141 NC NC
142 656I0/YIN0 I LV (pull
down)
Digital (luminance) input [LSB]
143 VSSP9 S Supply digital pad (0 V)
144 VDDP9 S Supply digital pad (3.3 V)
Pin No. Pin Name Type Connection
(If not used)
Short Description
PMQFP144-4
4.3. Description of Pins IC6004, continued
4.3. Description of Pins IC6004, continued
118 656I12 I LV (pull
down)
Digital (luminance) input
119 656I22 I LV (pull
down)
Digital (luminance) input
120 656I32 I LV (pull
down)
Digital (luminance) input
121 656I42 I LV (pull
down)
Digital (luminance) input
122 656I52 I LV (pull
down)
Digital (luminance) input
123 656I62 I LV (pull
down)
Digital (luminance) input
124 656I72 I LV (pull
down)
Digital (luminance) input
125 CLKIN2 I LV (pull
down)
Clock input [max. 81.0 MHz]
126 UVIN0 I LV (pull
down)
Digital (chrominance) input [LSB]
127 UVIN1 I LV (pull
down)
Digital (chrominance) input
128 UVIN2 I LV (pull
down)
Digital (chrominance) input
129 UVIN3 I LV (pull
down)
Digital (chrominance) input
130 VSSP8 S Supply digital core (0 V)
131 VDDP8 S Supply digital core (3.3 V)
132 VDD8M S Supply memory (1.8 V)
133 VSSD60 S Supply digital core (0 V)
134 VSSD61 S Supply digital core (0 V)
135 VDDD60 S Supply digital core (1.8V)
136 VDDD61 S Supply digital core (1.8 V)
137 UVIN4 I LV (pull
down)
Digital (chrominance) input
138 UVIN5 I LV (pull
down)
Digital (chrominance) input
139 UVIN6 I LV (pull
down)
Digital (chrominance) input
140 UVIN7 I LV (pull
down)
Digital (chrominance) input [MSB]
Pin No. Pin Name Type Connection
(If not used)
Short Description
PMQFP144-4
