Sharp LC-32GD8EE - Parts Listing; Replacement Parts List

149
LC-26GA5E
LC-32GA5E
LC-32GD8E/RU
LC-32BT8E/RU
LC-37GD8E/RU
LC-37BT8E/RU
LC-32/37GD8E/RU
LC-32/37BT8E/RU
MARK *: SPARE PARTS DELIVERY SECTION
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
R1LK315T3LF15 32" LCD Panel Module Unit R
R1LK370T3LZ5BX 37" LCD Panel Module Unit R
EZ EZ
DUNTKD890FM06 MAIN Unit (LC-32GD8E/RU, LC-32BT8E/RU) R
DUNTKD890FM07 MAIN Unit (LC-37GD8E/RU, LC-37BT8E/RU) R
DUNTKD604FM10 AV Unit R
DUNTKD605FM14 POWER Unit (LC-32GD8E/RU, LC-32BT8E/RU) R
DUNTKD605FM03 POWER Unit (LC-37GD8E/RU, LC-37BT8E/RU) R
DUNTKD606FMV0 KEY Unit R
DUNTKD607FMV0 R/C,LED Unit R
CKITKD609FM01 DIGITAL TUNER Unit S AY BN
DUNTKD628FM01 DIGITAL Unit R
IC1701 VHIBU4239G+-1Y BU4239G-TR
D AE AE
IC1702 VHIPQ20WZ11-1Y PQ20WZ1UJ00H
D AF AF
IC1703 VHIPQ20WZ11-1Y PQ20WZ1UJ00H
D AF AF
IC1704 VSSSM6J51TU-1Y SSM6J51TU(TE85L,F)
D AF AF
IC1705 VSSSM6J51TU-1Y SSM6J51TU(TE85L,F)
D AF AF
IC1706 VHIMP1410ES-1Y MP1410ES-LF-Z
D AP AP
IC1707 VHIPQ20WZ11-1Y PQ20WZ1UJ00H
D AF AF
IC1708 VHIMP1410ES-1Y MP1410ES-LF-Z
D AP AP
IC1709 VSSSM6J51TU-1Y SSM6J51TU(TE85L,F)
D AF AF
IC1710 RH-IXB823WJZZQ EPM240T100C5N
D AR AR
IC1711 VHIPQ1R50//-1Y PQ1R50J0000H
D AF AF
IC1901 VHI24LC2BIN-1Y 24LC02BT-I/SN
D AF AF
IC1905 VHISII9021+-1Q SII9021CTU
D BC BC
IC2301 VHIISL83220-1Y ISL83220ECVZ-T
D AQ AQ
IC2303 VHIBR24C21F-1Y BR24C21F-E2
D AG AG
IC2701 VHITVHC153T-1Y TC74VHC153FT(EL,M)
D AE AE
IC2702 VHIMM1507XN-1Y MM1507XNRE
D AD AD
IC2704 VHICD4052BP-1Y CD4052BPWR
D AD AD
IC2705 VHIMM1507XN-1Y MM1507XNRE
D AD AD
IC3001 VHIBR24L64F-1Y BR24L64F-WE2
D AK AK
IC3002 RH-IXB624WJN1Q VCT6973
D
IC3003 RH-IXB664WJZZY PIC16F913-I/SS-G-GW902T
D AY AY
IC3005 VHIBU4215G+-1Y BU4215G-TR
D AE AE
Q1703 VS2SC3928AR-1Y 2SC3928AR D AB AB
Q1704 VS2SC3928AR-1Y 2SC3928AR D AB AB
Q1705 VS2SA1530AR-1Y 2SA1530AR D AB AB
DUNTKD890FM07 (LC-37GD8E/RU,LC-37BT8E/RU)
TRANSISTORS
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
LCD PANEL
PRINTED WIRING BOARDS
DUNTKD890FM06 (LC-32GD8E/RU,LC-32BT8E/RU)
MAIN Unit
INTEGRATED CIRCUITS
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
Q1901 VS2SK536///-1Y 2SK536 D AE AE
Q1903 VS2SK536///-1Y 2SK536 D AE AE
Q1905 VSDTC144EE/-1Y DTC144EE D AA AA
Q1907 VSDTC144EE/-1Y DTC144EE D AA AA
Q1909 VSDTC144EE/-1Y DTC144EE D AA AA
Q2702 VS3LN01S///-1Y 3LN01S D AC AC
Q2703 VS2SC3928AR-1Y 2SC3928AR D AB AB
Q2704 VS2SC3928AR-1Y 2SC3928AR D AB AB
Q2705 VS2SC3928AR-1Y 2SC3928AR D AB AB
Q2706 VS2SC3928AR-1Y 2SC3928AR D AB AB
Q2707 VSDTC144EE/-1Y DTC144EE D AA AA
Q2708 VSDTC144EE/-1Y DTC144EE D AA AA
Q2709 VS3LN01S///-1Y 3LN01S D AC AC
Q2710 VS3LN01S///-1Y 3LN01S D AC AC
Q3003 VS3LN01S///-1Y 3LN01S D AC AC
Q3004 VS3LN01S///-1Y 3LN01S D AC AC
D1702 RH-EX0487CEZZY HZM2.0NBTL-E D AC AC
D1703 VHDHSU119//-1Y HSU119TRF-E D AB AB
D1704 VHDSFPA73//2EY SFPA-73VL D AD AD
D1705 VHDHSU119//-1Y HSU119TRF-E D AB AB
D1706 VHDHSU119//-1Y HSU119TRF-E D AB AB
D1707 RH-EX0487CEZZY HZM2.0NBTL-E D AC AC
D1708 VHDSFPA73//2EY SFPA-73VL D AD AD
D1901 VHDDAN202K/-1Y DAN202KT146 D AB AB
D1903 VHD1SS355//-1Y 1SS355TE-17 D AB AB
D1905 VHD1SS355//-1Y 1SS355TE-17 D AB AB
D2301 RH-EX1271CEZZY Zener Diode, 12V D AB AB
D2302 RH-EX1271CEZZY Zener Diode, 12V D AB AB
D2303 RH-EX1271CEZZY Zener Diode, 12V D AB AB
D2304 RH-EX1271CEZZY Zener Diode, 12V D AB AB
D2305 RH-EX1247CEZZY Zener Diode, 5.6V D AB AB
D2306 RH-EX1247CEZZY Zener Diode, 5.6V D AB AB
D2307 RH-EX1247CEZZY Zener Diode, 5.6V D AB AB
D2308 RH-EX1247CEZZY Zener Diode, 5.6V D AB AB
D2309 VHDDAN202K/-1Y DAN202KT146 D AB AB
D2310 VHD1SS226//-1Y 1SS226(T5L,F,T) D AC AC
D2311 VHD1SS226//-1Y 1SS226(T5L,F,T) D AC AC
D2312 VHD1SS226//-1Y 1SS226(T5L,F,T) D AC AC
D2313 RH-EX1247CEZZY ZENER DIODE, 5.6V D AB AB
TH3002 VHHM1103J03-1Y Thermistor D AC AC
X1901 RCRSCA108WJZZY Crystal D AF AF
X3001 RCRSC0012CEZZY Crystal D AH AH
FL2301 RFILN0003TAZZY Filter D AD AD
FL2302 RFILN0003TAZZY Filter D AD AD
FL2303 RFILN0003TAZZY Filter D AD AD
L1701 RCILPA213WJZZY Coil D AG AG
L1702 RCILPA213WJZZY Coil D AG AG
L1901 RCILFA134WJZZY Coil D AF AF
L1902 RCILFA134WJZZY Coil D AF AF
L1903 RCILFA134WJZZY Coil D AF AF
L1904 RCILFA134WJZZY Coil D AF AF
L2301 RCILFA071WJZZY Coil D AD AD
L2302 RCILFA071WJZZY Coil D AD AD
L2303 RCILFA071WJZZY Coil D AD AD
L2304 RCILFA071WJZZY Coil D AD AD
L2305 RCILFA071WJZZY Coil D AD AD
L2701 VPCUN1R5MR12NY Peaking 1.5
�H D
C1702 VCKYCY1EF104ZY 0.1 25V Ceramic
D AA AA
C1706 RC-KZA070WJZZY 22 6.3V Ceramic
D AD AD
C1711 VCKYCY1HB103KY 0.01 50V Ceramic
D AA AA
C1715 VCEASX1VN226MY 22 35V Electrolytic
D AC AC
DIODES
PACKAGED CIRCUITS
CAPACITORS
COILS AND FILTERS
PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identifi ed in this manual.
Electrical components having such features are identifi ed by in the Replacement Parts
Listing.
The use of a substitute replacement part which does not have the same safety characteristics
as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock fi re, or other hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
!
