Sharp LC-19DV200E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
B4312 9JD024HC52213 CORE,BEADS FCM1608KF-221T05
B4322 9JD024HC52213 CORE,BEADS FCM1608KF-221T05
B4326 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B5800 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B5802 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B5803 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B5804 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B7200 9JD024HC51216 CORE,BEADS HCB1608KF-121T20
B9600 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B9601 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B9602 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B9603 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B9604 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
B9605 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
L300 9JD021D0N220M COIL 22 UH
L301 9JD021D0N220M COIL 22 UH
L3000 9JD021UMK100P COIL 10 UH
L3001 9JD021UMK100P COIL 10 UH
L3003 9JD021UMK100P COIL 10 UH
L3600 9JD02D1000119 COIL CHOKE EXC28CG900U
L3601 9JD02D1000119 COIL CHOKE EXC28CG900U
L3602 9JD02D1000119 COIL CHOKE EXC28CG900U
L3603 9JD02D1000119 COIL CHOKE EXC28CG900U
L4200 9JD021ES11R8K COIL 1.8 UH
L4201 9JD021ES11R8K COIL 1.8 UH
*** JACKS ***
CP9600 9JD0639800006 HOLDER,IC 1857468-1
J4202 9JD060R431039 RCA JACK RCA-228H
(
3
)
NI-02
J4203 9JD060R411058 RCA JACK RCA-341H
(
NI
)
-09
()
J4204 9JD060R431040 RCA JACK RCA-341H
(
2
)
NI-06
! J4205 9JD060R131025 HEADPHONE JACK PJ-317-02
J4206 9JD063Y100098 SOCKET,21PIN RGB-56H
J4207 9JD063Y100098 SOCKET,21PIN RGB-56H
J4208 9JD060R131024 HEADPHONE JACK PJ-364H
J4301 9JD060R401140 RCA JACK RCA-101HT
(
OR
)
*** CONNECTORS ***
CD3200 9JD06CH2F0504 CORD CONNECTOR CH2F0504
CD3203 9JD06CH2E0504 CORD CONNECTOR CH2E0504
CP2804 9JD069S2U0739 CONNECTOR PCB SIDE A2006WV0-2X15P
CP4200 9JD069S250639 CONNECTOR PCB SIDE A2001WR2-5P
CP4301 9JD069S230639 CONNECTOR PCB SIDE A2001WR2-3P
*** CRYSTAL & CERAMIC OSCILLATORS ***
X800 9JD100DT05403 CRYSTAL DSX321G
X9600 9JD100GT02727 CRYSTAL SMD-49 C27000J029
*** NETWORKS ***
NR2400 9JD110P4220M5 R,NETWORK 4D02WGJ0220TCE
NR2402 9JD110P4220M5 R,NETWORK 4D02WGJ0220TCE
NR2403 9JD110P4220M5 R,NETWORK 4D02WGJ0220TCE
NR2404 9JD110P4220M5 R,NETWORK 4D02WGJ0220TCE
NR2804 9JD110P4220M5 R,NETWORK 4D02WGJ0220TCE
NR2805 9JD110P4220M5 R,NETWORK 4D02WGJ0220TCE
NR2806 9JD110P4220M5 R,NETWORK 4D02WGJ0220TCE
NR9600 9JD110P4330M5 R,NETWORK 4D02WGJ0330TCE
*** OTHERS ***
CP301 9JD06GG140019 CONNECTOR PCB SIDE A2502WR-4
A
CP800 9JD06GG260029 CONNECTOR PCB SIDE A2001WV-6
A
CP803 9JD06GG240029 CONNECTOR PCB SIDE A2001WV-4
A
CP804 9JD06G5AA1002 CONNECTOR PCB SIDE USB-A1D102F-4B4N
CP3601 9JD06GDYL3038 CONNECTOR PCB SIDE 1A0300030
CP3602 9JD06GDYL3038 CONNECTOR PCB SIDE 1A0300030
CP4201 9JD06GG2E0029 CONNECTOR PCB SIDE A2001WV-14
A
CP4302 9JD06G7S21501 CONNECTOR PCB SIDE WD-00021-R
CP5800 9JD06GF2G0020 CONNECTOR PCB SIDE WD-00028-R
K3-4
