Sharp KC-D40E User Manual

E-4
PART NAMES
FRONT / BACK
1 Air Outlet
(Front)
2 Operation panel
(Ref. E-5)
3 Display
(Ref. E-5)
4 Main Unit
5 Stopper
(2 Locations)
6 Caster
(4 Locations)
1
4
5
6
1 Air Outlet 6 Float
2 Handle
(2 Locations)
7 Humidifying Tray
3 Sensor
(Internal)
•Dust Sensor
•Temperature / Humidity Sensor
•Odour Sensor
(KC-D60E only)
8
Louver
(auto)
9 HEPA Filter
(white)
10 Deodorizing Filter
(black)
11 Back Panel
(Pre-Filter)
12 Air Inlet
4 Water Tank 13 Power Cord / Plug
5 Humidifying Filter
1
2
3
4
5
7
3
2
8
9
10
11
6
13
(Shape of plug depends on country.)
12
KC-D60 40E_EN (MA+CS).indd Sec1:4KC-D60 40E_EN (MA+CS).indd Sec1:4 10/29/13 5:14 PM10/29/13 5:14 PM
