Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
229
LC-30HV4U
LC-30HV4D
DUNTKB658FE01 (LC-30HV4U)
DUNTKB658FE02 (LC-30HV4D)
AV Unit (AVC System) (Continued)
R2603 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R2619 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2620 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R5701 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5702 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5704 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R5706 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R5718 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5719 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R5726 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R5728 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5729 VRS-CY1JF561JY J 560 1/16W Metal Oxide AA
R5730 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5731 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5732 VRS-CR3AD330JY J 33 1W Metal Oxide
R5733 RR-XZA001WJZZY J 1 1/4W Fuse Resistor AD
(RF732ETTD1R0J)
R5734 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R5735 RR-XZA001WJZZY J 1 1/4W Fuse Resistor AD
(RF732ETTD1R0J)
MISCELLANEOUS PARTS
FB1401 RBLN-0061TAZZY J Ferrite Bead AD
FB1402 RBLN-0061TAZZY J Ferrite Bead AD
FB1602 RBLN-0064TAZZY J Ferrite Bead AB
FB1650 RBLN-0060TAZZY J Ferrite Bead AB
FB1651 RBLN-0060TAZZY J Ferrite Bead AB
FB1652 RBLN-0060TAZZY J Ferrite Bead AB
FB1653 RBLN-0060TAZZY J Ferrite Bead AB
FB1654 RBLN-0060TAZZY J Ferrite Bead AB
FB1655 RBLN-0060TAZZY J Ferrite Bead AB
FB1656 RBLN-0060TAZZY J Ferrite Bead AB
FB1657 RBLN-0060TAZZY J Ferrite Bead AB
FB1658 RBLN-0006TAZZY J Ferrite Bead AB
FB2508 RBLN-0060TAZZY J Ferrite Bead AB
FB2509 RBLN-0210TAZZY J Ferrite Bead AB
FB5701 RBLN-0210TAZZY J Ferrite Bead AB
FB5702 RBLN-0210TAZZY J Ferrite Bead AB
FB5704 RBLN-0210TAZZY J Ferrite Bead AB
FB5706 RBLN-0210TAZZY J Ferrite Bead AB
FB5708 RBLN-0210TAZZY J Ferrite Bead AB
J1103 QTANJ0974CEZZ J AV Terminal AL
J1104 QTANJ0974CEZZ J AV Terminal AL
P1101 QTiPM0083CEZZ J Tip(GND) AB
P1301 QPLGN0435FJZZ J Plug, 26-pin AD
P2502 QPLGNA043WJZZ J Plug, 4-pin AB
P2504 QPLGN0572FJZZY J Plug, 10-pin AE
P2505 QCNCMA064WJZZ J Connector, 15-pin AD
P5701 QPLGN0546FJZZY J Plug, 9-pin AE
P5702 QPLGN0378GEZZ J Plug, 3-pin AB
SC1101 QSOCD0834CEZZ J Socket(S-VIDEO) AH
SC1102 QSOCD0834CEZZ J Socket(S-VIDEO) AH
SC1402 QSOCN0493FJZZY J Socket, 45-pin AG
SC1650 QSOCZA017WJZZ J DVI-Digital Unput Terminal AM
LUG1101 QLUGHA001WJZZY J Lug AD
LUG1102 QLUGHA001WJZZY J Lug AD
LUG1103 QLUGHA001WJZZY J Lug AD
LUG1104 QLUGHA001WJZZY J Lug AD
LUG1105 QLUGHA001WJZZY J Lug AD
TP1101 QLUGP0110TAFWY J Lug AB
TP1102 QLUGP0110TAFWY J Lug AB
PSLDMA148WJFM J Shield
QCNW-A822WJZZ J Connecting Cord(Main-AV) AF
QCNW-A823WJZZ J Connecting Cord(Main-AV) AM
QCNW-A824WJZZ J Connecting Cord(Main-AV) AQ
CPCi-A005WJ55 (LC-30HV4U)
CPCi-A005WJ57 (LC-30HV4D)
PC I/F Unit (AVC System)
INTEGRATED CIRCUITS
IC10001 RH-iX3270CEZZ J HD6417709 BH
IC10002 9DK001-15061 J PST600IM AL
IC10003 9DK001-11025 J AT24C128N-10SI-2.7 AT
IC10004 9DK001-15079 J CXA3506R BN
IC10007 9DK001-15038 J PQ05TZ11 AR
IC10008 9DK001-15071 J PQ20VZ11 AL
IC10019 9DK001-15060 J PST623XW AP
IC10025 RH-iXA091WJZZQ J CVIC2 BX
IC10027 RH-iXA431WJZZQ J LH28F320BFE-PTTL80 BA
IC10028 9DK001-11027 J MSM51V18165F-60TS-K AX
IC10053 9DK001-12079 J 74LVX86MTC AG
IC10310 9DK001-15082 J TLC5733A BC
IC10316 9DK001-15053 J TL431CPS AL
IC10319 9DK001-11029 J EM61V232TSB-6T AZ
IC10320 9DK001-11029 J EM61V232TSB-6T AZ
IC10321 9DK001-11029 J EM61V232TSB-6T AZ
IC10322 9DK001-11029 J EM61V232TSB-6T AZ
IC10327 9DK001-15084 J NJM4560M AK
IC10328 9DK001-15054 J TLC2933IPW AX
IC10400 9DK001-12079 J 74LVX86MTC AG
IC10402 9DK001-12105 J 74LVX125MTC AK
IC10404 9DK001-12105 J 74LVX125MTC AK
IC10405 9DK001-15107 J uPD4721G AS
IC10408 9DK001-12085 J HD74HCT244T AL
IC10410 9DK001-12085 J HD74HCT244T AL
IC10411 9DK001-12103 J 74LCX157MTC AK
IC10412 9DK001-15093 J PQ1R33 AP
IC10415 9DK001-15109 J BA09FP AN
IC10419 9DK001-12102 J TC7WH123FK AM
IC10420 9DK001-12108 J TC7WT126FU AL
IC10422 9DK001-12070 J HD74HCT125T AL
Note: When replace the following parts, PWB replacement
correspondence.
IC10413 — – SII170 —
TRANSISTORS
Q10012 9DK001-20025 J IMB3A AE
Q10013 9DK001-20011 J 2SC2412KQ AE
Q10015 9DK001-20012 J 2SA1037AKQ AE
Q10102 9DK001-20036 J NDC7002N AL
Q10103 9DK001-20011 J 2SC2412KQ AE
Q10104 9DK001-20011 J 2SC2412KQ AE
Q10105 9DK001-20011 J 2SC2412KQ AE
Q10107 9DK001-20011 J 2SC2412KQ AE
Q10108 9DK001-20011 J 2SC2412KQ AE
Q10109 9DK001-20011 J 2SC2412KQ AE
Q10110 9DK001-20011 J 2SC2412KQ AE
Q10111 9DK001-20012 J 2SA1037AKQ AE
Q10112 9DK001-20012 J 2SA1037AKQ AE
Q10113 9DK001-20012 J 2SA1037AKQ AE
Q10114 9DK001-20011 J 2SC2412KQ AE
Q10117 9DK001-20011 J 2SC2412KQ AE
Q10118 9DK001-20011 J 2SC2412KQ AE
Q10119 9DK001-20011 J 2SC2412KQ AE
Q10120 9DK001-20036 J NDC7002N AL
DIODES
D10009 9DK001-30018 J 1SS187 AD
D10020 9DK001-30018 J 1SS187 AD
D10050 9DK001-30015 J MA157A AE
D10051 9DK001-30015 J MA157A AE
D10054 9DK001-30022 J MA3120WA AG
D10055 9DK001-30022 J MA3120WA AG
D10056 9DK001-30022 J MA3120WA AG
D10057 9DK001-30022 J MA3120WA AG
D10070 9DK001-30020 J 1SS355 AD
D10071 9DK001-30020 J 1SS355 AD
D10072 9DK001-30020 J 1SS355 AD
D10073 9DK001-30021 J 1SS400 AE
D10075 9DK001-30018 J 1SS187 AD
