Sharp LC-22DV200E Service Manual

GENERAL SPECIFICATIONS
G-1 TV
LCD LCD Size / Visual Size 21.60 inch / 547.7mmV
System
LCD Type Color TFT LCD
Number of Pixels 1366(H) x 768(V)
View Range Left/Right 85/85 degree
Up/Down 80/80 degree
Bright Dot n 0
Zero Bright Dot Ratio --
Color System PAL / SECAM
Speaker 2 Speaker
Position Front
Size 1.0 x 2.7 inch
Impedance 8 ohm
Sound Output MAX 1.5W + 1.5W
10%(Typical) ---
NTSC3.58+4.43 /PAL60Hz Yes
G-2 DVD System
Color System NTSC, PAL
Disc
Disc Diameter 120 mm , 80 mm
Drive DSM-3
Search speed Fwd 4 step
Actual 4, 8, 16, 32 times (DVD)
4, 8, 16, 32 times (CD)
Rev 4 step
Actual 4, 8, 16, 32 times (DVD)
4, 8, 16, 32 times (CD)
Slow speed Fwd 4 step
Actual 1/16, 1/8, 1/4, 1/2 times
Rev 4 step
Actual 1/16, 1/8, 1/4, 1/2 times
G-3 Tuning
Broadcasting System Analog
System
Digital
Tuner and System 1Tuner (Analog+Digital)
Receive CH Destination UK, I.R., CCIR Hyper+France CATV
CH Coverage Analog IreE2~E4, X~Z+2, S1~S10, E5~E12,S11~S41,E21~E69
Digital E5~E12, ItaD~H2, Fra1~6, Rus6~12, E21~E69
Intermediate
Analog
DVB-T(OFDM 2k/8k, 16QAM/64QAM), DVB-T HD(H.264)
U.K., I.R., CCIR, FRENCH System
B/G, D/K, I/I, L
DVD, CD-DA, CD-R/RW, Video CD, SVCD
DVD-R/RW (Video Format Only)
BG / II / DK, L / L' (SECAM VL)
<
=
Intermediate
Analog
Frequency Picture(FP) 38.9 / 38.9 / 38.9 / 33.9MHz
Sound(FS)
33.4 / 32.9 / 32.4 / 40.4MHz
FP-FS
5.5 / 6.0 / 6.5 / 6.5MHz
Digital
36.167MHz
Auto Tuning Method
ALL Band (Not C.C.I.R. CH Plan)
Preset CH 2000 Service in total of Analog and Digital.
Stereo/Dual TV Sound Nicam/A2 Dual
Tuner Sound Muting Yes
G-4 Signal
Video Signal Input Level 1 V p-p/75 ohm
Output Level 1 V p-p/75 ohm
S/N Ratio (Weighted) 65dB
Horizontal Resolution at DVD Mode 400 Lines
RGB Signal Output Level --
Audio Signal Input Level -8.0dBm/50k ohm
Output Level at DVD -12.0dBm/1k ohm (-20dBFs 0dBFs=2.0Vrms)
at TV -8 dBm/1k ohm (0dBm=0.775Vrms)
Digital Output Level 0.5 V p-p/75 ohm
S/N Ratio at DVD (Weighted) 85dB
Harmonic Distortion 0.02% (1KHz)
Frequency Response : at DVD 4Hz - 22kHz
at Video CD/SVCD 4Hz - 20kHz
at CD 4Hz - 20kHz
G-5 Power
Power Source AC 220-240V AC 50Hz
DC ---
Power Consumption at AC 49 W at AC 230 V 50 Hz
at DC --
Stand by (at AC) w/ EPG Timer --
w/o EPG Timer 0.7 W at AC 230 V 50 Hz
Per Year -- kWh/Year
Protector Power Fuse Yes
G-6 Regulation
Safety CE(EN60065:2002+AMD.11:2008), SEMKO, HOMOLO,
Ukraine Safety
Radiation CE
X-Radiation ---
G-7 Temperature
Operation
+5
o
C ~ +40
o
C
Storage
-20
o
C ~ +60
o
C
Space Around Unit 100mm (4inch)
G-8 Operating Humidity
Less than 80% RH
G-9 OSD Language
(TV) English, Spanish, German, French, Italian, Swedish
Dutch, Russian, Portuguese, Turkish, Greek, Finnish
Polish, Danish, Norwegian, Hungarian, Czech, Slovak
Estonian, Latvian, Lithuanian, Slovenian, Ukranian
(DVD) English, Spanish, German, French, Italian, Swedish
Dutch, Russian, Portuguese, Turkish, Greek, Finnish
Polish, Danish, Norwegian, Hungarian, Czech, Slovak
Estonian, Latvian, Lithuanian, Slovenian, Ukranian
BG / II / DK, L / L' (SECAM VL)
A2-1
