dolby Digital, DTS
RMS rated power	310 W
Audio output channels	2.1 channels
Soundbar speaker RMS power	160 W
Subwoofer included	Yes
Subwoofer connectivity	Wireless
Receiver included	No
Product color	Black
Apple docking compatibility	Not supported
HDMI ports quantity	3
USB 2.0 ports quantity	0
Connectivity technology	Wired & Wireless
Digital audio optical in	1
