NO. PARTS CODE PRICE RANK NEW MARK PART RANK DESCRIPTION
R1722 VRS-TW2ED100JY AA V Resistor 560 Metal Oxide
R1723 VRS-TW2ED100JY AA V Resistor 560 Metal Oxide
R1726 VRS-TW2ED100JY AA V Resistor 560 Metal Oxide
R7019 VRS-TW2HF100JY AA V Resistor 10 1/2w
R9614 VRS-TW2HF1R0JY AA V Resistor 1 1/2w
R9615 VRS-TW2HF1R0JY AA V Resistor 1 1/2w
Q1703 VS2SA1530AR-1Y AA V Resistor 8.2 1/2w
Q3801 VSKRC102S//-1Y AB V Transistor KRC1025-RTK/P
Q502 VSKTA15
35T+-1Y AC V Transistor KTA1535T-RTK/P
Q3802 VSKTA1535T+-1Y AC V Transistor KTA1535T-RTK/P
Q501 VSKTC3875SG-1Y V Transistor
Q1501 VSKTC3875SG-1Y V Transistor
Q1705 VSKTC3875SG-1Y V Transistor
Q7801 VSMDD1951//-1Y V Transistor MDD1951RH
Q7802 VSMDD1951//-1Y V Transistor MDD1951RH
Q7002 VSSTD11N65M-1Y V Transistor STD11N65M2
D7005 RH-DXA095WJZZY AA V Diode
D7001 RH-DXA198WJZZY AA V Diode
D7002 RH-DXA198WJZZY AA V Diode
D7003 RH-DXA198WJZZY AA V Diode
D7004 RH-DXA198WJZZY AA V Diode
C7008 RC-EZB326WJZZ+ AA V Capacitor
TH7001 RH-HXA013WJZZ+ AD V Thermistor
VA7001 RH-VXA182WJN1+ V Diode
C7103 VCCSPA2HL220K+ AA V Capacitor 22p 500V Ceramic
R7015 VRN-RL3ABR36J+ V Resistor
R7010 VRS-RG3DB223J+ AA V Resistor 22k 2w Metal Oxide
F7001 QFS-HA001WJQZ V Fuse
J501 QJAKGA172WJQZ V Jack
J503 QJAKJA030WJQZ AD V Jack
J3301 QJAKJA039WJQZ AD V Jack
P7001 QPLGN0269GEZZ V AC Socket
J504 QSOCZA319WJQZ V USB Socket
C7007 RC-
EZC244WJZZ V Capacitor
C7106 RC-EZC247WJQZ V Capacitor
C7107 RC-EZC247WJQZ V Capacitor
C7001 RC-FZA558WJN1 V Capacitor
C7009 RC-FZA709WJQZ AA V Capacitor
C7012 RC-KZB009WJN1 AA V Capacitor
L7001 RCILFA434WJQZ AD V Coil
[3] B3KUE170I (MAIN/POWER UNIT)
