Sharp LC-22DC30M User Manual

LC-22DC30M
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET AND MECHANICAL PARTS
1 CCABAC854WJ01 N V Front Cabinet Ass'y
1-1 GCABAC854WJ4A N V Front Cabinet
1-2 HDECQB681WJ4A V LED Cover
1-3 PSPAHB389WJ4Z AA J Lens Himeron 20*10*t0.9
1-4 PSPAHC535WJ00 N V Mask Himeron 270*7*0.35, x2
1-5 PSPAHC536WJ00 N V Mask Himeron 477*7*0.35, x2
2 CCABBC058WJ01 N V Rear Cabinet Ass'y
2-1 GCABBC058WJ4A N V Rear Cabinet
2-2 JBTN-A954WJ4A V Control Button
2-3 LANGKD433WJ4W V Mounting Angle, x2
2-4 LANGKD438WJ4W V Visa Angle, x2
2-5 PMLT-A692WJZZ V SPK Moltplane, x2
2-6 PSPAHC137WJ4Z V Himeron 137*10*0.35, x2
2-7 XEBS830P08000 AA J For VESA Holder, 2/For Mounting Angle, x2
3 GCOVAE278WJ4A V Side Cover
5 TLABME198WJZZ N V Model Label (for Indonesia, Asia, Middle East, Philippines, Vietnam, Asia)
5 TLABME220WJZZ N V Model Label (for Saudi Arabia)
5 TLABME219WJZZ N V Model Label (for Thailand)
6 TLABV0182AJZZ AB J No.Card
7 GBFL-A034WJZZ V SPK Buffer, x2
8 LANGKD481WJ4W N V Support Angle
9 LANGKD435WJ4W V Bottom Bracket
10 PSPAGA385WJZZ AC J SPK Rubber, x4
11 PSPAZC816WJKZ V Spacer, x2
12 PSPAZC819WJKZ V Spacer, x3
13 TLABZD145WJZZ - - POP LABEL
14 XEBS830P08000 AA J Scerw, x4
15 XBPS730P06WS0 AA J Scerw, x4
16 XBBS830P08000 AA J Scerw, x6
17 PSLDMB795WJKZ V Conductive Tape
18 PSPAHB156WJ4Z AB J Spacer, x2
19 QCNW-M494WJPZ N V SP Wire
20 QCNW-M495WJPZ N V LVDS FFC
21 QCNW-M496WJPZ N V LED Wire
22 V
SP8030PA018A N V Speaker, x2
