LC-26SA1E/RU, LC-32SA1E/RU
7 – 10
1) TTL output version only
2) LVDS output version only
159 P1_7 I/O Port 1, Bit 7 Input/Output IF_AGC
160 P1_6 I/O Port 1, Bit 6 Input/Output SLOW SW1
161 P1_5 I/O Port 1, Bit 5 Input/Output SLOW SW2
162 P1_4 I/O Port 1, Bit 4 Input/Output KEY_ETC
163 GND3.3DAC – Ground DAC GND
164 VSUP3.3DAC – Supply Voltage DAC, 3.3V 3.3V
165 P1_3 I/O Port 1, Bit 3 Input/Output Open
166 P1_2 I/O Port 1, Bit 2 Input/Output Open
167 P1_1 I/O Port 1, Bit 1 Input/Output Open
168 P1_0 I/O Port 1, Bit 0 Input/Output Open
169 VSUP1.8FE – Supply Voltage Analog Video Frontend, 1.8 V 1.8V
170 VSUP3.3FE – Supply Voltage Analog Video Frontend, 3.3 V 3.3V
171 DHS I Digital Video H-sync Input DHSYNC
172 VIN21 I Analog Video 21B HD Input PC_V_B
173 VIN20 I Analog Video 20 G HD Input PC_V_G
174 VIN19 I Analog Video 19 R HD Input PC_V_R
175 VIN18 I Analog Video 18 Fast Blank 2 Input IN2_FSW
176 VIN17 I Analog Video 17 B HD Input BLUE2
177 VIN16 I Analog Video 16 G HD Input GREEN2
178 VIN15 I Analog Video 15 R HD Input RED/C2
179 VIN13 I Analog Video 13 B HD Input D TUNER_B
180 VIN12 I Analog Video 12 G HD Input D_TUNER_G
181 VIN11 I Analog Video 11 R HD Input D_TUNER_R
182 VIN9 I Analog Video 9 Y or B SD Input BLUE1
183 VIN8 I Analog Video 8 C or Fast Blank 1 Input IN3C
184 VIN7 I Analog Video 7 Y or G SD Input IN3Y
185 VSUP1.8FE – Supply Voltage Analog Video Frontend, 1.8 V 1.8V
186 VSUP1.8FE – Analog Video Frontend, Platform Ground GND
187 VIN6 I Analog Video 6 C or R SD Input RED/C1
188 VIN5 I Analog Video 5 Y/CVBS Input GREEN1
189 VIN3 I Analog Video 3 CVBS Input IN1_FSW
190 VIN2 I Analog Video 2 CVBS Input VIN_2
191 VIN1 I Analog Video 1 CVBS Input A_TUNER_CVBS
192 VSUP3.3VO – Supply Voltage Analog Video Output, 3.3 V 3.3V
193 VOUT3 O Analog CVBS Video 3 Output Open
194 VOUT2 O Analog CVBS Video 2 Output CV02 (outV)
195 VOUT1 O Analog CVBS Video 1 Output CV01 (outNV)
196 GND3.3IO3 – Ground Digital Input/Output Port 1 GND
197 VSUP3.3IO3 – Supply Voltage Input/Output Port 1, 3.3 V 3.3V
198 656I0 I Digital 656 Bit 0 Input (LSB) FRCO [0]
199 656I1 I Digital 656 Bit 1 Input FRCO [1]
200 656I2 I Digital 656 Bit 2 Input FRCO [2]
201 656I3 I Digital 656 Bit 3 Input FRCO [3]
202 656I4 I Digital 656 Bit 4 Input FRCO [4]
203 656I5 I Digital 656 Bit 5 Input FRCO [5]
204 656I6 I Digital 656 Bit 6 Input FRCO [6]
205 656I7 I Digital 656 Bit 7 Input FRCO [7]
206 656CLKI I Digital 656 Clock Input FRCCKO
207 656CLKO O Digital 656 Clock Output FRCCKI
208 656O7 O Digital 656 Bit 7 Output FRCI [7]
Pin No. Pin Name I/O Pin Function Sheet Name
To Next Page
