Sharp LC-32GD8EE - Page 164

164
LC-26GA5E
LC-32GA5E
LC-32/37GD8E/RU
LC-32/37BT8E/RU
REF No. PARTS DESCRIPTION * SN CODE EX CODE
1
CCABAB441WJ01 Cabinet A Ass'y (LC32-GD8E/RU)
S -- --
1
CCABAB441WJ02 Cabinet A Ass'y (LC32-BT8E/RU)
S -- --
1_1
Not Available Cabinet A
- -- --
1_2
GCOVAB478WJSA R/C LED Cover
S -- --
1_3
HBDGBA056WJSA Badge, "SHARP"
S -- --
1_4
LHLDW1033PEZZ Wire Holder, x1
R AA AA
1_5
PSPAHA607WJZZ Mask Spacer, x2
S -- --
1_6
PSPAHA608WJZZ Mask Spacer, x2
S -- --
1_7
PSPAHA786WJZZ Spacer, x2
S -- --
1_8
PSPAHA790WJZZ Spacer, x2
S -- --
1_9
PSPAZB211WJZZ Spacer, x4
S -- --
1_10
QCNW-E233WJQZ Connecting Cord
S -- --
1_11
QCNW-E800WJQZ Connecting Cord
S -- --
1_12
RCORF0103CEZZ Ferrite Core, x2
R AK AK
1_13
RSP-ZA184WJN1 Speaker, (L)
S -- --
1_14
RSP-ZA184WJN2 Speaker, (R
�
S -- --
1_15
XEBS930P08000 Screw, x2
R AA AA
1_16
LX-HZA003WJFN Screw, x2
R AC AC
2
CCABBA861WJ01 Cabinet B Ass'y
S AW BK
2_1
Not Available Cabinet B
-
2_2
LHLDWA055WJKZ Wire Holder, x1
R AC AC
3
CCOVAB480WJ01 Top Cover Ass'y
S -- --
3_1
Not Available Top Cover
- -- --
3_2
JBTN-A524WJKA Power Button
S -- --
3_3
JBTN-A525WJKA Operation Button
S -- --
3_4
MSPRCA068WJFW Spring, for Power Button
S -- --
3_5
XEBS930P08000 Screw, x2
R AA AA
4
CDAI-A290WJ01 Stand Support Ass'y (LC32-GD8E/RU)
S -- --
4
CDAI-A290WJ03 Stand Support Ass'y (LC32-BT8E/RU)
S -- --
4_1
Not Available Stand Support
- -- --
4_2
GDAI-A290WJSA Support Cover (LC32-GD)
S -- --
4_2
GDAI-A290WJSC Support Cover (LC32-BT)
S -- --
4_3
HDECQA600WJKA Decoration Cover, x4
S -- --
5
CDAI-A287WJ01 Stand Base Ass'y (LC32-GD8E/RU)
S -- --
5
CDAI-A287WJ05 Stand Base Ass'y (LC32-BT8E/RU)
S -- --
5_1
Not Available Base Cover
- -- --
5_2
LANGKA748WJZZ Base Angle
S -- --
5_3
PSPAZA949WJZZ Leg Cushion A, x4
S -- --
5_4
PSPAZA950WJZZ Leg Cushion B, x4
S -- --
5_5
XEBS740P10000 Screw, x10
S -- --
6
R1LK315T3LF15 32" LCD Panel Module
R
7
GCOVAB488WJKA Stand Cover
S -- --
8
HINDPB760WJSA Model Label (LC32-GD8EE/EK/EF)
S -- --
8
HINDPB761WJSA Model Label (LC32-GD8EI)
S -- --
8
HINDPB762WJSA Model Label (LC32-GD8RU)
S -- --
8
HINDPB791WJSA Model Label (LC32-BT8EE/EK/EF)
S -- --
8
HINDPB792WJSA Model Label (LC32-BT8EI)
S -- --
8
HINDPB793WJSA Model Label (LC32-BT8RU)
S -- --
9
LANGKA638WJFW LCD Angle-A, x2
S -- --
10
LANGKA639WJFW LCD Angle-B, x2
S -- --
11
LANGKA672WJFW LCD Angle-C, x1
S -- --
12
LANGTA263WJFW Center Angle (L)
S -- --
13
LANGTA266WJFW Stand Angle
S -- --
14
LANGTA267WJFW Center Angle (R)
S -- --
15
LCHSMA324WJZZ Chassis Tray
R -- --
16
LHLDW1033CE00 Wire Holder, x1
R AA AA
17
LHLDW1123GEZZ Wire Holder, x1
R AB AB
18
LHLDW1173CEZZ Wire Holder, x2
R AD AD
19
LHLDW1205CEZZ Wire Holder, x2
R AC AC
20
LHLDWA055WJKZ Wire Holder, x1
R AC AC
21
LHLDWA137WJZZ Wire Holder, x2
R AB AB
(LC-32GD8E/RU, LC-32BT8E/RU)
CABINET AND MECHANICAL PARTS LISTING
REF No. PARTS DESCRIPTION * SN CODE EX CODE
22
LHLDW1072GEZZ Wire Holder, x1
R AA AA
23
PCUSGA009WJKZ Cushion Spacer, x1
S -- --
24
PFLT-A004WJZZ Felt Sheet, x4
R AE AE
25
PMLT-A255WJZZ Spacer, x1
R AD AD
26
PMLT-A315WJZZ Spacer, x2
R AP AP
27
PSLDMA584WJZZ Shield, x1
R AE AE
28
PSLDMA770WJZZ Shield, x1
S -- --
29
PSLDMA877WJFW Control PWB Shield, x1
S -- --
30
PSLDMA943WJFW Digital PWB Shield, x1
S -- --
31
PSPAHA902WJZZ Spacer, x2
S -- --
32
DUNTKD890FM06 Main Unit
- -- --
33
DUNTKD604FM10 AV Unit
- -- --
34
DUNTKD605FM01 Power Unit
- -- --
35
DUNTKD628FM01 Digital Unit
- - -
36
CKITKD609FM01 DIGITAL TUNER Unit
S AY BN
37
DUNTKD606FMV0 Operation Unit
- - -
38
DUNTKD607FMV0 R/C, LED Unit
- - -
39
QCNW-E232WJQZ Connecting Cord
R AG AG
40
QCNW-E234WJQZ Connecting Cord
R AH AH
41
QCNW-E237WJPZ Connecting Cord
S -- --
42
QCNW-E799WJQZ Connecting Cord
R
43
QEARPA212WJFW Ground Part
R AE AE
44
QEARZA096WJFW Ground Part
R
45
RCORFA023WJZZ Ferrite Core, x1
R AK AK
46
TLABZB122WJZZ POP Label
S -- --
47
Not Available Serial No Label
- - -
48
LX-WZA042WJZZ Washer, x1
S -- --
49
LX-BZA146WJF7 Screw, x4
S -- --
50
LX-BZA147WJF7 Screw, x4
S -- --
51
XBBS930P06000 Screw, x10
R AA AA
52
XBPS730P06WS0 Screw, x17
R AA AA
53
XBPS830P06000 Screw, x1
R AA AA
54
XEBS930P08000 Screw, x4
S -- --
55
XEBS940P16000 Screw, x11
R AB AB
56
XEBSN40P10000 Screw, x5
R AB AB
57
XJPS730P04WS0 Screw, x2
S -- --
58
XJPS730P08WS0 Screw, x19
R AA AA
59 RCORFA064WJZZ FPC Wire Ferrite Core, x2 D
