Quick Reference Guide: AR-5316
Basic System Configuration (cont’d)
Internal Views
18 Document feeder tray (when
the SPF is installed)
19 Original guides (when the SPF
is installed)
20 Feeding roller cover (when the
SPF is installed)
21 Right side cover (when the SPF
is installed)
22 Exit area (when the SPF is
installed)
23 TD cartridge
24 TD cartridge strap 25 TD cartridge lock release lever 26 Roller rotating knob
27 Fusing unit release levers 28 Drum cartridge 29 Drum cartridge handle
30 Fusing unit paper guide
