ELECTRICAL REPLACEMENT PARTS LIST
REF. NO.
PART NO.
DESCRIPTION
CODE
REMOCON PCB ASS'Y
*** PCB ***
PCBDA0
9JDA54C01ADA0M
REMOCON PCB ASS'Y
CEJ513A
*** DIODES ***
D7601
9JD0021E9Q010
LED
LTL-1BEFJ-002A
*** OTHERS ***
CP7601
9JD06GG250029
CONNECTOR PCB SIDE
A2001WV-5A
OS7601
9JD077Q038009
REMOTE RECEIVER
KSM-2003TCW2P
MAIN PCB ASS'Y
*** PCB ***
PCBF40
9JDA54C01AF40M
MAIN PCB ASS'Y
CMJ151B
*** DIODES ***
D802
9JDDDARR730E0
DIODE SCHOTTKY BARRIER
KDR730E-RTK/P
!
D2802
9JDD4CRSK34A0
DIODE SCHOTTKY
SK34A
!
D2803
9JDD28R1QS040
DIODE
EC31QS04-TE12L
D3401
9JDD28R1QS040
DIODE
EC31QS04-TE12L
D3402
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D3404
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D3410
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D3410
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D3481
9JDD28R1QS040
DIODE
EC31QS04-TE12L
D3482
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D3602
9JDDDARR730E0
DIODE SCHOTTKY BARRIER
KDR730E-RTK/P
D3603
9JDDDARR730E0
DIODE SCHOTTKY BARRIER
KDR730E-RTK/P
D3604
9JDD61R0V8001
DIODE VARISTA
EZJZ0V80010
D3605
9JDD61R0V8001
DIODE VARISTA
EZJZ0V80010
D4302
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D4303
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D4304
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4305
9JDDE7RB8R22B
DIODE ZENER
UDZSNP8.2B TE-17
D4306
9JDDE7RB8R22B
DIODE ZENER
UDZSNP8.2B TE-17
D4307
9JDDE7RB8R22B
DIODE ZENER
UDZSNP8.2B TE-17
D4308
9JDDE7RB8R22B
DIODE ZENER
UDZSNP8.2B TE-17
D4310
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4311
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4312
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4313
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4314
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4315
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4316
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4317
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4318
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4319
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4320
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4322
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
D4323
9JDDE7RB4R72B
DIODE ZENER
UDZSNP4.7B TE-17
*** ICS ***
IC800
9JDIC8M053620
SCALER 470PIN BGA
MT5362CHG
IC801
9JDICRJ032CN0
EEPROM SOIC M32P
AT24C32CN-SH-T
IC802
9JDIGXM05162E
DDR2-800 512M CL=5
H5PS5162FFR-S5C
IC803
9JDIGXM05162E
DDR2-800 512M CL=5
H5PS5162FFR-S5C
IC804
9JDICRJ0F0810
NOR FLASH 8M SPI
AT26DF081A-SU
!
IC805
9JDIGRF0704U0
2A DROPOUT LINEAR REGULATOR
UP7704U8
IC806
9JDI9UF032290
RESET IC 2.9V TYPE
PST3229NR
IC807
-----
MEMORY DATA NAND FLASH 256M
HY27US08561A-TP
!
IC3401
9JDI5PJ045250
2A 30V SWITCHING REGULATOR
SC4525ASETRT
!
IC3402
9JDI1ZF9331D0
REGULATOR 3.3V
RP131H331D-T1-F
!
IC3403
9JDI1ZF9501D0
REGULATOR 5V
RP131H501D-T1-F
!
IC3404
9JDI1ZF9501D0
REGULATOR 5V
RP131H501D-T1-F
!
IC3405
9JDI1ZF9121DX
REGULATOR 1.25V
RP131H121D5-T1-F
