Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
121
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
CABINET AND MECHANICAL PARTS
(LC-26AF3M/H/X)
1 CCABAB080WJ01 J Front Cabinet Ass'y
(LC-26AF3H/M)
1 CCABAB200WJ01 J Front Cabinet Ass'y
(LC-26AF3X)
1-1 Not Available - Front Cabinet —
1-2 GCOVAB240WJSA J R/C, LED Decoration Cover
1-3 HBDGBA015WJSA J Badge, "SHARP" AH
1-4 PSPAHA323WJZZ J Mask Spacer, x2 AD
1-5 PSPAHA324WJZZ J Mask Spacer, x2 AC
2 CCABBA638WJ02 J Rear Cabinet Ass'y
(LC-26AF3H/M)
2 CCABBA697WJ01 J Rear Cabinet Ass'y
(LC-26AF3X)
2-1 Not Available - Rear Cabinet —
2-2 GCOVAB232WJKA J Terminal Cover
2-3 LHLDWA055WJKZ J Wire Holder (AC Cord) AC
2-4 PSPAHA413WJZZ J Mask Spacer AB
3 CCOVAB340WJ01 J Top Control Cover Ass'y
3-1 Not Available - Top Control Cover —
3-2 JBTN-A459WJKA J Power Button
3-3 JBTN-A460WJKA J Operation Button
3-4 MSPRCA049WJFW J Spring for Power Button AC
4 CDAi-A171WJ04 J Stand Base Ass'y
4-1 Not Available - Stand Base —
4-2 LANGKA590WJSA J Base Bracket
4-3 PSPAZA476WJZZ J LEG-Cushion-B, x4 AC
4-4 PSPAZA477WJZZ J LEG-Cushion-C, x4 AD
4-5 XEBS940P10000 J Screw, x8 For Base Angle AB
5 CHNDPA010WJ12 J Handle Ass'y
5-1 Not Available - Handle —
5-2 GCOVAA713WJSA J Grip AH
5-3 GCOVAB074WJKE J Swivel Cover
5-4 GDAi-A228WJSA J Support
5-5 LANGKA235WJFN J Swivel Base AG
5-6 LX-BZA019WJFN J Support Cover, x2 AB
5-7 LX-NZA001WJFN J Screw AD
5-8 MHNG-A071WJ02 J Stand Hinge Ass'y BE
5-9 PSPAZA083WJZZ J Cushion, x2 AB
5-10 XCSSN50P20000 J Screw, x4 AB
5-11 XESSN40P10000 J Screw, x8 AB
6 Not Available - 26"LCD Panel Unit Ass'y —
6-1 RLCDTA067WJZZ J 26"LCD Panel Unit
6-2 CCHSMA210WJN1 J Back Light Chassis Ass'y BM
6-2-1 Not Available - Back Light Chassis —
6-2-2 LANGKA469WJFW J Bracket (Top-R)
6-2-3 LANGKA470WJFW J Bracket (Top-L)
6-2-4 LANGKA503WJFW J Center Bracket
6-2-5 LANGKA504WJFW J Bracket (Bottom-R)
6-2-6 LANGKA505WJFW J Bracket (Bottom-L)
6-2-7 LHLDZA591WJKZ J Lamp Clip, x8 AC
6-2-8 PGUMMA010WJKA J Lamp Rubber, x16
6-2-9 PMiR-A076WJZZ J Mirror Sheet
6-2-10 TCAUZA031WJZZ J Caution Label AB
6-2-11 XBPS730P06WS0 J Screw, x6 (M3x6) AA
6-3 Not Available - 26" Lamp Ass'y —
6-3-1 KLMP-A073WJZZ J Lamp, x8
6-3-2 QCNW-D683WJQZ J Connector, x7 AD
6-3-3 QCNW-D686WJQZ J Connector AE
6-4 LHLDZA592WJKZ J Lamp Holder, x2 AK
6-5 LX-BZA051WJFN J Screw, x4 M4X10 AB
6-6 LX-BZA114WJFN J Screw, x4 Panel Biss AA
6-7 PCOVUA064WJZZ J Diffusion Panel AY
6-8 PSHEPA353WJZZ J Diffusion Sheet, x2
6-9 QEARZA089WJFW J Earth Spring, x2 AD
6-10 XBPS730P06WS0 J Screw, x6 M3*6 AA
6-11 XBPSN30P14000 J Screw, x6 M3x12 AA
6-12 XEBS830P12000 J Screw, x4 M3x12 Panel HLDAA
7 DUNTKD186FE06 - MAIN Unit(LC-26AF3H/M) —
7 DUNTKD186FE07 - MAIN Unit(LC-26AF3X) —
8 DUNTKD304DE07 - AV Unit(LC-26AF3M) —
8 DUNTKD304DE08 - AV Unit(LC-26AF3H) —
8 DUNTKD304DE10 - AV Unit(LC-26AF3X) —
9 DUNTKD305DE07 - KEY Unit(LC-26AF3M) —
9 DUNTKD305DE08 - KEY Unit(LC-26AF3H) —
9 DUNTKD305DE10 - KEY Unit(LC-26AF3X) —
10 DUNTKD306DE07 - R/C, LED Unit(LC-26AF3M) —
10 DUNTKD306DE08 - R/C, LED Unit(LC-26AF3H) —
10 DUNTKD306DE10 - R/C, LED Unit(LC-26AF3X) —
11 RUNTKA151WJZZ - INVERTER Unit —
(LC-26AF3M)
11 RUNTKA205WJZZ - INVERTER Unit —
(LC-26AF3H/X)
12 RDENCA128WJZZ - POWER UNIT(LC-26AF3M) —
12 RDENCA131WJZZ - POWER UNIT —
(LC-26AF3H/X)
13 GCOVAB243WJKA J ID Cover
14 HiNDP5733CESB J Indicator Plate AD
15 HiNDPB377WJSA J Model Label (LC-26AF3X) AF
15 HiNDPB378WJSA J Model Label (LC-26AF3H)
15 HiNDPB379WJSA J Model Label (LC-26AF3M)
16 LANGTA203WJFW J Center Angle
17 LANGTA204WJFW J Center Guide Angle
18 LANGTA240WJFW J Cover Angle
19 LCHSMA227WJKA J Chassis Frame
20 LHLDW1009CEZZ J Wire Holder (OMEGA Lock) AA
21 LHLDW1046CEZZ J Wire Holder (OMEGA Lock) AA
22 LHLDWA023WJKZ J Wire Holder, x2 AC
23 LHLDWA048WJKZ J Wire Holder (SP Wire)
24 PRDARA263WJFW J Heat Sink C
25 PSHEPA400WJZZ J Spacer, x4 (Side B)
26 PSLDMA710WJFW J HDMI Shield (Top)
27 PSLDMA711WJFW J HDMI Shield (Bottom)
28 PSPAZA848WJKZ J Cooling Sheet (For IC1203)
29 PSLDMA708WJFW J Main Shield (Top)
30 PSLDMA709WJFW J Main Shield (Bottom)
31 PSLDMA712WJN1 J Inverter Shield
32 PSLDMA769WJFW J Tuner Shield
33 PSPAGA243WJZZ J Inverter Cushion, x3 AC
34 PSPAZA844WJKZ J Cooling Sheet (For IC3300)
35 PSPAZA845WJKZ J Cooling Sheet (For IC4101)
36 PSPAZA846WJKZ J Cooling Sheet (For IC4503)
37 QCNCMA201WJZZ J Connecting Cord, AH
MAIN-AV B TO B
38 QCNW-D707WJPZ J Connecting Cord, AH
POW-INV(PD)
39 QCNW-D708WJPZ J Connecting Cord AK
POW-INV(PF)
40 QCNW-D839WJQZ J Connecting Cord, AV-KEY AF
41 QCNW-D840WJQZ J Connecting Cord, AV-R/C AH
42 QCNW-D842WJQZ J Connecting Cord, AL
AV-POWER
43 QCNW-D843WJQZ J Connecting Cord, AP
MAIN-POWER(PB)
44 QCNW-D844WJQZ J Connecting Cord AF
MAIN-POWER(PC)
45 QCNW-D845WJQZ J Connecting Cord, AE
INV_GND-GND
46 QCNW-E117WJQZ J Connecting Cord, AV-SP
47 QPWBMD143WJPZ J FPC, x2 FPC(80PIN) AM
48 RSP-ZA120WJZZ J Speaker Box-L AU
49 RSP-ZA121WJZZ J Speaker Box-R AU
50 LX-BZ3442CEF9 J Screw, x4 (Stand) AB
51 LX-BZA140WJFN J Screw, x4
(CENTER ANG DEC)
