Sharp LC-30HV4U User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
226
LC-30HV4U
LC-30HV4D
DUNTKB658FE01 (LC-30HV4U)
DUNTKB658FE02 (LC-30HV4D)
AV Unit (AVC System) (Continued)
C2515 VCKYCY1HB332KY J 3300p 50V Ceramic AA
C2516 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2517 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2518 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2519 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C2520 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C2521 VCEAPF1HW335MYJ 3.3 50V Electrolytic AC
C2522 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2523 VCKYTV1CB105KY J 1 16V Ceramic AC
C2524 VCKYTV1CB105KY J 1 16V Ceramic AC
C2525 VCKYTV1CB105KY J 1 16V Ceramic AC
C2526 VCKYTV1CB105KY J 1 16V Ceramic AC
C2527 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2528 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2529 VCKYTV1CB105KY J 1 16V Ceramic AC
C2530 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C2531 VCCCCY1HH560JY J 56p 50V Ceramic AB
C2532 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2533 VCCCCY1HH560JY J 56p 50V Ceramic AB
C2534 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2535 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2536 VCEASH1CN477MY J 470 16V Electrolytic AD
C2537 VCKYTV1CB105KY J 1 16V Ceramic AC
C2538 VCKYTV1CB105KY J 1 16V Ceramic AC
C2539 VCKYTV1CB105KY J 1 16V Ceramic AC
C2541 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2542 VCKYTV1CB105KY J 1 16V Ceramic AC
C2543 VCKYTV1CB105KY J 1 16V Ceramic AC
C2544 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2545 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2546 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2547 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2548 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2549 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2550 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C2551 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2552 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2553 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2554 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2556 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C2557 VCCCCY1HH561JY J 560p 50V Ceramic AB
C2558 VCCCCY1HH561JY J 560p 50V Ceramic AB
C2559 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C2560 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2561 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2562 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2563 VCEAPF1HW225MYJ 2.2 50V Electrolytic AB
C2564 VCEAPF1HW225MYJ 2.2 50V Electrolytic AB
C2565 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C2566 VCCCCY1HH561JY J 560p 50V Ceramic AB
C2567 VCKYTV1CB105KY J 1 16V Ceramic AC
C2568 VCKYTV1CB105KY J 1 16V Ceramic AC
C2569 VCCCCY1HH561JY J 560p 50V Ceramic AB
C2570 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C2571 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2572 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2573 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2574 VCKYTV1CB105KY J 1 16V Ceramic AC
C2575 VCKYTV1CB105KY J 1 16V Ceramic AC
C2576 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C2580 VCCCCY1HH5R0CYJ 5p 50V Ceramic AA
C2581 VCCCCY1HH5R0CYJ 5p 50V Ceramic AA
C2582 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2583 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2584 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2585 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2587 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2588 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2589 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2590 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2591 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2592 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2593 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2597 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2598 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C2600 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C2601 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C2602 VCKYTV1CB105KY J 1 16V Ceramic AC
C2603 VCKYTV1CB105KY J 1 16V Ceramic AC
C2604 VCEASH1CN337MY J 330 16V Electrolytic AE
C2605 VCEASH1CN337MY J 330 16V Electrolytic AE
C2606 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2607 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2608 VCCCCY1HH220JY J 22p 50V Ceramic AA
C2609 VCCCCY1HH220JY J 22p 50V Ceramic AA
C5701 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5702 VCEAPF1CW226MYJ 22 16V Electrolytic AB
C5703 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C5704 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5705 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5706 VCEAPF1CW226MYJ 22 16V Electrolytic AB
C5708 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5709 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5710 VCEAPF1CW226MYJ 22 16V Electrolytic AB
C5711 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C5712 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5713 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5714 VCEAPF1CW226MYJ 22 16V Electrolytic AB
C5715 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C5716 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5719 VCEAPF1CW106MYJ 10 16V Electrolytic AB
C5720 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5721 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5722 VCEAPF1CW226MYJ 22 16V Electrolytic AB
C5723 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C5724 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C5725 VCEAPF1CW107MYJ 100 16V Electrolytic AC
C5726 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C5727 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C5728 VCEAPF1CW226MYJ 22 16V Electrolytic AB
RESISTORS
R1101 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R1103 VRS-CY1JF274JY J 270k 1/16W Metal Oxide AA
R1104 VRS-CA1JF680JY J 68 1/16W Metal Oxide AA
R1106 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R1109 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R1110 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R1112 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1113 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1114 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R1115 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1116 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R1117 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R1118 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R1123 VRS-CB1JF223JY J 22k 1/16W Metal Oxide AA
R1124 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1125 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1126 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1127 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1128 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1129 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1130 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R1135 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1136 VRS-CY1JF274JY J 270k 1/16W Metal Oxide AA
R1137 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R1138 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R1139 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R1140 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1141 VRS-CY1JF274JY J 270k 1/16W Metal Oxide AA
R1142 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R1143 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1144 VRS-CY1JF274JY J 270k 1/16W Metal Oxide AA
R1145 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R1146 VRS-TQ2BD750JY J 75 1/8W Metal Oxide AA
R1147 VRS-TX2HF750JY J 75 1/2W Metal Oxide AB
