94 AYOUT O LV Middle level (STANDBY=0)
Luminance output (STANDBY=1)
95 VSSA2 S Supply analog DAC G/Y (0 V)
96 VDDA3 S Supply analog DAC R/V (3.3 V)
97 AVOUT O LV Middle level (STANDBY=0)
Chrominance output (STANDBY=1)
98 VSSA3 S Supply analog DAC R/V (0 V)
99 VSSA4 S Supply analog band gap (0 V)
100 VDDA4 S Supply analogband gap (3.3 V)
101 VSSD5 S Supply digital core (0 V)
102 VDDD5 S Supply digital core (1.8 V)
103 NC NC
104 NC NC
105 SCL I/O I²C bus clk
106 SDA I/O I²C bus data
107 NC NC
108 NC NC
109 VSSP7 S Supply digital pad (0 V)
110 VDDP7 S Supply digital pad (3.3 V)
111 TMS I Connect to
VDD (3.3 V)
Test mode select (3.3 V)
112 NC NC
113 TDO/
SVMOFF
O/I LV Test data out (ACTSVMOFF=1)
SVM input signal (ACTSVMOFF=0)
114 TDI I Connect to
VSS (0 V)
Test data in (0 V)
115 TCLK I Connect to
VDD (3.3 V)
Test clock (3.3 V)
116 INTR O LV Interrupt signal
Static 0 (CPUIRQ2=00)
Static 1 (CPUIRQ2=01)
Interrupt signal output from PC (CPUIRQ2= 1x)
117 656I02 I LV (pull
down)
Digital (luminance) input [LSB]
Pin No. Pin Name Type Connection
(If not used)
Short Description
PMQFP144-4
