Sharp LC-19DV200E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
*** PCB ***
PCB240 9JDA54Z01A240M POWER PCB ASS'Y CEJ549
A
*** RESISTORS ***
! R3811 9JDRC31X1125J RC 1.2M OHM 1W
! R3812 9JDRC31X1126J RC 12M OHM 1W
! R3825 9JDR3K781R22J R,METAL OXIDE 0.22 OHM 1W
! R3830 9JDR002T4103J RC 10K OHM 1/4W
R3851 9JDR3K78AR22J R,METAL OXIDE 0.22 OHM 2W
R3855 9JDR3K78AR22J R,METAL OXIDE 0.22 OHM 2W
! R3860 9JDR655842R2J R,FUSE 2.2 OHM 1/4W
! R3861 9JDR3K781823J R,METAL OXIDE 82K OHM 1W
! R3864 9JDR002T2101J RC 100 OHM 1/2W
*** CAPACITORS ***
C3801 9JDP4K12D104K CMPP 0.1 UF 310V
! C3805 9JDE718HH331D CE 330 UF 400V
! C3808 9JDP4K12D224K CMPP 0.22 UF 310V
! C3809 9JDCE39E0M13M CC 0.001 UF 250V E
! C3810 9JDCE39E0M13M CC 0.001 UF 250V E
! C3811 9JDCE39E0M13M CC 0.001 UF 250V E
! C3812 9JDCE39E0M13M CC 0.001 UF 250V E
! C3813 9JDP4K12D224K CMPP 0.22 UF 310V
! C3825 9JDE63ZFH220D CE 22 UF 400V
C3832 9JDC0340R6Q2K CC 470 PF 1KV R
C3833 9JDC0340R613K CC 0.001 UF 1KV R
C3836 9JDC234SL6E1J CC 15 PF 1KV SL
! C3837 9JDP4NBE5333J CMPP 0.033 UF 630
! C3839 9JDC0390R6H3K CC 0.0022UF 1KV R
C3840 9JDCE39E0MQ2K CC 470 PF 250V E
C3841 9JDCE39E0MQ2K CC 470 PF 250V E
C3848 9JDE9E8F3102D CE 1000 UF 25V
C3849 9JDE9E8F3102D CE 1000 UF 25V
! C3850 9JDE7EYT1102M CE 1000 UF 10V
! C3851 9JDE8E1G4102M CE 1000 UF 35V
! C3852 9JDE8E2T1471D CE 470 UF 10V
C3853 9JDE8E6F2472D CE 4700 UF 16V
C3855 9JDE8E1G4102M CE 1000 UF 35V
C3856 9JDC0PLRR713K CC 0.001 UF 2KV R
C3870 9JDC0PLRR7H2K CC 220 PF 2KV R
*** DIODES ***
D3803 9JDD2Z05SB800 DIODE,BRIDGE D5SB80
! D3804 9JDD7KE103020 DIODE VARIST
A
S10K300E2S5M4
D3805 9JDD97U03001B DIODE,ZENER MTZJ30B T-77
D3806 9JDDOU011020M DIODE VARIST
A
DA38-102MB-M
! D3807 9JDD4CTN40060 DIODE SILICON 1N4006-A5
! D3808 9JDD4CTN40060 DIODE SILICON 1N4006-A5
D3809 9JDD2ARMAB340 DIODE SCHOTTKY SMAB34
D3810 9JDD4CT01H6A0 DIODE RECTIFIER 1H6-A2
D3812 9JDD97U03001B DIODE,ZENER MTZJ30B T-77
D3813 9JDDJBUA15012 DIODE ZENER HZS15NB2
D3814 9JDDDARR730E0 DIODE SCHOTTKY BARRIER KDR730E-RTK/P
D3815 9JDD4AT106FE0 DIODE RECTIFIER RL106F-E
D3816 9JDD1VT001330 DIODE,SILICON 1SS133T-77
D3817 9JDD28R11FS40 DIODE SCHOTTKY EC11FS4-TE12L
D3818 9JDD28R11FS40 DIODE SCHOTTKY EC11FS4-TE12L
D3819 9JDD28A10A450 DIODE SCHOTTKY BARRIER FCQS10A045
! D3820 9JDD2LT001F50 DIODE SILICON 1F5-E
! D3821 9JDD28A10A061 DIODE SCHOTTKY BARRIER FCQS10A065
D3822 9JDD28A10A080 DIODE SCHOTTKY BARRIER FCHS10A08
D3824 9JDD97U01101B DIODE,ZENER MTZJ11B T-77
! D3825 9JDD28A10A080 DIODE SCHOTTKY BARRIER FCHS10A08
D3828 9JDD28R1QS040 DIODE EC31QS04-TE12L
D3830 9JDDJBUA15012 DIODE ZENER HZS15NB2
D3832 9JDDJBUA22012 DIODE ZENER HZS22NB2
D3833 9JDD97U01801B DIODE,ZENER MTZJ18B T-77
*** ICS ***
K3-6
