Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
233
LC-30HV4U
LC-30HV4D
CPCi-A005WJ55 (LC-30HV4U)
CPCi-A005WJ57 (LC-30HV4D)
PC I/F Unit (AVC System) (Continued)
R11033 9DK001-50177 J 1k 1/16W Chip1608 AA
R11034 9DK001-50186 J 22k 1/16W Chip1608 AA
R11035 9DK001-50212 J 100k 1/16W Chip1608 AA
R11036 9DK001-50177 J 1k 1/16W Chip1608 AA
R11037 9DK001-50186 J 22k 1/16W Chip1608 AA
R11038 9DK001-50212 J 100k 1/16W Chip1608 AA
R11042 9DK001-50177 J 1k 1/16W Chip1608 AA
R11043 9DK001-50177 J 1k 1/16W Chip1608 AA
R11044 9DK001-50177 J 1k 1/16W Chip1608 AA
R11045 9DK001-50174 J 560 1/16W Chip1608 AA
R11048 9DK001-50161 J 47 1/16W Chip1608 AA
R11049 9DK001-50161 J 47 1/16W Chip1608 AA
R11050 9DK001-50161 J 47 1/16W Chip1608 AA
R11051 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11052 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11053 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11054 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11055 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11056 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11058 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11059 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11060 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11061 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11062 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11076 9DK001-51030 J 10k 1/16W
Resistor Array AD
R11077 9DK001-50282 J 220 1/16W Chip1608 AA
R11077 9DK001-50177 J 1k 1/16W Chip1608 AA
R11079 9DK001-51039 J 56 1/16W Resistor Array AD
R11080 9DK001-50149 J 0 1/16W Chip1608 AB
R11081 9DK001-50149 J 0 1/16W Chip1608 AB
R11081 9DK001-50149 J 0 1/16W Chip1608 AB
R11082 9DK001-50159 J 22 1/16W Chip1608 AA
R11083 9DK001-50177 J 1k 1/16W Chip1608 AA
R11084 9DK001-50185 J 10k 1/16W Chip1608 AA
R11085 9DK001-50185 J 10k 1/16W Chip1608 AA
R11089 9DK001-50165 J 100 1/16W Chip1608 AA
R11099 9DK001-50149 J 0 1/16W Chip1608 AB
R11101 9DK001-51039 J 56 1/16W Resistor Array AD
R11102 9DK001-51039 J 56 1/16W Resistor Array AD
R11104 9DK001-50165 J 100 1/16W Chip1608 AA
R11106 9DK001-50185 J 10k 1/16W Chip1608 AA
R11109 9DK001-50149 J 0 1/16W Chip1608 AB
R11110 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11126 9DK001-50088 J 10 1/4W Chip1608 AB
R11127 9DK001-50185 J 10k 1/16W Chip1608 AA
R11128 9DK001-50161 J 47 1/16W Chip1608 AA
R11129 9DK001-50185 J 10k 1/16W Chip1608 AA
R11130 9DK001-50185 J 10k 1/16W Chip1608 AA
R11131 9DK001-50185 J 10k 1/16W Chip1608 AA
R11132 9DK001-50165 J 100 1/16W Chip1608 AA
R11134 9DK001-50161 J 47 1/16W Chip1608 AA
R11135 9DK001-50185 J 10k 1/16W Chip1608 AA
R11201 9DK001-50165 J 100 1/16W Chip1608 AA
R11202 9DK001-50149 J 0 1/16W Chip1608 AB
MISCELLANEOUS PARTS
FB10016 9DK001-50110 J 0 1/10W Chip2125 AB
FB10018 9DK001-50110 J 0 1/10W Chip2125 AB
FB10019 9DK001-50110 J 0 1/10W Chip2125 AB
FB10050 9DK001-81060 J Ferrite Bead AF
FB10051 9DK001-81060 J Ferrite Bead AF
FB10052 9DK001-81060 J Ferrite Bead AF
FB10053 9DK001-81060 J Ferrite Bead AF
S10001 9DK001-70012 J SSSS812-B-2B AL
CN10003 9DK001-60078 J DVI Connector AQ
CN10008 9DK001-60070 J Connector, 12pin AH
CN10009 9DK001-60071 J Connector, 13pin AH
CN10001 9DK001-60074 J Connector, 15pin AL
CN10005 9DK001-60066 J D-Sub, 9pin AT
CN10006 9DK001-60067 J Connector, 30pin AK
CN10007 9DK001-60058 J Connector, 50pin AS
TP10004 9DK001-84014 J Lug AE
DUNTKA658FE13 (LC-30HV4U)
DUNTKA658FE12 (LC-30HV4D)
LCD CONTROL Unit (Display)
INTEGRATED CIRCUITS
IC4101 VHiMB8346BV-1Y J MB88346BPFV AN
IC4102 VHiMB8346BV-1Y J MB88346BPFV AN
IC4103 VHiNJM2060V-1Y J NJM2060V AF
IC4104 VHiNJM2060V-1Y J NJM2060V AF
IC4105 VHiNJM2060V-1Y J NJM2060V AF
IC4106 VHiNJM2060V-1Y J NJM2060V AF
IC4107 VHiNJM2060V-1Y J NJM2060V AF
IC4108 VHiNJM2060V-1Y J NJM2060V AF
IC4109 VHiLM6134BX-1Y J LM6134BIMX AQ
IC4110 VHiLM6134BX-1Y J LM6134BIMX AQ
IC4111 VHiNJM4580V-1Y J NJM4580V AE
IC4112 VHiPQ20VZ11-1Y J PQ20VZ11 AG
IC4513 VHiTC74AC8T-1Y J TC74AC08FT AF
IC4514 VHiTC74AC8T-1Y J TC74AC08FT AF
IC4515 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC4516 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC4551 RH-iX3493CEZZQ J EPF10K100EQC BE
IC4554 RH-iXA302WJN1Q J EPC2TC32 AV
IC4555 VHiLT1615ES-1Y J LT1615ES5 AP
IC4556 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC4557 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC4558 VHiLT1617ES-1Y J LT1617ES5 AP
IC4559 VHiLTC1872+-1Y J LTC1872ES6 AR
IC4560 VSSi4884DY+-1Y J SI4884DY-T1 AG
IC4701 RH-iX3493CEZZQ J EPF10K100EQC BE
IC4702 RH-iX3636CEZZQ J MS81V10160-12 BC
IC4704 RH-iXA391WJN1Q J EPC2TC32 AV
IC4901 RH-iX3493CEZZQ J EPF10K100EQC BE
IC4902 RH-iX3636CEZZQ J MS81V10160-12 BC
IC4903 VHiTC74AC8T-1Y J TC74AC08FT AF
IC4904 RH-iXA390WJN1Q J EPC2TC32 AV
TRANSISTORS
Q4101 VS2SD1664Q/-1Y J 2SD1664Q AC
Q4103 VS2SC3928AR-1Y J 2SC3928AR AB
Q4105 VSDTC114YE/-1Y J DTC114YE AB
Q4551 VS2SK1826++-1Y J 2SK1826++ AC
Q4553 VS2SK1826++-1Y J 2SK1826++ AC
Q4554 VS2SA1530AR-1Y J 2SA1530AR AB
Q4555 VS2SC3928AR-1Y J 2SC3928AR AB
Q4556 VS2SC3928AR-1Y J 2SC3928AR AB
Q4557 VSTP0610T++-1Y J TP0610T++ AD
Q4650 VS2SA1530AR-1Y J 2SA1530AR AB
DIODES
D4102 VHDDAN222//-1Y J Diode AA
D4103 VHDSC8024//-1Y J Diode AC
D4104 VHDSC8024//-1Y J Diode AC
D4106 VHDHSU119//-1Y J Diode AB
D4501 VHDSFPB54//2EY J Diode AC
D4502 VHDSFPB54//2EY J Diode AC
D4551 VHDHSU119//-1Y J Diode AB
D4552 VHDHSU119//-1Y J Diode AB
D4556 VHDSFPB54//2EY J Diode AC
D4557 VHD1SS355//-1Y J Diode AB
D4558 VHDHSU119//-1Y J Diode AB
D4559 VHDSFPB74//2EY J Diode AD
D4560 VHDSFPB54//2EY J Diode AC
D4561 VHDSFPB74//2EY J Diode AD
D4562 RH-EX1274CEZZY J Zener Diode, 13V AB
D4563 VHDHSU119//-1Y J Diode AB
D4564 VHDHSU119//-1Y J Diode AB
FILTERS AND COILS
FL4501 RFiLNA002WJZZY J Filter AD
FL4502 RFiLNA002WJZZY J Filter AD
FL4503 RFiLNA002WJZZY J Filter AD
FL4505 RFiLNA002WJZZY J Filter AD
FL4506 RFiLNA002WJZZY J Filter AD
FL4510 RFiLNA021WJZZY J Filter AE
