Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
249
LC-30HV4U
LC-30HV4D
CABINET AND MECHANICAL PARTS
(AVC System)
1
Not Available
– Rear Panel Ass’y —
1-1 LANGTA038WJFW J Rear Panel AM
1-2 HiNDPA396WJSA J Indication Label AP
(LC-30HV4U)
1-2 HiNDPA352WJSA J Indication Label
(LC-30HV4D)
2 CCABAA289WJ01 J Chassis Flame Ass’yBB
2-1
Not Available
– Chassis Flame —
2-2 LANGTA027WJFW J Stand Angle AG
2-3 LHLDW1021GE00 J Wire Holder, x2 AB
2-4 LHLDW1139CEZZ J Wire Holder, x1 AA
2-5 PZETZA008WJZZ J Insulating Sheet AH
2-6 QEARZA020WJFW J Earth Spring, x2 AC
2-7 XJPSN30P08XS0 J Screw, x2 AA
3 CCABBA111WJ01 J Bottom Cabinet Ass’yAY
3-1
Not Available
– Bottom Cabinet —
3-2 GLEGGA012WJZZ J Leg, x4 AD
4 CCABBA180WJ01 J Top Cabinet Ass’yAZ
(LC-30HV4U)
4 CCABBA180WJ02 J Top Cabinet Ass’y
(LC-30HV4D)
4-1
Not Available
– Top Cabinet —
4-2 TCAUHA050WJZZ J Caution Label AE
(LC-30HV4U)
4-2 TCAUHA068WJZZ J Caution Label
(LC-30HV4D)
5
Not Available
– PC I/F Bottom Shield Ass’y —
5-1 LANGTA023WJFW J PC I/F Bottom Shield AP
5-2 LHLDW1021GE00 J Wire Holder, x1 AB
5-3 PFLT-A004WJZZ J Spacer, x1 AE
6 CPNLCA070WJ01 J Front Panel Ass’yBG
(LC-30HV4U)
6 CPNLCA066WJ01 J Front Panel Ass’yBG
(LC-30HV4D)
6-1
Not Available
– Front Panel —
6-2 GCOVAA288WJSA J Door Cover AW
6-3 GDORFA018WJSA J Door AN
6-4 HBDGBA013WJSA J Badge, ”SHARP” AK
6-5 HDECQA166WJSA J LED Cover AF
6-6 HiNDPA290WJSA J Indication Label AH
6-7 JBTN-2074CEKB J Power Button AF
6-8 LANGF9552CESA J Angle, for Door AC
6-9 LANGTA024WJFW J Angle, for Damper AE
6-10 LANGTA047WJFW J Angle AC
6-11 LHLDZ3057GEZZ J Magnet Holder AE
6-12 LHLDZA138WJZZ J Button Holder AD
6-13 LX-BZ3434CEFN J Screw, x2 AB
6-14 MSPRC0210CEFW J Spring, for Power Button AB
6-15 PCOVPA014WJSA J Door Cover AK
6-16 PDMPFA001WJZZ J Damper AG
6-17 PSPAZ0457CESA J Spacer, for Door, x2 AA
6-18 XBPSD20P05000 J Screw, x2 AA
6-19 XEBSD30P08000 J Screw, x4 AA
7
Not Available
– PC I/F Top Shield Ass’y —
7-1 PSLDMA157WJFW J PC I/F Top Shield AS
7-2 PSPAKA019WJZZ J Spacer AF
8
Not Available
– Earth Angle Ass’y —
8-1 LANGTA001WJZZ J Earth Angle Ass’yAF
8-2 PMLT-A001WJZZ J Spacer, x1 AE
8-3 QEARZA010WJZZ J Conductive Spacer, x2 AK
9 GCOVAA243WJSA J Side Cover(L) AN
10 GCOVAA244WJSA J Side Cover(R) AN
11 LANGTA022WJFW J MAIN Unit Angle AN
12 LANGTA028WJFW J Inlet Angle AH
13 LANGTA039WJFW J AV Unit Angle AP
14 LHLDW1009CEZZ J Wire Holder, x1 AA
15 LHLDW1033CE00 J Wire Holder, x1 AA
16 LHLDW1060CEZZ J Wire Holder, x2 AB
17 LHLDW1121GEZZ J Wire Holder, x1 AB
18 LHLDZ2156CEN2 J Fan Holder AH
19 LX-BZ3434CEFN J Screw, x2 AB
20 LX-NZ3047GEZZ J Tuner Nut, x3 AA
21 NFANR0120CEZZ J Cooling Fan AU
22 NSFTZ0134CEFW J Shaft Screw, x8 AD
23 PSLDMA144WJFW J Earth Shield AQ
24 PSPAZA121WJKZ J Radiating Spacer AT
25 PSPAZA122WJKZ J Radiating Spacer AK
26 DUNTKB401FE07 – MAIN Unit —
27 DUNTKB493FE07 – POWER Unit (LC-30HV4U) —
27 DUNTKB493FE08 – POWER Unit (LC-30HV4D) —
28 DUNTKB593DE30 – FRONT Unit (LC-30HV4U) —
28 DUNTKB593DE31 – FRONT Unit (LC-30HV4D) —
29 DUNTKB594DE30 – SR Unit (LC-30HV4U) —
29 DUNTKB594DE31 – SR Unit (LC-30HV4D) —
30 DUNTKB658FE01 – AV Unit (LC-30HV4U) —
30 DUNTKB658FE02 – AV Unit (LC-30HV4D) —
31 CPCi-A005WJ55 – PC I/F Unit (LC-30HV4U) —
31 CPCi-A005WJ57 – PC I/F Unit (LC-30HV4D) —
32 QCNW-A827WJZZ J Connecting Cord AD
33 QCNW-A847WJZZ J Connecting Cord(Main-AV) AD
34 QCNW-A848WJZZ J Connecting Cord AD
(Main-PC I/F)
35 QCNW-A849WJZZ J Connecting Cord AC
(Main-PC I/F)
36 QCNW-A833WJZZ J Connecting Cord(AV-Front) AE
37 QCNW-A838WJZZ J Connecting Cord AK
(Front-PC I/F)
38 QCNW-A828WJZZ J Connecting Cord(AV-SR) AK
39 QCNW-A844WJZZ J Connecting Cord AM
(PC I/F-SR)
40 QCNW-A825WJZZ J Connecting Cord AK
(Main-Power)
41 QCNW-A826WJZZ J Connecting Cord AG
(Main-Power)
42 QCNW-A846WJZZ J Connecting Cord AH
(Power-PC I/F)
43 QCNW-A822WJZZ J Connecting Cord(Main-AV) AF
44 QCNW-A823WJZZ J Connecting Cord(Main-AV) AM
45 QCNW-A824WJZZ J Connecting Cord(Main-AV) AQ
46 QEARZ0056CEFW J Earth Angle, x4 AC
47 CEARZA023WJ01 J Earth Angle, x1
48 CEARZA024WJ01 J Earth Angle, x1
50
Not Available
– Serial No. Label —
51 XBBSN30P06000 J Screw, x2 AA
52 XBPSN30P06000 J Screw, x6 AA
53 XBPSN40P06J00 J Screw, x1 AA
54 XEBSF30P08000 J Screw, x6 AA
55 XJPSN30P08XS0 J Screw, x53 AA
