Sharp LC-32GD8EE - Page 156

156
LC-26GA5E
LC-32GA5E
LC-32/37GD8E/RU
LC-32/37BT8E/RU
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
FB1101 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1102 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1103 RBLN-0077TAZZY Ferrite Beads R AB AB
FB1104 RBLN-0077TAZZY Ferrite Beads R AB AB
FB1105 RBLN-0051TAZZY Ferrite Beads R AC AC
FB1106 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1107 RBLN-0051TAZZY Ferrite Beads R AC AC
FB1108 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1109 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1110 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1111 RBLN-0051TAZZY Ferrite Beads R AC AC
FB1112 RBLN-0051TAZZY Ferrite Beads R AC AC
FB1201 RBLN-0051TAZZY Ferrite Beads R AC AC
FB1202 RBLN-0051TAZZY Ferrite Beads R AC AC
FB1203 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1204 RBLN-0062TAZZY Ferrite Beads R AB AB
FB1213 RBLN-0210TAZZY Ferrite Beads R AB AB
FB1218 RBLN-0254TAZZY Ferrite Beads R AB AB
J1101 QSOCZA116WJZZ Socket, 42pin R
J1201 QJAKZA033WJZZ Jack, 16pin (INPUT3) R
J1301 QJAKJA007WJZZ Jack 7pin (HEAD PHONE OUT) R AD AD
LUG301 QLUGHA009WJZZY Lug R AC AC
LUG302 QLUGHA009WJZZY Lug R AC AC
LUG303 QLUGHA009WJZZY Lug R AC AC
LUG304 QLUGHA009WJZZY Lug R AC AC
P301 QPLGNA173WJZZY Plug, 4pin (SP) R AD AD
P1101 QCNCMA250WJZZ Connector, 23pin (to MAIN2) R AE AE
P1102 QCNCMA250WJZZ Connector, 23pin (to MAIN2) R AE AE
P1201 QCNCMA250WJZZ Connector, 23pin (to MAIN2) R AE AE
SC301 QSOCZ0738CEZZ Socket, 7pin (to POWER) R AE AE
IC704 VHiMR4030++-1 MR4030-7101 R
IC705 VHiMR4020++-1 MR4020-7101 R
IC706 VHiTA76431R-1Y TA76431FR(TE12) R
IC707 VHiTA76431R-1Y TA76431FR(TE12) R
IC708 VHiNJM2904M-1Y NJM2904M R AE AE
IC709 VHiNJM2903M-1Y NJM2903M R
Q702 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q704 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q708 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q710 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q712 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q713 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q721 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q723 RH-TXA037WJZZY TXA037WJ
R AE AE
Q724 RH-TXA037WJZZY TXA038WJ
R AE AE
Q726 VS2SC3928AR-1Y 2SC3928AR
R AB AB
Q729 VS2SD2185R+-1Y 2SD2185R
R AF AF
Q730 RH-TXA026WJZZY TXA026WJ
R AD AD
Q731 RH-TXA026WJZZY TXA027WJ
R AD AD
! D701 RH-DX0477CEZZ D5SB60
R AF AF
D707 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D714 RH-EX1398CEZZY UDZSTE-178.2B
R AB AB
DUNTKD604FM10
DIODES
TRANSISTORS
INTEGRATED CIRCUITS
MISCELLANEOUS PARTS
DUNTKD605FM14/03 (LC-32GD8, LC-32BT8 / (LC-37GD8, LC-37BT8)
POWER Unit
AV Unit (Continued)
REF No. PARTS DESCRIPTION *
SN CODE EX CODE
D715 VHDD1FL20U/-1Y D1FL20U
R AC AC
D716 VHDU05NU44+-1Y U05NU44(TE12L,Q)
R AE AE
D717 VHDD1FL20U/-1Y D1FL20U
R AC AC
D718 RH-EXA091WJZZY UDZSTE-1711B
R AB AB
D720 VHDU05NU44+-1Y U05NU44(TE12L,Q)
R AE AE
D721 RH-EXA096WJZZY UDZSTE-1718B
R AB AB
D722 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D724 VHDD1FL20U/-1Y D1FL20U
R AC AC
D725 VHDD1FL20U/-1Y D1FL20U
R AC AC
D726 VHDD1FL20U/-1Y D1FL20U
R AC AC
D728 VHEST03D170-1 ZENER DIODE
R AG AG
D729 VHEST03D170-1 ZENER DIODE
R AG AG
! D730 RH-FXA003WJZZ PC123Y82
R AD AD
! D731 RH-FXA003WJZZ PC123Y82
R AD AD
! D732 RH-FXA003WJZZ PC123Y82
R AD AD
! D733 RH-FXA003WJZZ PC123Y82
R AD AD
! D734 RH-FXA003WJZZ PC123Y82
R AD AD
D735 VHDSF6L20U+-1 SF6L20U
R AG AG
D736 RH-DXA080WJZZ SF20JC10-7100
R AK AK
D737 RH-DXA081WJZZ D15SCA4M-7000
R AH AH
D738 RH-DXA088WJZZY D1FL40-5063
R AD AD
D739 RH-DXA085WJZZ D5S9M-7000
R AK AK
D741 RH-EX1398CEZZY UDZSTE-178.2B
R AB AB
D742 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D746 RH-EXA102WJZZY UDZSTE-1733B
R AB AB
D747 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D748 RH-EXA094WJZZY UDZSTE-1715B
R AB AB
D749 RH-EX1400CEZZY UDZSTE-1710B
R AB AB
D751 RH-EX1398CEZZY UDZSTE-178.2B
R AB AB
D752 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D753 RH-EXA094WJZZY UDZSTE-1715B
R AB AB
D754 RH-EXA101WJZZY UDZSTE-1730B
R AB AB
D755 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D756 RH-EXA101WJZZY UDZSTE-1730B
R AB AB
D757 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D759 RH-EXA101WJZZY UDZSTE-1730B
R AB AB
D761 VHDD1FL20U/-1Y D1FL20U
R AC AC
D762 VHEST03D170-1 ZENER DIODE
R AG AG
D763 RH-EX1394CEZZY ZENER DIODE, 5.6V
R AB AB
D765 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D767 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D771 VHEST03D-82-1 ZENER DIODE
R AG AG
D772 RH-EXA102WJZZY UDZSTE-1733B
R AB AB
D773 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D774 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D775 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D776 RH-EX1234CEZZY ZENER DIODE, 3.6V
R AE AE
D777 VHDU05NU44+-1Y U05NU44(TE12L,Q)
R AE AE
D778 VHDU05NU44+-1Y U05NU44(TE12L,Q)
R AE AE
D779 VHD1SS355//-1Y 1SS355TE-17
R AB AB
D780 RH-EX1015GEZZY PTZTE2516B
R AD AD
D781 RH-EX1015GEZZY PTZTE2516B
R AD AD
D782 RH-EXA359WJZZY ZENER DIODE, 33V
R AE AE
D783 RH-EXA359WJZZY ZENER DIODE, 33V
R AE AE
! TH701 RH-HXA033WJZZ Thermistor
R AG AG
! VA701 RH-VXA071WJQZ ERZV10D471CS
R AD AD
! VA702 RH-VXA071WJQZ ERZV10D471CS
R AD AD
! L701 RCILFA211WJZZ Coil
R AG AG
! L702 RCILF0024PEZZ Coil
R AN AN
THERMISTOR
VARISTOR
COILS AND TRANSFORMERS
