Sharp LC-19DV200E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
! IC3801 9JDI1KJ9A431
A
VARIABLE SHUNT REGULATOR TAPE KIA431A-AT
! IC3802 9JDI16D052030 CURRENT RESONANT CTL IC MCZ5203NA-7101
! IC3803 9JDI5PD028LN0 VIPER28LN VIPER28LN
IC3804 9JDI1KJ9A431
A
VARIABLE SHUNT REGULATOR TAPE KIA431A-AT
! IC3805 9JDI5HJ950UC0 REGULATOR VO=5.0V IO=800M
A
S-1170B50UC-OUJTFG
IC3806 9JDTK9A3443B0 FET SI3443BDV-T1-E3
! IC3807 9JDI53F958930 1.8A 1CH STEP DOWN SW REG LV5893M
! IC3808 9JD000220002W PHOTO COUPLER PS2561AL1-1-V
(
W
)
IC3809 9JD000220002W PHOTO COUPLER PS2561AL1-1-V
(
W
)
! IC3810 9JD000220002W PHOTO COUPLER PS2561AL1-1-V
(
W
)
*** TRANSISTORS ***
! Q3802 9JDTAAT01281Y TRANSISTOR SILICON KTA1281
_
Y
! Q3805 9JDTJXG10NK50 FET STF10NK50Z
! Q3806 9JDTJXG10NK50 FET STF10NK50Z
Q3807 9JDTCAA3875SY TRANSISTOR SILICON KTC3875S
_
Y
_
RTK
Q3809 9JDTAAA1504SY TRANSISTOR SILICON KTA1504S
_
Y
_
RTK
Q3812 9JDTNAAA05001 COMPOUND TRANSISTOR KRC101S-RTK
Q3813 9JDTAAT012714 TRANSISTOR, SILICON KTA1271
_
Y-AT
Q3814 9JDTCATC31980 TRANSISTOR,SILICON KTC3198-AT
(
Y,GR
)
*** COILS ***
B3802 9JD024AC1121G CORE,BEADS BLM31PG121SN1L
! L3801 9JD029B000185 COIL,LINE FILTER JLB28120
L3802 9JD02167E100K COIL 10 UH
L3803 9JD02167E100K COIL 10 UH
L3806 9JD02167E100K COIL 10 UH
L3807 9JD021D0N220M COIL 22 UH
*** TRANSFORMERS ***
! T3801 9JD048728002H TRANSFORMER,SWITCHING 8728002H
! T3802 9JD0481190141 TRANSFORMER,SWITCHING 81190141
*** JACKS ***
! J3801 9JD064Q2A0004 JACK,AC CCT2302-0721C
*** CONNECTORS ***
CD3806 9JD06CH282504 CORD CONNECTOR CH282504
CP3808 9JD069S2F0629 CONNECTOR PCB SIDE A2001WV2-15P
CP3809 9JD069S2E0629 CONNECTOR PCB SIDE A2001WV2-14P
*** FUSES ***
! F3801 9JD0805T02501 FUSE SCT 2.5
A
! F3802 9JD0805T02501 FUSE SCT 2.5
A
F3803 9JD0835A02505 MICRO FUSE 20N
_
2500FSW
*** THERMISTOR ***
! TH3801 9JDDSQFVE4R0L THERMISTOR 4D2-22LCS
*** OTHERS ***
CP3803 9JD06GG2E0019 CONNECTOR PCB SIDE A2001WR-14
A
EL2401 9JD124116281
A
EYE LET XRY16X28BD
EL2402 9JD124120301
A
EYE LET XRY20X30BD
OPERATION PCB ASS'Y
*** PCB ***
PCB270 9JDA54Z01A270M OPERATION PCB ASS'Y CEJ550
A
*** SWITCHES ***
SW2201 9JD0504101T34 SWITCH,TACT EVQ21505R
SW2202 9JD0504101T34 SWITCH,TACT EVQ21505R
SW2203 9JD0504101T34 SWITCH,TACT EVQ21505R
K3-7
