Sharp HT-SB60 Service Manual

HT-SB60
1 – 5
1. Remote Control Transmitter
2. TV ARC Button
3. Music (Sound Mode) Button
4. Cinema (Sound Mode) Button
5. Sport (Sound Mode) Button
6. BYPASS Button
7. 3D AUDIO Button
8. APC Button
9. TV Operation Button
10. AV SYNC Down Button
11. Source Button
12. Subwoofer Level Down Button
13. Bass Button
14. On/Stand-by Button
15. Game (Sound Mode) Button
16. News (Sound Mode) Button
17. Night (Sound Mode) Button
18. Dimmer Button
19. Demo Button
20. MUTE/Speaker Output Selection Button
21. AV SYNC Up Button
22. Volume Up Button
23. Subwoofer Level Up Button
24. Treble Button
25. Volume Down Button
Remote Control
2
3
4
5
7
8
10
12
13
1
9
11
6
15
16
17
18
19
20
21
23
22
24
25
14
AUDIO
Note:
Some models of SHARP TV may not be operable.
TV Operation Buttons (Only SHARP TV):
On/Stand-by
Button
Sets the TV
power to
“ON” or
“STAND-BY”.
Input Select
Button (TV)
Press the
button to
switch the
input source.
Channel Up
and Down
Buttons
Switch up/
down the TV
channels.
Volume Up
and Down
Buttons
Turn up/
down the TV
volume.
1 – 3

Sharp HT-SB60 Specifications

General

Audio decoders	Dolby Digital, DTS
RMS rated power	310 W
Audio output channels	2.1 channels
Soundbar speaker RMS power	160 W
Subwoofer included	Yes
Subwoofer connectivity	Wireless
Receiver included	No
Product color	Black
Apple docking compatibility	Not supported
HDMI ports quantity	3
USB 2.0 ports quantity	0
Connectivity technology	Wired & Wireless
Digital audio optical in	1
