Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
100
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
DUNTKD304DE07/08/10(LC-26AF3M/H/X)
DUNTKD304DE01/02/03(LC-32AF3M/H/X)
DUNTKD304DE04/05/06(LC-37AF3M/H/X)
AV Unit (Continued)
L1104 VPCLN100MR36NY J Peaking 10µH 20%
L1105 VPCLN100MR36NY J Peaking 10µH 20%
L1107 VPD9M330J3R6NY J Peaking 33µH 5% AC
L1900 RCiLFA134WJZZY J Coil AF
L1901 RCiLFA134WJZZY J Coil AF
L1902 RCiLFA134WJZZY J Coil AF
L1903 RCiLFA134WJZZY J Coil AF
L3901 RCiLPA614WJPZ J Coil AD
L3902 RCiLPA614WJPZ J Coil AD
SF1101 RFiLC0445CEZZ J Filter AM
SF1102 RFiLC0444CEZZ J Filter AN
CAPACITORS
C1100 VCERML1EN336MY J 33 25V AC
C1101 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1102 VCCCCY1HH220JY J 22p 50V Ceramic AA
C1103 VCERMZ1CN477MY J 470 16V AE
C1104 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1105 VCERMZ1CN107MY J 100 16V AD
C1106 VCERML1HN107MY J 100 50V AE
C1107 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1108 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1109 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1110 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1111 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1112 VCERML1CN106MY J 10 16V AC
C1113 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1114 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1115 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1116 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1117 RC-KZA073WJZZY J 10 16V Ceramic AD
C1118 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1119 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1120 VCERMZ1VN106MY J 10 35V AC
C1121 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1122 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1123 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1124 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1125 VCERMZ1CN107MY J 100 16V AD
C1126 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1127 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1128 VCCCCY1HH391JY J 390p 50V Ceramic AB
C1129 VCKYTV1CB224KY J 0.22 16V Ceramic AB
C1130 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1131 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C1132 VCERMZ1CN227MY J 220 16V AD
C1134 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C1136 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1137 VCCCCY1HH120JY J 12p 50V Ceramic AA
C1138 VCCCCY1HH8R0DY J 8p 50V Ceramic AA
C1206 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1207 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1208 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1209 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1210 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1212 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1214 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1215 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1216 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1217 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1218 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1219 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1220 VCKYTV1CB105KY J 1 16V Ceramic AC
C1221 VCKYTV1CB105KY J 1 16V Ceramic AC
C1222 VCKYTV1CB105KY J 1 16V Ceramic AC
C1223 VCKYTV1CB105KY J 1 16V Ceramic AC
C1224 RC-KZA073WJZZY J 10 16V Ceramic AD
C1226 RC-KZA073WJZZY J 10 16V Ceramic AD
C1228 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1231 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1237 RC-KZA073WJZZY J 10 16V Ceramic AD
C1238 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1239 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1240 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1241 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1242 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1243 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1244 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1246 RC-KZA073WJZZY J 10 16V Ceramic AD
C1247 RC-KZA073WJZZY J 10 16V Ceramic AD
C1248 RC-KZA073WJZZY J 10 16V Ceramic AD
C1249 RC-KZA073WJZZY J 10 16V Ceramic AD
C1250 RC-KZA073WJZZY J 10 16V Ceramic AD
C1251 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1253 RC-KZA073WJZZY J 10 16V Ceramic AD
C1255 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1256 VCERMZ1CN107MY J 100 16V AD
C1259 RC-KZA073WJZZY J 10 16V Ceramic AD
C1261 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1262 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1263 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1264 VCERML1CN226MY J 22 16V AC
C1266 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1267 VCCCCY1HH101JY J 100p 50V Ceramic AA
C1268 VCKYTV1CB105KY J 1 16V Ceramic AC
C1269 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1270 VCCCCY1HH101JY J 100p 50V Ceramic AA
C1271 VCCCCY1HH100DY J 10p 50V Ceramic AA
C1272 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1273 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1274 VCKYTV1CB105KY J 1 16V Ceramic AC
C1276 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1277 VCKYTV1CB105KY J 1 16V Ceramic AC
C1278 RC-KZA073WJZZY J 10 16V Ceramic AD
C1279 VCKYTV1CB105KY J 1 16V Ceramic AC
C1281 VCERMZ1CN477MY J 470 16V AE
C1282 VCKYTV1CB105KY J 1 16V Ceramic AC
C1284 VCKYTV1CB105KY J 1 16V Ceramic AC
C1285 VCKYTV1CB105KY J 1 16V Ceramic AC
C1286 VCKYTV1CB105KY J 1 16V Ceramic AC
C1287 VCKYTV1CB105KY J 1 16V Ceramic AC
C1288 VCKYTV1CB105KY J 1 16V Ceramic AC
C1289 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1290 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1291 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1292 VCKYTV1CB105KY J 1 16V Ceramic AC
C1293 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1294 VCCCCY1HH330JY J 33p 50V Ceramic AA
C1295 VCKYTV1CB105KY J 1 16V Ceramic AC
C1296 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1297 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1298 VCERML1CN106MY J 10 16V AC
C1299 VCERMZ1CN476MY J 47 16V AC
C1300 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1301 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1302 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1303 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1304 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1305 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1306 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1308 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1309 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1310 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1311 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1903 VCERMZ1CN476MY J 47 16V AC
C1904 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1905 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1906 VCERML1CN106MY J 10 16V AC
C1907 VCAAPE0JJ107MY J 100 6.3V Electrolytic AE
C1908 RC-KZA109WJZZY J 10 16V Ceramic AC
C1909 RC-KZA109WJZZY J 10 16V Ceramic AC
C1910 VCAAPE0JJ107MY J 100 6.3V Electrolytic AE
C1911 VCKYCY1HB102KY J 1000p 50V Ceramic AA
