Sharp LC-22DV200E Service Manual

GENERAL SPECIFICATIONS
AC Adapter No
AC Cord (for AC Adapter) No
AC Cord Yes
AV Cord (2Pin-1Pin) No
HDMI-DVI Cable No
Registration Card No
300 ohm to 75 ohm Antenna Adapter No
Stand Screw??? Yes (3pcs)
Stand Yes
Frame Stand No
G-14 Interface
Switch Side Power (Tact) Yes
System Select No
Main Power SW No
Channel Up / Play / Menu Up Yes
Channel Down / Stop / Menu Down Yes
Volume Up/Menu > Yes
Volume Down/Menu < Yes
Input Select/Enter Yes
Menu Yes
Eject Yes
Indicator Power/Stand-by Yes(GREEN / RED)
On Timer No
Terminals Rear Video Input 1
RCA x 1 (AV2)
Audio Input 1
RCA x 2(L/MONO, R) (AV2)
S- Input 1 Yes
Video Input 2 No
Audio Input 2 No
S- Input 2 No
Video Output No
Audio Output No
Digital Audio Out (Coaxial)
Yes
Other Terminal Headphone
Euro Scart (21Pin)
1Scart (AV1)
Component In
RCA x 3
Audio Input (Component In use)
RCA x 2(L/MONO, R)
PC Monitor Input (D-Sub)
Yes
PC Monitor Input (D-Sub)
Yes
Audio Input
Mini Pin Jack( 3.5), STEREO
HDMI Input 1
Yes
Audio Input (HDMI/DVI In use) PC Monitor Audio Input Alternative
HDMI Input 2 No
Audio Input (HDMI/DVI In use) No
HDMI Input 3 No
Audio Input (HDMI/DVI In use) No
USB(Software Update)
Yes
Sub Woofer Output No
Diversity No
Ext Speaker No
DC Jack 12V(Center +) No
AC Inlet
Yes
VHF/UHF Antenna Input
DIN Type
Side CI Card Slot Yes
G-15 Set Size
Approx. W x D x H (mm) 536.5 x 201 x 396
w/o Stand,Handle Approx. W x D x H (mm)
536.5 x 67 x 367.5
G-16 Weight
Net Approx. 5.3kg (11.7lbs)
Net w/o Stand,Handle Approx. 4.7kg (10.4lbs)
Gross Approx. 7.7kg (16.9lbs)
Gross w/Master Carton (Approx.) --- kg ( --- lbs)
G-17 Carton
Master Carton No
Content ---- Sets
Material -- /--
Dimensions W x D x H(mm) -- x -- x --
Description of Origin No
Gift Box Yes
Material Single/Brown
Dimensions W x D x H(mm) 660 x 458 x 168
Design As per Buyer's
Description of Origin No
Drop Test Natural Dropping At 1 Corner / 3 Edges / 6 Surfaces
Height (cm) 80
Container Stuffing 1092 Sets/45' Trailer
w/Pallet Yes
w/Wrapping Yes
G-18 Material
Cabinet Cabinet Front PC+ABS 94V0 NON-HALOGEN
Cabinet Rear PS 94V0 NON-DECABROM
Stand PC+ABS 94V0 NON-HALOGEN
PCB Non-Halogen No
Eyelet Yes
G-19 Environment
Environmental standard requirement Green procurement of SHARP
Pb- Free Phase3(PHASE3A)
Measures for Whisker Yes
WEEE Yes
A2-6
