Sharp LC-22DV200E Service Manual

1. Remove the Stand, Back Cabinet Ass'y and LCD Panel.
(Refer to item 1 of the DISASSEMBLY INSTRUCTIONS.)
2.
Slide the Gear Middle toward the arrow direction by hand to release the lock. (Refer to Fig. 1)
3. Take out the Disc from the DVD Deck. Be careful not to scratch on the Disc.
DVD Deck
DISC REMOVAL METHOD AT NO POWER SUPPLY
Gear Middle
Fig. 1
Gear Middle
A1-4
