Sharp IMAGER AR-5316 User Manual

Quick Reference Guide: AR-5316
Pre-Setup: Tools, Documentation, & Admonitions
Toolbox Basics
Mechanical
• Screwdriver, Phillips #2
• Screwdriver, Flat #1
• Wrench, 1.5mm Hex head
• Feeler gauges
Electrical
• Voltmeter
• ESD wrist or ankle strap
• Approved surge suppressor
• 30x lighted viewing device
Miscellaneous
• Clean, soft, lint-free cloths
• Alcohol
Special Tools & Service Documentation
Electrical/Electronic Component
Admonitions
!
WARNING: Electrical hazard.
Employ proper precautions when
working with high-voltage electrical
equipment.
CAUTION: Improper handling of
electronic components can damage
the equipment.
Properly ground and wear an
electro-static device (ESD) on your
wrist or ankle when working with
electronic modules. Similarly, use
anti-static bags to protect electronic
components during storage or
shipping.
E
S
D
Material Safety Data Sheets
(MSDSs)*
* Download MSDSs at http://www.sharp-service.com
Laser Admonition
For your protection, do
not remove protective
covers or bypass safety
interlocks.
* Optional equipment
Product
Code
Description MSDS No.
AR-016TD Toner developer
cartridge (Black)
F-31381
AR-016DR Drum cartridge F-01381
2
Description Part No.
AR-5316, Service Manual SM_AR-5316
Code: 00ZAR5316/A1E
AR-5316, Parts Guide PG_AR-5316
Code: 00ZAR5316/P1E
*AR-RP6 / AR-SP6 Service
Manual
SM_AR-RP6 / AR-SP6
Code: 00ZARSP6//A1E

Sharp IMAGER AR-5316 Specifications

General

Print Technology	Laser
Print Speed	16 ppm
Max Resolution	600 x 600 dpi
Copy Speed	16 cpm
Warm-Up Time	25 seconds
Type	Monochrome
Functions	Print, Copy, Scan
Interface	USB 2.0
Scan Resolution	600 x 600 dpi
Original Size	A3
Scan to	Email, PC
Paper Capacity	350 sheets
