Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
99
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
TUNER
TU1100 RTUNQA021WJZZ J Tuner AW
INTEGRATED CIRCUITS
IC1100 VHiBA7655AF-1Y J BA7655AF AG
IC1103 VHiM62332FP-1Y J M62332FP AL
IC1104 VHiTDA9885+-1Y J TDA9885TS/V3 AP
IC1202 VHiMM1506XN-1Y J MM1506XNRE AD
IC1203 VHiMM1630EQ-1Q J MM1630EQ AT
IC1902 VHi24LC2BiN-1Y J 24LC02B-I/SN AF
IC1904 VHiSii9021+-1Q J SIL9021CTU BC
IC1905 VHiAK4384ET-1Y J AK4384ET AG
IC1906 VHiNJM2750M-1Y J NJM2750M(TE2) AH
IC2500 VHiNJU26901-1Y J NJU26901E2 AS
IC2501 VHiMSP3453G-1Q J MSP3453-QA-B3 BB
IC2502 VHiLVX125FT-1Y J TC74LVX125FT AG
IC2503 VHiT7SET08U1EY J TC7SET08FU(T5L AC
IC2504 VHiNJM4565M-1Y J NJM4565M AE
IC2506 VHiBH3544F+-1Y J BH3544F-E2 AE
IC3900 VHiTDA7480/-1 J TDA7480 AM
IC3901 VHiTDA7480/-1 J TDA7480 AM
IC5700 VHiBA08SFP+-1Y J BA08SFP-E2 AG
IC5701 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC5702 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC5703 VHiPQ1R25++-1Y J PQ1R25 AD
IC5704 VHiPQ033EZ1-1Y J PQ033EZ01ZP AF
IC5705 VHiPQ018EZ5-1Y J PQ018EZ5MZP AF
TRANSISTORS
Q1100 VS2SA1530AR-1Y J 2SA1530AR AB
Q1101 VS2SC2735//1EY J 2SC2735 AC
Q1102 VS2SC2735//1EY J 2SC2735 AC
Q1103 VS2SA1530AR-1Y J 2SA1530AR AB
Q1104 VS2SC3928AR-1Y J 2SC3928AR AB
Q1105 VS2SC3928AR-1Y J 2SC3928AR AB
Q1206 VSDTC314TK/-1Y J DTC314TK AC
Q1207 VSDTC314TK/-1Y J DTC314TK AC
Q1208 VSDTC144EE/-1Y J DTC144EE AA
Q1209 VSDTC144EE/-1Y J DTC144EE AA
Q1210 VSDTC144EE/-1Y J DTC144EE AA
Q1215 VS2SA1530AR-1Y J 2SA1530AR AB
Q1216 VS2SA1530AR-1Y J 2SA1530AR AB
Q1217 VS2SK536///-1Y J 2SK536 AE
Q1218 VS2SK536///-1Y J 2SK536 AE
Q1219 VSDTC144EE/-1Y J DTC144EE AA
Q1220 VSDTC144EE/-1Y J DTC144EE AA
Q1900 VS2SK536///-1Y J 2SK536 AE
Q1901 VS2SK536///-1Y J 2SK536 AE
Q1902 VSDTC144EE/-1Y J DTC144EE AA
Q1903 VSDTC144EE/-1Y J DTC144EE AA
Q1904 VSDTA144EE/-1Y J DTA144EE AA
Q1905 VSDTC144EE/-1Y J DTC144EE AA
Q2500 VS2SC3928AR-1Y J 2SC3928AR AB
Q2501 VSDTC144EE/-1Y J DTC144EE AA
Q3900 VS2SA1530AR-1Y J 2SA1530AR AB
Q3901 VS2SC3928AR-1Y J 2SC3928AR AB
Q3902 VS2SA1530AR-1Y J 2SA1530AR AB
Q3903 VS2SC3928AR-1Y J 2SC3928AR AB
Q3904 VS2SC3928AR-1Y J 2SC3928AR AB
Q3905 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D1100 VHD1SS390++-1Y J 1SS390 AB
D1101 RH-EX0677GEZZY J Zener Diode, 33V AC
D1102 RH-EX0253TAZZY J Zener Diode, 3.3V AC
D1103 VHD1SS390++-1Y J 1SS390 AB
D1104 VHD1SS390++-1Y J 1SS390 AB
DUNTKD304DE07/08/10(LC-26AF3M/H/X)
DUNTKD304DE01/02/03(LC-32AF3M/H/X)
DUNTKD304DE04/05/06(LC-37AF3M/H/X)
AV Unit
D1206 RH-EX0265TAZZY J Zener Diode, 10V AB
D1209 RH-EX0265TAZZY J Zener Diode, 10V AB
D1210 RH-EX0265TAZZY J Zener Diode, 10V AB
D1211 RH-EX0265TAZZY J Zener Diode, 10V AB
D1212 RH-EX0265TAZZY J Zener Diode, 10V AB
D1213 RH-EX0265TAZZY J Zener Diode, 10V AB
D1214 RH-EX0265TAZZY J Zener Diode, 10V AB
D1215 RH-EX0265TAZZY J Zener Diode, 10V AB
D1216 RH-EX0265TAZZY J Zener Diode, 10V AB
D1217 RH-EX0265TAZZY J Zener Diode, 10V AB
D1218 RH-EX0265TAZZY J Zener Diode, 10V AB
D1219 RH-EX0265TAZZY J Zener Diode, 10V AB
D1220 RH-EX0265TAZZY J Zener Diode, 10V AB
D1221 RH-EX0265TAZZY J Zener Diode, 10V AB
D1222 RH-EX0265TAZZY J Zener Diode, 10V AB
D1223 RH-EX0265TAZZY J Zener Diode, 10V AB
D1224 RH-EX0265TAZZY J Zener Diode, 10V AB
D1225 RH-EX0265TAZZY J Zener Diode, 10V AB
D1226 RH-EX0265TAZZY J Zener Diode, 10V AB
D1227 RH-EX0265TAZZY J Zener Diode, 10V AB
D1228 RH-EX0265TAZZY J Zener Diode, 10V AB
D1229 VHDBAS316//-1Y J BAS316 AB
D1230 VHDBAS316//-1Y J BAS316 AB
D1900 VHDSFPB54//2EY J SFPB54 AC
D1901 VHDBAS316//-1Y J BAS316 AB
D1904 RH-EX0267TAZZY J Zener Diode, 12V AB
D1905 RH-EX0267TAZZY J Zener Diode, 12V AB
D1906 VHDBAS316//-1Y J BAS316 AB
D1907 VHDSFPB54//2EY J SFPB54 AC
D3900 VHD1SS390++-1Y J 1SS390 AB
D3901 VHD1SS390++-1Y J 1SS390 AB
D3902 VHD1SS390++-1Y J 1SS390 AB
D3903 VHD1SS390++-1Y J 1SS390 AB
D5700 RH-DXA024WJZZY J Diode AE
D5701 RH-DXA024WJZZY J Diode AE
D5702 RH-DXA024WJZZY J Diode AE
D5703 VHDBAS316//-1Y J BAS316 AB
D5704 VHDBAS316//-1Y J BAS316 AB
D5705 VHDBAS316//-1Y J BAS316 AB
D5706 VHDBAS316//-1Y J BAS316 AB
D5707 VHDBAS316//-1Y J BAS316 AB
D5708 VHDBAS316//-1Y J BAS316 AB
PACKAGED CIRCUITS
X1100 RCRSAA029WJZZ J Crystal AF
X1900 RCRSCA108WJZZY J Crystal 28.322MHz AF
X2500 RCRSB0250GEZZ+ J Crystal 18.432MHz AG
COILS AND FILTERS
FL1200 RFiLN0017TAZZY J Filter AC
FL1201 RFiLN0017TAZZY J Filter AC
FL1202 RFiLN0017TAZZY J Filter AC
FL1203 RFiLN0017TAZZY J Filter AC
FL1204 RFiLN0017TAZZY J Filter AC
FL1205 RFiLN0017TAZZY J Filter AC
FL1206 RFiLN0017TAZZY J Filter AC
FL1207 RFiLN0017TAZZY J Filter AC
FL1208 RFiLN0017TAZZY J Filter AC
FL1209 RFiLN0017TAZZY J Filter AC
FL 1214 RFiLNA118WJZZY J Filter(LC-26AF3H/M/X) AC
FL 1214 RFiLN0023TAZZY Filter
(LC-32AF3H/M/X/37AF3H/M/X)
FL 1215 RFiLNA118WJZZY J Filter(LC-26AF3H/M/X) AC
FL 1215 RFiLN0023TAZZY Filter
(LC-32AF3H/M/X/37AF3H/M/X)
FL 1216 RFiLNA118WJZZY J Filter(LC-26AF3H/M/X) AC
FL 1216 RFiLN0023TAZZY Filter
(LC-32AF3H/M/X/37AF3H/M/X)
FL 1217 RFiLNA118WJZZY J Filter(LC-26AF3H/M/X) AC
FL 1217 RFiLN0023TAZZY Filter
(LC-32AF3H/M/X/37AF3H/M/X)
FL 1218 RFiLNA118WJZZY J Filter(LC-26AF3H/M/X) AC
FL 1218 RFiLN0023TAZZY Filter
(LC-32AF3H/M/X/37AF3H/M/X)
L1102 VPD9M1R2JR66NY J Peaking 1.2µH 5% AB
L1103 VPD9M1R2JR66NY J Peaking 1.2µH 5% AB
