Sharp LC-19DV200E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
SH3200 9JD126D000045 TERMINAL PIN YQ-12
SH3204 9JD126D000045 TERMINAL PIN YQ-12
SH3205 9JD126D000045 TERMINAL PIN YQ-12
SH3206 9JD126D000045 TERMINAL PIN YQ-12
DVD MT PCB ASS'Y
*** PCB ***
PCB130 9JDA54Z01A130M DVD MT PCB ASS'Y DMJ120B
*** DIODES ***
D2301 9JDDDARR730E0 DIODE SCHOTTKY BARRIER KDR730E-RTK/P
D2302 9JDDDARR730E0 DIODE SCHOTTKY BARRIER KDR730E-RTK/P
D4001 9JDDGERMA1110 DIODE SILICON MA111-
(
TX
)
*** ICS ***
! IC2301 9JDI1UFV5766S 5CH MOTOR DRIVER IC AM5766
IC4001 9JDIC8K0389LD DVD MPEG 128PIN MEDIATEK MT1389DE/L-L
IC4004 ----- MEMORY DATA 16MBIT FLASH 100MHZ EN25Q16-100HIP
IC4005 9JDIGXJ01620F SDRAM 64M CL=2 HY57V641620FTP-7
IC8501 9JDI0QF045650 DUAL OPEAMP NJM4565M
(
TE1
)
IC8502 9JDI1ZF981D50 REGULATOR 1.8V RP131H181D5-T1-F
*** TRANSISTORS ***
Q2301 9JDTCAA3875SY TRANSISTOR SILICON KTC3875S
_
Y
_
RTK
Q2302 9JDTAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P
Q2303 9JDTAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P
Q2304 9JDTCAA3875SY TRANSISTOR SILICON KTC3875S Y RTK
__
Q2305 9JDTCAA3875SY TRANSISTOR SILICON KTC3875S
_
Y
_
RTK
Q8506 9JDT27T035410 FET 2SK3541
_
T2L
Q8507 9JDT27T035410 FET 2SK3541
_
T2L
*** COILS ***
B2341 9JD024HC56013 CORE,BEADS FCM1608KF-601T02
B2342 9JD024HC56013 CORE,BEADS FCM1608KF-601T02
B4003 9JD024HC51023 CORE,BEADS FCM1608KF-102T02
B4008 9JD024HC51023 CORE,BEADS FCM1608KF-102T02
B4010 9JD024HC51023 CORE,BEADS FCM1608KF-102T02
B4012 9JD024HC51023 CORE,BEADS FCM1608KF-102T02
B8501 9JD024HC51216 CORE,BEADS HCB1608KF-121T20
B8502 9JD024HC51023 CORE,BEADS FCM1608KF-102T02
B8503 9JD024HC51216 CORE,BEADS HCB1608KF-121T20
B8504 9JD024HC51023 CORE,BEADS FCM1608KF-102T02
L8501 9JD021ES11R8K COIL 1.8 UH
*** CONNECTORS ***
CP2301 9JD069EVKT01C CONNECTOR PCB SIDE 04
_
6232
_
422
_
008
_
868+
CP2302 9JD069EV5001C CONNECTOR PCB SIDE 00
_
6232
_
005
_
006
_
894+
CP2303 9JD069EV4001C CONNECTOR PCB SIDE 00
_
6232
_
004
_
006
_
894+
*** CRYSTAL & CERAMIC OSCILLATORS ***
X4001 9JD1003T02733 CRYSTAL HC49SFWB
*** NETWORKS ***
NR4002 9JD11074330M7 R,NETWORK CRA108330JV
*** OTHERS ***
CP8501 9JD06GG2E0019 CONNECTOR PCB SIDE A2001WR-14
A
CP8502 9JD06GG280019 CONNECTOR PCB SIDE A2001WR-8
A
SH8501 9JD126D000045 TERMINAL PIN YQ-12
SH8502 9JD126D000045 TERMINAL PIN YQ-12
POWER PCB ASS'Y
K3-5
