LC-24LE170I
13
NO. PARTS CODE PRICE RANK NEW MARK PART RANK DESCRIPTION
D7012 RH-FXA014WJZZ AA V Diode
T7001 RTRNWA472WJQZ V Transformer
D7803 VHDSR560///-1 V Diode
QPWBNG595WJZZ IR/LED PWB
P 0151 QPLGNB150WJZZY AC V LED IR Socket
C0157 RC-KZA237WJZZY AB V Capacitor
C0158 RC-KZA237WJZZY AB V Capacitor
D0152 RH-PXA193WJQZY AB V Diode
D0153 RH-PXA194WJQZY AB V Diode
R0151 VRS-CZ1JF101JY AA V Resistor 100 1/16w Metal Oxide
R0152 VRS-CZ1JF103JY AA V Resistor 10k 1/16w
Metal Oxide
R0154 VRS-CZ1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R0158 VRS-CZ1JF151JY AA V Resistor 150 1/16w Metal Oxide
R0159 VRS-CZ1JF681JY AA V Resistor 680 1/16w Metal Oxide
Q0152 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112V-1R
Q0153 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112V-1R
RMC0151 RRMCUA088WJZZ AE V IR Receiver HM238R-W4
NO. PARTS CODE PRICE RANK NEW MARK PART RANK DESCRIPTION
1 CCABAD184WJ02 V CAB -A ASSEMBLY
1-1 GCAB
AD184WJ6A V CAB-A
1-2 HDECQB939WJ6B V FRONT DECO
1-3 LANGKE743WJ6W V EARTH PLATE
1-4 PSLDMB964WJZZ V CONDUCT FOAM-H
1-5 PSLDMB965WJZZ V CONDUCT FOAM-V
1-6 PSLDMB971WJZZ V CONDUCT TAPE
1-7 ZSFIM-15T320E V PROTECT SHEET
1-8 ZSFIM-15T550E V PROTECT SHEET
2 CCABBC486WJ01 V CAB-B ASSEMBLY
2-1 GCABBC486WJ6A V CAB-B
2-2 JBTN-B023WJ6A V POWER BUTTON
2-3 LANGKE792WJ6W V TOP VESA ANG
2-4 LANGKE793WJ6W V BTM VESA ANG
3 GCOVAF096WJ6A V TERMINAL COVER
4 GCOVAF098WJ
6A V RC COVER
5 GCOVAF104WJ6A V AC COVER
6 JBTN-B024WJ6A V JOY BUTTON
[3] B3KUE170I (MAIN/POWER UNIT)
[4] B3KUE175I2 (LED/IR UNIT)
[5] CABINET AND MECHANICAL PARTS
