②
③
①
①
②
E-7
ENGLISH
CAUTION
REFILLING THE WATER TANK
•
Check to see that there is no water leaking.
• Be sure to wipe off any excess water on
the outside of the Water Tank.
• When carrying the Water Tank, hold it
with both hands so that the Water Tank
opening is facing up.
When using the Clean Air Humidify Mode, or the Haze Mode.
• Do not expose the unit to water. Short circuit and/or electrical shock may occur as a result.
• Do not use hot water (40 ºC), chemical agents, aromatic substances, dirty water, or other
damaging substances, deformation and/or malfunction may occur.
• Use only fresh tap water. Use of other water sources may promote the growth of mold, fungus and/
or bacteria.
Tighten
CAUTION
Remove the Water Tank by
pushing the handle down and
pulling it forward.
Fill the Water Tank with tap Water.
Install the Water Tank.
1
2
3
Click
Click
MAX
KC-D60 40E_EN (MA+CS).indd Sec1:7KC-D60 40E_EN (MA+CS).indd Sec1:7 10/29/13 5:14 PM10/29/13 5:14 PM
To Next Page
