Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
98
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
DUNTKD186FE06(LC-26AF3H/M)
DUNTKD186FE07(LC-26AF3X)
DUNTKD186FE08(LC-32AF3H/M)
DUNTKD186FE10(LC-32AF3X)
DUNTKD186FE04(LC-37AF3H/M)
DUNTKD186FE05(LC-37AF3X)
MAIN Unit (Continued)
R4527 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4528 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R4529 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4530 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4531 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4532 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4533 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4534 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4537 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R4538 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4539 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R4601 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R4602 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R4603 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R4604 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R4605 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R4606 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R4607 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R4608 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4609 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4610 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4651 VRS-CH1JF000JY J 0 1/16W Metal Oxide AA
R4652 VRS-CH1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB1801 RBLN-0254TAZZY J Ferrite Beads AB
FB2001 RBLN-0254TAZZY J Ferrite Beads AB
FB3302 RBLN-0254TAZZY J Ferrite Beads AB
FB3303 RBLN-0254TAZZY J Ferrite Beads AB
FB3304 RBLN-0254TAZZY J Ferrite Beads AB
FB3305 RBLN-0254TAZZY J Ferrite Beads AB
FB3306 RBLN-0254TAZZY J Ferrite Beads AB
FB3309 RBLN-0254TAZZY J Ferrite Beads AB
FB3311 RBLN-0254TAZZY J Ferrite Beads AB
FB3312 RBLN-0254TAZZY J Ferrite Beads AB
FB3313 RBLN-0254TAZZY J Ferrite Beads AB
FB3314 RBLN-0254TAZZY J Ferrite Beads AB
FB3315 RBLN-0254TAZZY J Ferrite Beads AB
FB3316 RBLN-0254TAZZY J Ferrite Beads AB
FB3317 RBLN-0254TAZZY J Ferrite Beads AB
FB3704 RBLN-0254TAZZY J Ferrite Beads AB
FB4101 RBLN-A005WJZZY J Ferrite Beads AA
FB4102 RBLN-A005WJZZY J Ferrite Beads AA
FB4103 RBLN-A005WJZZY J Ferrite Beads AA
FB4104 RBLN-A005WJZZY J Ferrite Beads AA
FB4501 RBLN-0210TAZZY J Ferrite Beads AB
FB4502 RBLN-0210TAZZY J Ferrite Beads AB
FB4503 RBLN-0210TAZZY J Ferrite Beads AB
FB4504 RBLN-0210TAZZY J Ferrite Beads AB
FB4505 RBLN-A005WJZZY J Ferrite Beads AA
FB4601 RBLN-0210TAZZY J Ferrite Beads AB
FB4602 RBLN-0210TAZZY J Ferrite Beads AB
FB4603 RBLN-0210TAZZY J Ferrite Beads AB
P1800 QCNCMA492WJZZ J Connector, 24Pin
(TO POWER UNIT)
P1801 QEARBA005WJFMY J Ground-Part AD
P1802 QEARBA005WJFMY J Ground-Part AD
P1803 QEARBA005WJFMY J Ground-Part AD
P1804 QEARBA005WJFMY J Ground-Part AD
P1805 QEARBA005WJFMY J Ground-Part AD
P2001 QPLGNA144WJZZY J Plug, 20Pin AF
P4101 QPLGNA174WJZZY J Plug, 5Pin AE
(TO INVERTER1 (BL))
SC2001 QSOCNA480WJQZY J Socket, 40Pin AG
SC3701 QCNCWA284WJZZY J Connector, 50Pin(TO AV) AH
SC4651 QSOCNA222WJZZY J Socket, 80Pin AH
SC4652 QSOCNA222WJZZY J Socket, 80Pin AH
LUG1800 QLUGHA009WJZZY J Lug AC
LUG1801 QLUGHA009WJZZY J Lug AC
LUG1802 QLUGHA009WJZZY J Lug AC
LUG1803 QLUGHA009WJZZY J Lug AC
LUG1804 QLUGHA009WJZZY J Lug AC
LUG1806 QLUGHA009WJZZY J Lug AC
LUG1807 QLUGHA009WJZZY J Lug AC
LUG1808 QLUGHA009WJZZY J Lug AC
LUG1809 QLUGHA009WJZZY J Lug AC
LUG1810 QLUGHA009WJZZY J Lug AC
LUG1811 QLUGZA002WJZZY J Lug AC
LUG1812 QLUGZA002WJZZY J Lug AC
