71 ± 1mm
Fold it by 90°
DISASSEMBLY INSTRUCTIONS
Install the position (A) and (B)
[ 4 pin FFC ]
[ 5 pin FFC ]
Fig. 2-5-B
(A)
(B)
Fig. 2-5-C
Printing Surface
B2-5
25 ± 1mm Fold it by 90°
Fold it by 90° 15 ± 1mm
16 ± 1mm
10 ± 1mm
Fig. 2-5-D
Printing Surface
B2-5
