Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
120
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
RDENCA131WJZZ(LC-26/32/37AF3H/X)
POWER Unit (Continued)
R763 9JG0034016240 J 10k 1/10W Resistor(CHIP)
R764 9JG0034016240 J 10k 1/10W Resistor(CHIP)
R768 9JG0034003920 J 0 1/10W Resistor(CHIP)
R769 9JG0034016240 J 10k 1/10W Resistor(CHIP)
R770 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R772 9JG0034003882 J 15k 1/10W Resistor(CHIP)
R773 9JG0034016240 J 10k 1/10W Resistor(CHIP)
R774 9JG0034003742 J 100 1/10W Resistor(CHIP)
R775 9JG0034003882 J 15k 1/10W Resistor(CHIP)
R776 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R777 9JG0034003742 J 100 1/10W Resistor(CHIP)
R778 9JG0034003920 J 0 1/10W Resistor(CHIP)
R779 9JG0034015139 J 470k 1/2W Resistor
(Special Power)(RSP)
R780 9JG0034108366 J 220k 1/8W Resistor(CHIP)
R781 9JG0034108366 J 220k 1/8W Resistor(CHIP)
R782 9JG0034108366 J 220k 1/8W Resistor(CHIP)
R783 9JG0034109176 J 56k 1/8W Resistor(CHIP)
R784 9JG0034033900 J 1 1/2W Metal Oxide
R785 9JG0034059349 J 4.7k 1/4W Resistor(CARBON)
R786 9JG0034003955 J 4.7k 1/10W Resistor(CHIP)
R787 9JG0034004021 J 470 1/10W Resistor(CHIP)
R788 9JG0034003955 J 4.7k 1/10W Resistor(CHIP)
R901 9JG0034005060 J 4.7 1/10W Resistor(CHIP)
R903 9JG0034006482 J 2.2k 1/16W Resistor(CHIP)
R904 9JG0034006962 J 22k 1/16W Resistor(CHIP)
R905 9JG0034006474 J 100 1/16W Resistor(CHIP)
R1701 9JG0034003750 J 1k 1/10W Resistor(CHIP)
R1702 9JG0034004544 J 47 1/10W Resistor(CHIP)
R1703 9JG0034018189 J 6.8k 1/10W Resistor(CHIP)
R1704 9JG0034006210 J 4.7k 1/10W Resistor(CHIP)
R1705 9JG0034003750 J 1k 1/10W Resistor(CHIP)
R1706 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1707 9JG0034024111 J 120 1/10W Resistor(CHIP)
R1708 9JG0034018189 J 6.8k 1/10W Resistor(CHIP)
R1709 9JG0034018162 J 1.5k 1/10W Resistor(CHIP)
R1710 9JG0034036683 J 47 1/8W Resistor(CHIP)
R1711 9JG0034003955 J 4.7k 1/10W Resistor(CHIP)
R1712 9JG0034003750 J 1k 1/10W Resistor(CHIP)
R1713 9JG0034051291 J 27 1/10W Resistor(CHIP)
R1716 9JG0034003955 J 4.7k 1/10W Resistor(CHIP)
R1717 9JG0034003955 J 4.7k 1/10W Resistor(CHIP)
R1718 9JG0034019894 J 100 1/10W Resistor(CHIP)
R1719 9JG0034097445 J 68 1/8W Resistor(CHIP)
R1720 9JG0034024154 J 820 1/10W Resistor(CHIP)
R1721 9JG0034019894 J 100 1/10W Resistor(CHIP)
R1722 9JG0034098557 J 22 1/10W Resistor(CHIP)
R1723 9JG0034005907 J 470 1/10W Resistor(CHIP)
R1724 9JG0034097453 J 18 1/10W Resistor(CHIP)
R1725 9JG0034016232 J 10 1/10W Resistor(CHIP)
R1726 9JG0034005907 J 470 1/10W Resistor(CHIP)
R1727 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1728 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1729 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1730 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1731 9JG0034005303 J 47k 1/8W Resistor(CHIP)
R1732 9JG0034003750 J 1k 1/10W Resistor(CHIP)
R1734 9JG0034016321 J 47k 1/10W Resistor(CHIP)
R1735 9JG0034003750 J 1k 1/10W Resistor(CHIP)
R1736 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1737 9JG0034016283 J 220 1/10W Resistor(CHIP)
R1741 9JG0034016240 J 10k 1/10W Resistor(CHIP)
R1742 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1743 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1744 9JG0034003742 J 100 1/10W Resistor(CHIP)
R1745 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1746 9JG0034003750 J 1k 1/10W Resistor(CHIP)
R1747 9JG0034005257 J 470 1/8W Resistor(CHIP)
R1748 9JG0034003955 J 4.7k 1/10W Resistor(CHIP)
R1749 9JG0034016313 J 2.7k 1/10W Resistor(CHIP)
R1750 9JG0034004315 J 2.2k 1/8W Resistor(CHIP)
R1751 9JG0034004293 J 100 1/8W Resistor(CHIP)
R1752 9JG0034004293 J 100 1/8W Resistor(CHIP)
R1753 9JG0034016291 J 2.2k 1/10W Resistor(CHIP)
R1754 9JG0034016240 J 10k 1/10W Resistor(CHIP)
R1755 9JG0034003920 J 0 1/10W Resistor(CHIP)
R1756 9JG0034030448 J 1.2k 1/10W Resistor(CHIP)
R1757 9JG0034001421 J 10k 1/4W Resistor(CARBON)
R1758 9JG0034001421 J 10k 1/4W Resistor(CARBON)
R1759 9JG0034004021 J 470 1/10W Resistor(CHIP)
R1760 9JG0034003866 J 6.8k 1/10W Resistor(CHIP)
R1761 9JG0034033889 J 0.47 1/2W Metal Oxide
R1762 9JG0034003890 J 10 1/8W Resistor(CHIP)
R1763 9JG0034003866 J 6.8k 1/10W Resistor(CHIP)
R1764 9JG0034003866 J 6.8k 1/10W Resistor(CHIP)
R1765 9JG0034051372 J 1 1/10W Resistor(CHIP)
RX1701 9JG0034003920 J 0 1/10W Resistor(CHIP)
RX1703 9JG0034003920 J 0 1/10W Resistor(CHIP)
RX1704 9JG0034003750 J 1k 1/10W Resistor(CHIP)
MISCELLANEOUS PARTS
RC701 9JG0034016135 J Rectifier Stack, D5SBA60
RC702 9JG0034039208 J Rectifier Stack, FMX-G26S
RC1701 9JG0034095159 J Rectifier Stack, RB085T-40
RC1702 9JG0034073538 J Rectifier Stack, FMB-24
RC1703 9JG0034112924 J Rectifier Stack, D5SC4MR
RC1705 9JG0034016607 J Rectifier Stack, FMB-G14L
RC1706 9JG0034016607 J Rectifier Stack, FMB-G14L
CN701 9JG0034078424 J Receptacle, CCT2302-0711
CN702 9JG0034113939 J Connector, 5566-02A-210
CN1701 9JG0034095175 J Connector, B16B-PNDZS-1
CN1702 9JG0034094160 J Connector, B24B-PNDZS-1
CN1703 9JG0034094195 J Connector, B05B-PASK-1
CN1704 9JG0034094209 J Connector, B07B-PASK-1
CN1705 9JG0034094187 J Connector, B02B-PASK-1
F701 9JG0034088284 J Ceramic Fuse, AC250V 5A
F702 9JG0034088284 J Ceramic Fuse, AC250V 5A
F703 9JG0034074720 J Fuse, DC450V 2A
NR701 9JG0034054207 J Surge Absorber,
ERZV10D471(V10471U)
NR702 9JG0034054207 J Surge Absorber,
ERZV10D471(V10471U)
PKG1 9JG0034126569 J PWB, PSC10141
PKG7 9JG0034121451 J PWB, PSC20073
RL701 9JG0034088047 J Relay, ALKS326 DC18V
RL702 9JG0034088047 J Relay, ALKS326 DC18V
TH701 9JG0034019495 J Thermistor, SCK132R56MSA
TH702 9JG0034068356 J Thermistor, SCK08053M
TK1701 9JG0034090785 J Terminal, TP00451-21
TK1702 9JG0034090785 J Terminal, TP00451-21
TK1703 9JG0034090785 J Terminal, TP00451-21
TK1706 9JG0034090785 J Terminal, TP00451-21
TK1707 9JG0034090785 J Terminal, TP00451-21
TK1708 9JG0034090785 J Terminal, TP00451-21
TK1709 9JG0034090785 J Terminal, TP00451-21
TK1710 9JG0034090785 J Terminal, TP00451-21
1 9JG0034098026 J Sheet Metal Fitting,
APC42200-541
2 9JG0034098158 J Heat Sink, APH44000-790-1
3 9JG0034098166 J Heat Sink, APH44000-791-1
4 9JG0034098174 J Heat Sink, APH44000-792-1
5 9JG0034126399 J Insulator, APG47100-836
6 9JG0034116032 J Insulator, APG47100-834
8 9JG0034017611 J Screw, M3x8
9 9JG0034017603 J Screw, M3x10
10 9JG0034023484 J Eyelet, 16300108 DIA1.6X3L
11 9JG0034023492 J Eyelet, 25330108 DIA2.5X3.3L
12 9JG0034022445 J Name Plate, FCA32300-543-1
13 9JG0034000123 J Tube, F2(Z)DIA10x0.25
