Sharp LC-19LE430E User Manual

LC-19LE430E/UK, LC-22LE430E/UK, LC-26LE430E/UK, LC-32LE430E/UK
12
Fig.4
2. Remove the 4 screws. Detach the Base neck as Fig.4.
Step 2. Remove the REAR COVER Assy.
1. Remove the 5 screws. Detach the REAR COVER as Fig.5.
Fig.5
Note: How to easy remove rear cabinet
Step 3. Remove the Main, Power and the Speakers.
Put left hand on the center of rear cabinet
Right hand fingers put under the machine rim
Press down
Pull up Pull up
Pull up Pull up
