Sharp LC-32GD8EE - Page 166

166
LC-26GA5E
LC-32GA5E
LC-32/37GD8E/RU
LC-32/37BT8E/RU
REF No. PARTS DESCRIPTION * SN CODE EX CODE
17
LHLDW1173CEZZ Wire Holder, x3
R AD AD
18
LHLDW1205CEZZ Wire Holder, x2
R AC AC
19
LHLDWA055WJKZ Wire Holder, x1
R AC AC
20
LHLDW1072GEZZ Wire Holder, x1
R
21
PCUSGA009WJKZ Cushion Spacer
22
PFLT-A004WJZZ Felt Sheet, x2
R AE AE
23
PMLT-A255WJZZ Spacer, x1
R AD AD
24
PMLT-A315WJZZ Spacer, x2
R AP AP
25
PSHEFA018WJZZ Sheet, x1
S -- --
26
PSLDMA770WJZZ Shield, x1
S -- --
27
PSLDMA584WJZZ Shield, x1
R AE AE
28
PSLDMA877WJFW Control PWB Shield
S -- --
29
PSLDMA943WJFW Digital PWB Shield
S -- --
30
PSLDMA840WJZZ Shield, x1
R AD AD
31
PSPAHA902WJZZ Spacer, x2
S -- --
32
DUNTKD890FM07 Main Unit
- - -
33
DUNTKD604FM10 AV Unit
- - -
34
DUNTKD605FM03 Power Unit
- - -
35
DUNTKD628FM01 Digital Unit
- - -
36
CKITKD609FM01 DIGITAL TUNER Unit
S AY BN
37
DUNTKD606FMV0 Operation Unit
- - -
38
DUNTKD607FMV0 R/C LED Unit
- - -
39
QCNW-E412WJQZ Connecting Cord
R AG AG
40
QCNW-E415WJQZ Connecting Cord
R AP AP
41
QCNW-E237WJPZ Connecting Cord
S -- --
42
QCNW-E419WJQZ Connecting Cord
R AM AM
43
QCNW-E609WJQZ Connecting Cord
R AH AH
44
QEARPA212WJFW Grounding Part
R AE AE
45
QEARZA096WJFW Grounding Part
S -- --
46
RCORF0103CEZZ Ferrite Core, x2
S AK AK
47
TLABZB122WJZZ POP
�Label
S -- --
48
Not Available Serial No Label
- - -
49
LX-BZA146WJF7 Screw, x4
S -- --
50
LX-BZA147WJF7 Screw, x4
S -- --
51
XBBS930P06000 Screw, x10
R AA AA
52
XBPS730P06WS0 Screw, x17
R AA AA
53
XBPS830P06000 Screw, x1
R AA AA
54
XEBS930P08000 Screw, x4
S AA AA
55
XEBS940P16000 Screw, x11
R AB AB
56
XEBSN40P10000 Screw, x5
R AB AB
57
XJPS730P04WS0 Screw, x2
S -- --
58
XJPS730P08WS0 Screw, x4
R AA AA
59 RCORFA064WJZZ FPC WireFerrite Core, x2 D
REF No. PARTS DESCRIPTION * SN CODE EX CODE
1
CCABAB443WJ01 Cabinet A Ass'y (LC-37GD8E/RU)
S -- --
1
CCABAB443WJ02 Cabinet A Ass'y (LC-37BT8E/RU)
S -- --
1_1
Not Available Cabinet A
- - -
1_2
GCOVAB478WJSA R/C, LED Cover
S -- --
1_3
HBDGBA060WJSA Badge, "SHARP"
S -- --
1_4
LX-HZA003WJFN Screw, x2
S -- --
1_5
PSPAHA858WJZZ Mask Spacer, x2
S -- --
1_6
PSPAHA859WJZZ Mask Spacer, x2
S -- --
1_7
PSPAZB211WJZZ Spacer for Speaker, x4
S -- --
1_8
QCNW-E413WJQZ Connecting Cord
S -- --
1_9
QCNW-E801WJQZ Connecting Cord
S -- --
1_10
RCORF0103CEZZ Ferrite Core, x1
R AK AK
1_11
RCORFA023WJZZ Ferrite Core, x2
R AK AK
1_12
RSP-ZA184WJN1 Speaker-L
S -- --
1_13
RSP-ZA184WJN2 Speaker-R
S -- --
1-14
XEBS930P08000 Screw, x2
R AA AA
2
CCABBA714WJ01 Cabinet B Ass'y
S AY BM
2_1
Not Available Cabinet B
- - -
2_2
LHLDWA055WJKZ Wire Holder, x1
R AC AC
2_3
PSPAHA823WJZZ Spacer-A, x1
S -- --
2_4
PSPAHA824WJZZ Spacer-B, x1
S -- --
2_5
PSPAHA834WJZZ Spacer-C, x2
S -- --
2_6
PSPAHA826WJZZ Spacer-D, x2
S -- --
3
CCOVAB480WJ01 Top Cover Ass'y
S -- --
3_1
Not Available Top Cover
- - -
3_2
JBTN-A524WJKA Power Button
S -- --
3_3
JBTN-A525WJKA Operation Button
S -- --
3_4
MSPRCA068WJFW Spring, for Power Button
S -- --
3_5
XEBS930P08000 Screw, x3
R AA AA
4
CDAI-A290WJ01 Stand Support Ass'y (LC-37GD8E/RU)
S -- --
4
CDAI-A290WJ03 Stand Support Ass'y (LC-37BT8E/RU)
S -- --
4_1
Not Available Stand Support
- - -
4_2
GDAI-A290WJSA Support Cover (LC-37GD8E/RU)
S -- --
4_2
GDAI-A290WJSC Support Cover (LC-37BT8E/RU)
S -- --
4_3
HDECQA600WJKA Decoration Cover, x4
S -- --
5
CDAI-A301WJ01 Stand Base Ass'y (LC-37GD8E/RU)
S -- --
5
CDAI-A301WJ03 Stand Base Ass'y (LC-37BT8E/RU)
S -- --
5_1
Not Available Stand Base Cover
- - -
5_2
LANGKA635WJZZ Base Angle
S -- --
5_3
PSPAZA949WJZZ Leg Cushion A, x4
S -- --
5_4
PSPAZA950WJZZ Leg Cushion B, x4
S -- --
5_5
XEBS740P10000 Screw, x10
S -- --
6
R1LK370T3LZ5BX 37" LCD Panel Module
R EZ EZ
7
GCOVAB488WJKA Stand Cover
S -- --
8
HINDPB763WJSA Model Label
�(LC-37GD8EE/EK/EF)
S -- --
8
HINDPB764WJSA
Model Label�(LC-37GD8EI) S -- --
8
HINDPB765WJSA
Model Label�(LC-37GD8RU) S -- --
8
HINDPB794WJSA Model Label
�(LC-37BT8EE/EK/EF)
S -- --
8
HINDPB795WJSA
Model Label�(LC-37BT8EI) S -- --
8
HINDPB796WJSA
Model Label�(LC-37BT8RU) S -- --
9
LANGKA672WJFW LCD Angle C, x1
S -- --
10
LANGKA675WJFW LCD Angle, x4
S -- --
11
LANGTA266WJFW Stand Angle
S -- --
12
LANGTA268WJFW Center Angle (L)
S -- --
13
LANGTA269WJFW Center Angle (R)
S -- --
14
LCHSMA324WJZZ Chassis Tray
R
15
LHLDW1033CE00 Wire Holder, x1
R
16
LHLDW1123GEZZ Wire Holder, x3
R AB AB
(LC-37GD8E/RU, LC-37BT8E/RU)
CABINET AND MECHANICAL PARTS LISTING
