Sharp LC-19DV200E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
SW2204 9JD0504101T34 SWITCH,TACT EVQ21505R
SW2205 9JD0504101T34 SWITCH,TACT EVQ21505R
SW2206 9JD0504101T34 SWITCH,TACT EVQ21505R
SW2207 9JD0504101T34 SWITCH,TACT EVQ21505R
SW2208 9JD0504101T34 SWITCH,TACT EVQ21505R
*** OTHERS ***
CP2202 9JD06GG230019 CONNECTOR PCB SIDE A2001WR-3
A
TUNER PCB ASS'Y
*** PCB ***
PCB290 9JDA54Z01A290M TUNER PCB ASS'Y CEJ569
A
*** COILS ***
B5805 9JD024HC51816 CORE,BEADS HCB1608KF-181T20
*** TUNER ***
! TU5800 9JD0164Y03008 DIGITAL TUNER TDTW-S126D
*** OTHERS ***
CP5801 9JD06GF2G0010 CONNECTOR PCB SIDE WD-00027-R
SH5801 9JD126D000045 TERMINAL PIN YQ-12
AND OTHERS
*** COILS ***
TR4201 9JD02AHB9A972 CORE,FERRITE W5T29X7.5X19
*** CONNECTORS ***
CD302 9JD06CH143904 CORD CONNECTOR CH143904
CD3803 9JD06CH2E1405 CORD CONNECTOR CH2E1405
CD4200 9JD06CH254602 CORD CONNECTOR CH254602
CD4201 9JD06CH2E2602 CORD CONNECTOR CH2E2602
CD4301 9JD06CH233302 CORD CONNECTOR CH233302
*** AC CORD ***
! CD3810 9JD120Q155804 CORD AC P205-1324-4
*** OTHERS ***
BT001 9JD141L003022 BATTERY,MANGAN R6P
(
AR
)
2P WO GM PET EU
BT002 9JD141L003022 BATTERY,MANGAN R6P
(
AR
)
2P WO GM PET EU
CD2801 9JD06EARU2208 CORD CONNECTOR EARU2208
! SP301 9JD070Y056003 SPEAKER S0412F03
! SP302 9JD070Y056003 SPEAKER S0412F03
TM101 9JD076B0RV011 TRANSMITTER ETR0088-010510LF
! V2801 9JD09EV126019 LCD V260B2-L01
RESISTOR
RC................... CARBON RESISTOR
CAPACITORS
CC................... CERAMIC CAPACITOR
CE................... ALUMI ELECTROLYTIC CAPACITOR
CP................... POLYESTER CAPACITOR
CPP.................. POLYPROPYLENE CAPACITOR
CPL.................. PLASTIC CAPACITOR
CMP....................... METAL POLYESTER CAPACITOR
CMPL................ METAL PLASTIC CAPACITOR
CMPP................ METAL POLYPROPYLENE CAPACITOR
K3-8
