Sharp LC-19LE430E

LC-19LE430E/UK, LC-22LE430E/UK, LC-26LE430E/UK, LC-32LE430E/UK
24
3. Release the speaker cable from its clamp, pull up and remove the speaker as Fig.9.
Fig.9
Step 4. Remove the Bracket and Bezel.
1. Remove the 10 screws. Detach the Bracket as Fig.10, Fig.11 and Fig.12.
Fig.10 Fig.11 Fig.12
2. Remove the panel from the bezel as Fig.13
Panel:
Fig.13
Step 5. Remove the IR and Key board.
1. Disconnect 1 cable, then release the clips. Detach the IR board as Fig.14.
Fig.14
2. Disconnect 1 cable. Detach the Key board as Fig.15.
Fig.15
